Summary of Contents for SGS Trio OEK-400
- Page 1 CONVEYOR TOASTER (OEK-400) USER’S AND MAINTENANCE MANUAL PRODUCTION YEAR: SERIAL NO : 2009 Published on : 23.01.2004 VER:V11.7 Page1 of 12...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE NR. TOPICS COVER PAGE TABLE OF CONTENTS INTRODUCTION TECHNICAL DATA WARNING SIGNS SAFETY DETAILS TRANSPORTING AND MOVING INSTALLATION OF THE DEVICE AND ELECTRICAL CIRCUIT DIAGRAM 10-11 OPERATION OF THE DEVICE TERMS OF GUARANTEE CAUTION This device should only be used in facilities where relevant standards, laws and safety requirements are complied with 2/12... -
Page 3: Introduction
INTRODUCTION Dear User, Thank you for purchasing our device and for your reliance upon our company. Our devices have been used within our customers kitchen, your kitchen in 110 countries. Our devices are produced in compliance with international standards. Important notice: Please read or ensure that the users read this user’s manual in order to achieve the desired performance in line with your expectations and to use your device for long years. -
Page 4: Technical Data
TECHNICAL DATA TECHNİCAL SPECIFICATION OEK-400 TOTAL ELECTRICAL INPUT (kW) SUPPLY VOLTAGE (VAC) 220/240 WORKING FREQUENCY (Hz) 50/60 POWER SUPPLY CABLE (Number of cores x mm²) 3x1,5 DIMENSIONS (Width-Length-Height) (mm) 440x400x340 BENCH HEIGHT (mm) MAXIMUM SLOPE 5 ° CLASS PROTECTION CLASS IP 20 CAPACITY (slices per hour) 4/12... -
Page 5: Warning Signs
WARNING SIGNS POWER NETWORK GROUNDING GROUNDING POWER OVERHEAT VOLTAGE: 220/240V NPE - ~50/60 Hz SUPPLY CONNECTION: MONOPHASE / GROUNDED 5/12... -
Page 6: Safety Details
SAFETY DETAILS ☞ Supply voltage of the device is 220-240V 50 Hz. Do not use different voltage. ☞ Power supply connection should be made using a 30 mA current leakage fuse as a protection against current leakage danger. ☞ The device should not be immersed in water and should not be cleaned up with pressure water. -
Page 7: Transporting And Moving
TRANSPORTING AND MOVING TRANSPORTING : ☞ Before moving disconnect from the power supply. ☞ The vehicle can be moved with manpower. ☞ Do not hit or drop the device when moving. Machines installed by an authorized service CANNOT BE MOVED ELSEWHERE, ITS POWER SUPPLY CABLES CANNOT BE EXTENDED OR REPLACED except by an authorized service. - Page 8 INSTALLATION DIAGRAM AND INSTALLATION OF THE DEVICE 1. Resistance 2. Turning rate setting button 3. Slices outcome tray 4. Conveyor 5. Slice feeding panel 6. Outcome direction setter 7. Power supply cable 8. Commutator - Workbench on which the device stands should be adjustable and leveled with balance. - Power connections should be checked by an eligible electrician and the device should be connected to a fuse at 400 mm.
-
Page 9: Electrical Circuit Diagram
ELECTRICAL CIRCUIT DIAGRAM S1 : Commutator S2 : Rate Setting Button RA : Lower Resistance RU : Upper Resistance M1 : Motor M2 : Fan d : Diode 9/12... - Page 10 OPERATION OF THE APPLIANCE OPERATION OF THE DEVICE: Conveyor toaster is used in kitchens of restaurants, fast food stands, canteens, hospitals in order to Roast bread. Before initial use of the device, the outer surface should be wiped with a cloth soaked in warm water and soap.
-
Page 11: Operation Of The Device
OPERATION OF THE DEVICE CLEAN-UP AND MAINTENANCE Clean-up and maintenance should be accomplished by the consumer Before (before the power is switched on) and after the first use and every subsequent use, outer surface of the device should be completely cleaned up with sponge and liquid detergent. -
Page 12: Terms Of Guarantee
TERMS OF GUARANTEE 1- Documents without sales date, factory and sales company approval on, are not valid. In order to benefit from the guarantee, guarantee document should be presented. 2- If the device is installed and operated following the instructions in the installation, maintenance and user's manual, it is warranted for failures resulting from failures resulting from workmanship and material failures.
