- Page 1 Maple Armor FW6308-CLA1 Intercom 3G Wireless Building door phone Operating/Programming/Installation Manual DOC-FW6308-CLA1...
-
Page 2: Table Of Contents
Table of Contents SYSTEM FEATURES AND PARAMETERS ..................2 USER OPERATION ......................... 3 1) M ............................3 2) C : ............................3 ALLING 3) P : ........................3 ASSWORD TO UNLOCK 4) T : ......................... 3 UNCTION 4.1) Instructions ..........................3 4.2) Query............................ -
Page 3: System Features And Parameters
System Features and Parameters Mature mobile communication technology. Inset a Mobile SIM card and memory card into outdoor station, Frequency Range: UMTS/HSDPA: Quad band, 850/900/1900/2100MHz. GSM/GPRS/EDGE: Quad band, 850/900/1800/1900Mhz. This Product only support GSM network system, do not support CDMA Two working mode: 2G and 3G mode. -
Page 4: User Operation
User Operation 15 GSM 02:47 01.06.2016 WELCOME Insert Room No.&#To Dial 1. Outdoor station main menu shows: . Show “GSM” means under 2G mode, show “3G” means under 3G mode, will automatically Or Press #2 For Name List Dial# Exit* switch, number “15”... -
Page 5: User Set
* Speaker volume: Press to enter the page of speaker volume: , 0-7 for the speaker volume level. The higher value, the louder. Operation:0 Volume: 6 >_ The page shows "Speaker Volume: 6" means the current speaker volume. Return to previous post automatically when enter the relative number. * Set time: Press to enter the page of time setting, and could set your locate time. - Page 6 Please note only need open “ regoxc.bat" for one time on same PC. * Next to open the software “ DZ-GSM1.exe", press-- NEW, could see “please enter a new file name”, the enter name as --“contact_info.txt" (please note, the name must be same like it) as below pics, next step could to edit users details.
-
Page 7: Sms Functions
SMS functions I. Administrator SMS to modify user information: *Modified the username: 02*#NNNN#cccc, NNNN means room number, cccc means username. * Modified the user phone numbers: 03*#NNNN#10086, 03 means operating instruction for modified the first phone no, NNNN means room number, 10086 means phone number. 04*#NNNN#10086, 04 means operating instruction for modified the second phone no, NNNN means room number, 10086 means phone number. -
Page 8: Administrator Sms To Modify Unlocking Code
IV.Administrator SMS to modify unlocking code: SMS modify Public unlocking code: 00*#New Password (Length of new code much same as the device setting code). 2)SMS to modify Personal unlocking code (Must be 6 digits): 01*#NNNN#CCCCCC (NNNN means 4 digits room number, CCCCCC means 6 digits new code). -
Page 9: Installation Instructions
Installation Instructions 1. Product wiring diagram SD card socket SIM card socket Main circuit board The button for Going out Access control Speaker... -
Page 10: Dimensions
2. Dimension Side Front Back 3. Against the wall box and Hole Size against the wall box hole size Front Side...
