- Page 1 TRANSLATED FROM ORIGINAL USER MANUAL MODULAR MULTIDECK REFRIGERATED DISPLAY RCh-O / RCh-SR 11/2021...
-
Page 2: Table Of Contents
Table of contents 1. Application and device code meaning 2. Product characteristics 3. Cooling system diagram 4. Wiring system 5. Wiring system diagram 6. Drawings 7. Positioning, start-up and operation 8. Maintenance 9. Transport and equipment 10. Temperature controller manual 11. - Page 3 Please read this user manual carefully before using the device and keep it for future reference. Following the manual's recommendations guarantees long-lasting and failure-free exploitation of the device IT IS FORBIDDEN 1. Make repairs on your own and fail to comply with the rules contained in this manual regarding the connection and operation of the device;...
-
Page 4: Application And Device Code Meaning
1. APPLICATION AND DEVICE CODE MEANING The multideck refrigerated display is stationary-type device intended for storing and displaying food products (previously cooled) at a reduced temperature. Device code meaning Example of device code: RCh-SR / 196 / 70 – type of the device: multideck refrigerated display –... -
Page 5: Product Characteristics
2. PRODUCT CHARACTERISTICS > rated voltage: 230V~ / 50Hz > refrigerant: HFC-452A; ODP = 0, GWP = 2140 > operating temperature: +2°C ÷ +10°C > sound pressure level: <70dB (A) Device / module* Device Usable depth of Usable width / depth Usable exposition LED power width... -
Page 6: Wiring System Diagram
5. WIRING SYSTEM DIAGRAM Fig. 1 Electric diagram for RCh-O/125, 188 and RCh-SR/188 1 – electronic temperature controller 2 – compressor 3 – thermal protection 4 – starting relay 5 – starting capacitor 6 – run capacitor 7 – compressor’s electric node 8 –... -
Page 7: Drawings
(finished with a wood-like board - a hole for fixing the night blind) compressor condenser adjustable leg Fig. 4 Cross-section RCh-O Fig. 5 Cross-section RCh-SR... - Page 8 It is possible to install crossbar closer to the back. Only one crossbar is allowed to install on this type of bracket. Screw the crossbar together with brackets. Fig. 6 Permissible load on the crossbar Maximum load of the crossbar, spread evenly over the whole length – 40 kg but maximum load of one hook –...
-
Page 9: Positioning, Start-Up And Operation
cascade formed from two crossbar with „S” crossbars with “S” hooks hooks crossbar with „szpic” hooks Fig. 7 Installation and dimensions of crossbars 7. POSITIONING, START-UP AND OPERATION To ensure correct operation, the multideck refrigerated display should be placed in an area with a good air circulation, away from sources of heat and sunlight, free from dust (the device is not dustproof). -
Page 10: Maintenance
Start-up and beginning operation The cooling unit and lighting are switched on and off using the switches shown in Fig 3. The temperature inside is adjusted by the temperature controller, according to the instructions in p. 10. After switching the device on, leave it empty until it turns off for the first time. -
Page 11: Transport And Equipment
9. TRANSPORT AND EQUIPMENT Secure the device during transport to prevent its overturning, damage to the paint coating and breaking of the glass elements. When handling the device do not press the glass elements, do not grab the cooling unit protective grid to lift the device. - Page 12 SWITCHES DESCRIPTION Information: Short pressing of any of the switches causes appearance of message related to the currently active function.. 7. UP / ON OFF During normal operation of the controller; pressed for longer than 3 sec. will cause change of controller ON/OFF operation state, pressed along with the “DOWN” switch at the same time for longer than 3 sec.
- Page 13 Manual defrost In order to activate the manual defrost press the “DOWN” switch for more than 3 sec. The essential condition is the temperature has to be lower than +6°C. Temperature checking on the defrost probe > press the “SET” switch for longer than 3 sec. (in case there is the alarm is activated it is necessary to switch the sound alarm off first).
- Page 14 Description of the main signals and alarms LED flashing – The activation of the corresponding function is delayed by a timer > awaiting an external signal or disabled by another procedure that is already in progress. e.g. if is a continuous cycle in progress and a defrost is called, the latter will remain pending until the end of the continuous cycle, and the corresponding LED (defrost) will flash.
-
Page 15: Interferences
11. INTERFERENCES The most often occurring interferences of the device operation: Reasons Symptoms Solution > Contaminated Before cleaning of the condenser it is Visible dust layer on the condenser fins, > condenser necessary to switch the device off. hot air coming out of the aggregate chamber, Impurities on the condenser should be >... - Page 16 Poland. The package should be removed according to the regulations of environmental protection. „RAPA” S. Międlar W. i I. Szymańscy sp. j. Service: POLAND, 20-149 Lublin, 9 Ceramiczna Street tel. +48 81 718 46 08 nr rej.
