EE Systems Group eLEDing EE803WLL Quick Start Manual

SOLAR
Walkway LED LIGHT
LANDSCAPE GARDEN PATH

Working Profile

2. Evening
Automatically
ON with dim
brightness level
light
eLEDing EE803WLL
SOLAR PANEL
2
ON/OFF
3
LED LIGHTING
4
BASE
1.Charging during day
3. Light turning with Max
brightness once detect
sound activated around
3
Solar Powered Walkway Smart LED Light

Specification

Solar Panel: 3W PET
Battery: 2.6AH
LED: Super LEDs 3W
Color: Warm White;
(Option: Blue, Green for dim)
Material: Aluminum Alloy
Solar Charging Time: 9-10Hrs
Lighting Time: Over 3 nights
Product Size:24" x 7"
Waterproof: IP65
Warranty: 1 Year

Installation

1. Setup support base on top with solar
1)
panel via 4 screws
2. Connect solar panel cable
3. Turn on the light by push the switch by
momentary
4. Fasten the base w/ screws on the
ground/floor or 6" x 4" wood base etc.
4, When there is no
sound activated
around, it dims lower
brightness until dawn
2
3
4
