Mesh Nebulizer User Manual
Brief Introduction
This device utilizes state-of-the-art microporous atomizing mesh technology that
sprays liquid medication into aerosol/vapor form and delivers it directly to the
patient for inhalation. Both adult and pediatric patients suffer from asthma,
Chronic Obstructive Pulmonary Disease (COPD) such as emphysema and chronic
bronchitis, or other respiratory disease that are characterized by obstruction to air
flow and/or patients who are on and off ventilation or other positive pressure
breathing assistance.
Warning
For pure soluble liquid only. Please don't use purified water, oil, milk, or thick
liquid. The atomization volume varies varies with the concentration of the
liquid.
Clean the mesh plate after each use to avoid blockage. Note: Do not touch the
mesh with your hand, brushes or any hard objects.
Do not rinse or immerse the nubulizer in any liquid. Any liquid spilled on or
inside the nubulizer should be allowed to dry before operating.
Do not place the nubulizer on heated surfaces.
Do not turn on the nebulizer when the medicine container has no liquid.
Description of Device and Accessories
1.
Medicine container lid
2.
Medicine container
3.
Nebulizer
4.
Charge port
5.
ON/OFF button / operation LEDs
6.
Masks (2)
7.
Mouthpieces (2)
8.
Mesh plate cover
9.
USB charging cable
7
6
4
5
1
2
3
8
9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Dr. Clark Mini
- Page 1 Mesh Nebulizer User Manual Brief Introduction This device utilizes state-of-the-art microporous atomizing mesh technology that sprays liquid medication into aerosol/vapor form and delivers it directly to the patient for inhalation. Both adult and pediatric patients suffer from asthma, Chronic Obstructive Pulmonary Disease (COPD) such as emphysema and chronic bronchitis, or other respiratory disease that are characterized by obstruction to air flow and/or patients who are on and off ventilation or other positive pressure breathing assistance.
- Page 2 Function Three atomization modes: strong, medium and weak. Chose the modes by pressing the ON/OFF button. LED light indicator. The light turns yellow when the atomizer is charging. It turns green when it completes charging and is ready to atomize. It turns green and yellow alternately when it is performing an automatic cleaning.
- Page 3 Recharge the device every two months to ensure longer battery life. Device and Accessories 1 x Mini nebulizer 1 x USB cable 2 x Face masks (for kids and adults) 2 x Mouthpieces...
- Page 4 Troubleshooting / FAQ Problem / Question Possible Cause / Answer The nebulizer produces Insufficient medicine in the nebulizer. little or no aerosol The nebulizer is not held in an upright position. The medicine used is unsuitable for spraying (e. g. too thick, viscosity must be less than 3). The indoor temperature is too low.
