Contec DS-220D-M01 Product Manual

(Fanless, Atom E3845, CFast, LINUX, DVI-I)
At first, read "Safety Precautions" and make proper use of this product.
Product Configuration List
Name
The main body *1
The attachment fittings
VESA fitting bracket
CFast card removal prevention fitting
USB removal prevention fitting
USB removal prevention clamp.
Washer assembled screw (M3 x 6, black)
*1 The hardware specifications are the same as the hardware specifications in "BX-220D-DC661211" except for the
following section "The difference from BX-220D-DC661211". For reference, download the user's manual of
"BX-220D-DC661211" from the CONTEC homepage.
*2 Do not use this AC power cable with any devices except for an attached AC adaptor.
Product Configuration Image
Body
CFast card removal Washer assembled screw
prevention fitting
(M3x6, black)
USB removal
prevention fitting
* See the Product Configuration List to check if all the components are included for the specified number of units.
1
Digital Signage Player
DS-220D-M01
Product Guide
CONTEC CO., LTD.
Pcs.
1
2
2
1
1
2
6
The attachment Cable clamp
fittings
Washer assembled and
cross recessed hexagonal bolt
(M4x10, black)
Product Guide
Product Registration
Warranty Certificate
Product Registration Card
Product Guide
& Warranty Certificate
Name
Washer assembled and cross recessed
hexagonal bolt (M4 x 10, black)
Cable clamp
AC adaptor
AC cable *2
Product guide (this sheet)
Sirial number label
License sheet
USB removal prevention clamp
AC adaptor
Card &
XXXXXXXXXXXXX
XXXXXXXXXXXXX
Serial number label
Pcs.
4
1
1
1
1
1
1
VESA fitting bracket
AC cable
License sheet
License sheet
DS-220D-M01
