Ultimaker S5 Air Manager
Repair manual: Air Manager fan
Introduction
In case of the error message ER86 - Air Manager fan is unable to rotate at the desired speed, the fan of the Air Manager must be
replaced. Ultimaker continues to investigate ER86 occurrences, and requires the batch number of aff ected fans.
This document describes how to remove the fi lter housing and how to open it up to access the fan on pages 2-3. Please share the
fan batch information with your support contact. Pages 4-5 describe how to install the replacement fan and how to reassemble the
Ultimaker S5 Air Manager.
Requirements
To remove and open the fi lter housing, you only need one
tool, which was included with the Air Manager accessories:
• Hex key 2.5 mm
Notes
Caution:
Make sure the Ultimaker S5 is turned off , and the
power cable is disconnected before you start the replacement.
Tip:
You do not need to use the Air Manager removal tools; the
mounting bracket will stay installed on the printer.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S5 Air Manager and is the answer not in the manual?

Questions and answers

Related Manuals for Ultimaker S5 Air Manager

Summary of Contents for Ultimaker S5 Air Manager

  • Page 1 In case of the error message ER86 - Air Manager fan is unable to rotate at the desired speed, the fan of the Air Manager must be replaced. Ultimaker continues to investigate ER86 occurrences, and requires the batch number of aff ected fans.
  • Page 2 Push back against the mounting bracket while pushing the Note: This requires some force. The fi lter housing will come loose fi lter housing forwards. with a loud snapping sound; this is normal. Ultimaker S5 Air Manager Repair manual: Air Manager fan...

  • Page 3: Remove The Fan

    Please share the fan’s batch number, as shown in this Note: Do not touch the PCB while disconnecting the fan. photo, with your support contact. Ultimaker is collecting data on aff ected fans. Ultimaker S5 Air Manager Repair manual: Air Manager fan...
  • Page 4 6. Tighten each of the four M4x45 screws to secure with the fi lter housing the fi lter housing parts Note: The orientation of the fan guard should be as Tools: 2.5 mm hex key shown in this picture Ultimaker S5 Air Manager Repair manual: Air Manager fan...
  • Page 5 The fl at side of the connector faces towards the printer. Note: The cable must be fully inserted and held in place with the clip to ensure the most reliable connection. Finished! You can now power on the Ultimaker S5 again. Ultimaker S5 Air Manager Repair manual: Air Manager fan...
