Summary of Contents for Anern 3.2KW
- Page 1 USER MANUAL KW / 5KW HYBRID SMART SOLAR SYSTEM VERSION:1.0 Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 2: Table Of Contents
SPECIFICATIONS ............................32 ........................32 ABLE PECIFICATIONS ......................33 ABLE NVERTER PECIFICATIONS ......................... 34 ABLE HARGE PECIFICATIONS .......................... 34 ABLE ENERAL PECIFICATIONS TROUBLE SHOOTING ..........................35 APPENDIX: APPROXIMATE BACK-UP TIME TABLE ................36 Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 3: About This Manual
13. Warning!! Only qualified service persons are able to service this device. If errors still persist after following troubleshooting table, please send this inverter/charger back to local dealer or service center for maintenance. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 4: Introduction
Consult with your system integrator for other possible system architectures depending on your requirements. This inverter can power all kinds of appliances in home or office environment, including motor-type appliances such as tube light, fan, refrigerator and air conditioner. Figure 1 Hybrid Power System Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 5: Product Overview
1. LCD display 2. AC output Reserve 3. Power on/off switch 4. DC breaker 5. PV input 6. AC output 7. AC input 8. Communication port 9. GND terminal 10. Circuit breaker Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 6 External battery method 1. Users can set up their own external batteries according to their own needs. 2. The external battery pack voltage shall be in line with the system requirement voltage（3.2KW/24V 5KW/48V） ，Battery capacity reference back-up time. 3. The external battery access location is the DC breaker input side. Note the positive and negative polarity of the battery, and the battery pack cannot be short-circuited.
-
Page 7: Installation
Be sure to keep other objects and surfaces as shown in the diagram to guarantee sufficient heat dissipation and to have enough space for removing wires. SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 8: Battery Connection
Installation must be performed with care due to high battery voltage in series. CAUTION!! Before making the final DC connection or closing DC breaker/disconnector, be sure positive (+) must be connected to positive (+) and negative (-) must be connected to negative (-). Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 9: Ac Input/Output Connection
4. Then, insert AC output wires according to polarities indicated on terminal block and tighten terminal screws. Be sure to connect PE protective conductor ( ) first. →Ground (yellow-green) L→LINE (brown or black) N→Neutral (blue) 5. Make sure the wires are securely connected. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 10: Pv Connection
10 pieces in serial and 2 sets in parallel 20 pcs 5000W PV Module Wire Connection 4.7 Final Assembly After connecting all wirings, please put bottom cover back by screwing two screws as shown below. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 11 Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 12: Communication Connection
GPRS module. Download APP and installed from APP store, and Refer to “GPRS RTU Quick Installation Guideline” to set up network and registering. The inverter status would be shown by mobile phone APP or webpage of computer. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 13: Operation
Output is powered by utility in Line mode. Green Flashing Output is powered by battery or PV in battery mode. Solid On Battery is fully charged. Green Flashing Battery is charging. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 14 Function Keys Function Key Description To exit setting mode To go to previous selection DOWN To go to next selection ENTER To confirm the selection in setting mode or enter setting mode Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 15: Lcd Display Icons
Bottom three bars will be on and the top Voltage mode > 2.167 V/cell bar will flash. Floating mode. Batteries are fully charged. 4 bars will be on. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 16 Indicates unit connects to the PV panel. Indicates load is supplied by utility power. Indicates the utility charger circuit is working. Indicates the DC/AC inverter circuit is working. Mute Operation Indicates unit alarm is disabled. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 17: Lcd Setting
12. Maximum charging current: To configure total charging current for solar and utility chargers. (Max. charging current = utility charging current + solar charging current) Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 18 Maximum utility charging current 30A (default) Note: If setting value in program 02 is smaller than that in program in 11, the inverter will apply charging current from program 02 for utility charger. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 19 “Solar first” in program 01. 46V (default) Available options in 3.2KVA model: Setting voltage point back Battery fully charged to battery mode when selecting “SBU priority” or “Solar first” in program 01. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 20 24.5V 25.5V 26.5V 27V (default) 27.5V 28.5V Available options in 5KVA model: Battery fully charged 54V (default) Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 21 Alarm on (default) Alarm off Beeps while primary source is interrupted Bypass disable (default) Bypass enable Overload bypass: When enabled, the unit will transfer to line mode if overload occurs in battery mode. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 22 Low DC cut-off voltage will be fixed to setting value no matter what percentage of load is connected. Battery equalization Battery equalization disable (default) Battery equalization If “Flooded” or “User-Defined” is selected in program 05, this program can be set up. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 23 Real time setting---Minute Default 00, range 00~23 Real time setting---Hour Default 01, range 01~31 Real time setting---Date Default 01, range 01~12 Real time setting---Month Default 16, range 16~99 Real time setting---Year Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 24: Display Setting
LCD display Input Voltage=230V, output voltage=230V Input voltage/Output voltage (Default Display Screen) Input frequency=50Hz Input frequency PV voltage=260V PV voltage PV current = 2.5A PV current PV power = 500W PV power Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 25 AC and PV charging current=50A PV charging current=50A Charging current AC charging current=50A AC and PV charging power=500W PV charging power=500W Charging power AC charging power=500W Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 26 When connected load is lower than 1kVA, load in VA will present xxxVA like below chart. Load in VA When load is larger than 1kVA (≧1KVA), load in VA will present x.xkVA like below chart. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 27: Operating Mode Description
Charging by utility. batteries. time, the inverter can charge battery without AC output. *Power saving mode: If Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 28 Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 29: Battery Equalization Description
You must enable battery equalization function in monitoring LCD setting program 30 first. Then, you may apply this function in device by either one of following methods: 1. Setting equalization interval in program 35. 2. Active equalization immediately in program 36. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 30 If battery voltage is still lower than battery equalization voltage when battery equalized timeout setting is over, the charge controller will stop equalization and return to float stage. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 31: Fault Reference Code
Overload Beep once every 0.5 second Output power derating Beep twice every 3 seconds PV energy is low. Beep twice every 3 seconds Battery equalization None Battery is not connected None Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 32: Specifications
>95% ( Rated R load, battery full charged ) 10ms typical (UPS); Transfer Time 20ms typical (Appliances) Output power derating: When AC input voltage drops to 170V, the output power will be derated. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 33 Low DC Cut-off Voltage @ load < 50% 21.5Vdc 43.0Vdc @ load ≥ 50% 21.0Vdc 42.0Vdc High DC Recovery Voltage 32Vdc 62Vdc 63Vdc High DC Cut-off Voltage 33Vdc No Load Power Consumption <35W Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
- Page 34 Safety Certification Operating Temperature Range -10°C to 50°C Storage temperature -15°C~ 60°C Humidity 5% to 95% Relative Humidity (Non-condensing) Dimension (D*W*H), mm 710 x 870 x 930 Net Weight, kg（No battery） Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
-
Page 35: Trouble Shooting
Over current or surge. Restart the unit, if the error Fault code 52 Bus voltage is too low. happens again, please return to repair center. Fault code 55 Output voltage is unbalanced. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... -
Page 36: Appendix: Approximate Back-Up Time Table
3200 3500 4000 4500 5000 Note: Backup time depends on the quality of the battery, age of battery and type of battery. Specifications of batteries may vary depending on different manufacturers. Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989... - Page 37 327-100003-00G Web: anern-marketing.com | Email: marketing@anern.com | Whatsapp: +86 13058030989...
