Product: IEEE 802.11g 54Mbps Wireless Network PC Card

Model: WL 01 2454 25M0

54Mbps wireless Network

PC Card

USER MANUAL

Marketing Dept.

Editorial:

George Chou

Approved By:

54Mbps Wireless Network PC Card

DOCUMENT

USER MANUAL

REV.

1.1

REV. DATA

09/23/2004

GST Confidential

Table of Contents

Need help?

Do you have a question about the WL 01 2454 25M0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Sun Tech WL 01 2454 25M0

Page 1 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 54Mbps wireless Network PC Card USER MANUAL Marketing Dept. Editorial: George Chou Approved By: 54Mbps Wireless Network PC Card DOCUMENT USER MANUAL REV. REV. DATA 09/23/2004 GST Confidential...
Page 2 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 Version History Version Description Date Editor V1.0 Raymond Create the file 4, Agu, 2004 George Chou V1.1 Raymond Delete encryption few 23,Sep,2004 Jessica Yang contents GST Confidential...
Page 3: Table Of Contents
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 Contents Overview ....................4 Product Feature ................4 System Requirement ................4 Getting Start....................5 LED Indicators ..................5 Install the 802.11g Wireless Network PC Card .........5 2.2.1 Utility Installation ..............5 2.2.2 Driver Installation ..............8...
Page 4: Overview
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 1. Overview 1.1 Product Feature ● Compliance with IEEE 802.11g and 802.11b standards ● Highly efficient design mechanism to provide unbeatable performance ● Achieving data rate up to 54Mbps for 802.11g and 11Mps for 802.11b with wide range coverage;...
Page 5: Getting Start
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 2. Getting Start 2.1 LED Indicators The Power LED will be ON when the unit is powered up. The Link LED will be Blinking indicates a WLAN connection.
Page 6 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 InstallShield Wizard will automatically start. Please click “Next” to continue. If user wants to change the installation folder, press “Brower” to change the directory or press “Next” to continue.
Page 7 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 Users can also rename the installation folder, type the name in the column, or press “Next” to continue. Click “Finish” to finish the installation. Restart computer to make the settings effective.
Page 8: Driver Installation
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 2.2.2 Driver Installation 1. After restarting the computer, insert the PC card into cardbus. Few seconds later, there will be a window popup as the following picture.
Page 9 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 3. Click “Finish” to finish the driver installation. 4. To make sure if the installation is successful, you could check it through the device management. GST Confidential...
Page 10 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 5. Once the installation is successful, a utility program icon will show on your desktop. To lunch the utility, just double click the icon. GST Confidential...
Page 11: Configuration
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 3. Configuration 3.1 Link Information The default page is as below after you launch the Utility program. Status: Shows the BSSID associated, which can be used to identify the wireless network.
Page 12: Configuration
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 3.2 Configuration This is the page where you can change the basic settings of the Access Point with the minimum amount of effort to implement a secure wireless network environment.
Page 13: Advanced
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 transmitted at 1Mbps that allows the PHY circuitry to reach steady-state demodulation and synchronization of bit clock and frame start. Two different preambles and headers are defined: the mandatory supported Long Preamble and header, which interoperates with the 1 Mbit/s and 2 Mbit/s DSSS specification (as described in IEEE Std 802.11), and an optional Short Preamble...
Page 14 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 If WPA-PSK is selected, click the configuration button. The popping window is as the below. Please enter the key. Auth. Mode: There are three modes available to choose.
Page 15: Site Survey
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 3.4 Site Survey This page allows you to enable the Site Survey function to scan for the available wireless network (wireless clients and Access Points) and establish wireless communications with one.
Page 16: About Us
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 3.5 About US This page displays some information about the 54Mpbs wireless LAN PC card utility, which includes the version numbers for Driver, Firmware and Utility. When there is new version of software available for upgrade, you will be able to identify by version numbers.
Page 17: Glossary
Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 4. Glossary Access Point: An internetworking device that seamlessly connects wired and wireless networks. Ad-Hoc: An independent wireless LAN network formed by a group of computers, each with a network adapter.
Page 18 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 BSS: BSS stands for “Basic Service Set”. It is an Access Point and all the LAN PCs that associated with it. Channel: The bandwidth which wireless Radio operates is divided into several segments, which we call them “Channels”.
Page 19 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 to become Extended Service Set. LAN mobile users can roam between different BSSs in an ESS. ESSID: The unique identifier that identifies the ESS. In infrastructure association, the stations use the same ESSID as AP’s to get connected.
Page 20 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 Multiple Bridge – One of the additional AP operating modes offered by 54Mbps Access Point, which allows a group of APs that consists of two or more APs to connect two or more Ethernet networks or Ethernet enabled clients together.
Page 21 Product: IEEE 802.11g 54Mbps Wireless Network PC Card Model: WL 01 2454 25M0 are set up with direct access to the Internet, your computer is provided with a copy of the TCP/IP program just as every other computer that you may send messages to or get information from also has a copy of TCP/IP.
Page 22 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
