- Page 1 Assembly Instructions Electric cylinder Lambda ..........28 Ausgabe: 10.2017 PM-Nr.: B.015842 Version: 1-2...
-
Page 2: Table Of Contents
Table of Contents 1. Declaration of incorporation 1.1 Declaration of incorporation for the Lambda electric cylinder ......30 2. General notes 2.1 Notes on these assembly instructions ..............32 3. Liability/Warranty 3.1 Liability ........................33 3.2 Product monitoring ....................33 3.3 Language of the assembly instructions .............. - Page 3 Table of Contents 7. Life phases 7.1 Electric cylinder scope of delivery ................43 7.3 Transport and storage ..................... 43 7.3 Important information on installation and putting into operation ...... 44 7.4 Electrical connecting possibilities ................45 7.4.1 Electrical connection with plug ..............45 7.4.2 Electrical connection with cable ..............
-
Page 4: Declaration Of Incorporation
1. Declaration of Incorporation 1.1 Declaration of incorporation for the Lambda electric cylinder As set out in Machinery Directive 2006/42/EC, Annex II, 1.B for partly completed machinery The manufacturer The person in the community that is authorised to compile the... - Page 5 1. Declaration of Incorporation The manufacturer or the person authorised are obliged to hand over the special documents for the partially completed machine to the national authorities on reasoned request. This transmission is carried out electronically. The commercial protective rights remain unaffected by this. Important note! The partially completed machine must not be put into operation, until, if required, it has been determined that the machine in which the partially completed machine is to be installed complies with the regulations of this guideline.
-
Page 6: General Notes
2. General notes 2.1 Notes on these assembly instructions These assembly instructions are documentation which is only valid for the electric cylinder described and are intended for the manufacturer of the end product into which this partly completed machinery is to be installed. We wish to explicitly point out that the manufacturer of the end product must produce operating instructions for the end user containing all the functions and hazard warnings of the end product. -
Page 7: Liability/Warranty
Only original spare parts may be used when undertaking repair and maintenance. Phoenix Mecano Komponenten AG does not accept any liability for spare parts that have not been tested and approved for use by Phoenix Mecano Komponenten AG. -
Page 8: Use/Operators
Moving persons with this electric cylinder, for example, is an example of improper use and is forbidden. In event of improper use, Phoenix Mecano Komponenten AG is no longer liable for this electric cylinder and its general operating licence will expire. -
Page 9: Safety
5. Safety 5.1 Safety instructions Phoenix Mecano Komponenten AG has built this electric cylinder according to the current state of the art and existing safety regulations. Nonetheless, this electric cylinder can pose risks to persons and property if it is used improperly or for a non-intended use or if the safety instructions are not observed. -
Page 10: Special Safety Instructions
• reasons. The performance specifications of these electric cylinder specified by • Phoenix Mecano Komponenten AG must not be exceeded. The type plate must remain legible. It must be possible to identify the ratings data effortlessly at • any time. -
Page 11: Product Information
5 mm/s 8 mm/s 21 mm/s 6.3 Variants The following versions are available for the Lambda electric cylinder: • Without anti-trap protection: pull and press at full force. • With anti-trap protection with tensile: press with full force and pull with very little force. With •... -
Page 12: Dimensions Of The Geometry
6. Product information 6.4 Dimensions of the geometry can be rotated by 90 deg. can be rotated by 90 deg. Adjustment without power Additional connecting options Connecting plug at with cable variant with potentiometer... -
Page 13: Technical Specification
6. Product information 6.5 Technical specifications Version 1 Version 2 Version 3 Stroke length up to 400 mm up to 600 mm Stroke smaller than 400 mm = Stroke+175 mm Dimension A - Installation dimension Stroke greater than or equal to 400 mm = Stroke+225 mm Standard lifting length 100;... -
Page 14: Performance Chart, Version 1
6. Product information 6.5.1 Performance chart, version 1 max. 6,000 N pressure max. 4,000 N tension 5 mm/s lifting speed max. up to 400 mm lift Lifting force 6.5.2 Performance chart, version 2 max. 4,500 N pressure max. 4,000 N tension 8 mm/s lifting speed max. -
Page 15: Performance Chart, Version 3
6. Product information 6.5.3 Performance chart, version 3 max. 2,000 N pressure max. 2,000 N tension 21 mm/s lifting speed max. up to 600 mm lift Lifting force... -
Page 16: Electric Cylinder Overview Diagram
6. Product information 6.6 Electric cylinder overview diagram Hood Linch pin Limit switch unit Push rod Guide tube Suspension "front" Adjustment without power (optional) Bearing Suspension "rear" O ring seal Worm gear shaft Trapezium spindle Gear housing Auger Motor Seal... -
Page 17: Life Phases
Lowest/highest ambient temperature: -20 °C/+60 °C • Relative humidity: from 30 % to 75 % • Air pressure: from 700 hPa to 1060 hPa • Falling below the dewpoint is not allowed Divergent environmental factors must be approved by Phoenix Mecano Komponenten AG. -
Page 18: Important Information On Installation And Putting Into Operation
7. Life phases 7.3 Important information on installation and putting into operation It is essential that you note and observe the following instructions. Otherwise persons could be injured or the electric cylinder or other components could be damaged. • No additional holes may be made in the electric cylinder. •... -
Page 19: Electrical Connecting Possibilities
7. Life phases 7.4 Electrical connecting possibilities 7.4.1 Electrical connection with plug The electric cylinder is installed with a 2-pin device socket + as standard. The socket complies with DIN43650-A / ISO4400. Thermoswitch Linch pin S1= Limit switch for traversing direction -extract- S2= Limit switch for traversing direction -retract- M= Permanent magnet motor = Thermoswitch... -
Page 20: Electrical Connection With Cable
7. Life phases 7.4.2 Electrical connection with cable The electric cylinder wit potentiometer is supplied with an Amphenol device plug, number of poles 6 + PE; series C16-1. Thermoswitch Linch pin S1= Limit switch for traversing direction -extract- S2= Limit switch for traversing direction -retract- M= Permanent magnet motor = Thermoswitch With (+) at connection... -
Page 21: Electrical Connection With Integrated Potentiometer
7. Life phases 7.4.3 Electrical connection with integrated potentiometer The Lambda Colonne wit potentiometer is supplied with an Amphenol device plug, number of poles 6 + PE; series C16-1. Linch pin S1= Limit switch for traversing direction -extract- S2= Limit switch for traversing direction -retract-... -
Page 22: Adjustment Without Power (Can Be Extracted)
The stroke of the cylinder originally set is not changed when using the Bowden cable. The adjustment force required on the push rod after releasing using the Bowden cable is different depending on the configuration of the Lambda electric cylinder: Version 1: approx. 300 N Version 2: approx. -
Page 23: Fitting And Installation
7. Life phases 7.5.3 Fitting and installation Never pretension the Bowden cable when it is in a free state otherwise there is a risk of releasing the push rod. Thereafter, the electric cylinder will not fulfil its function in operation. There is a risk of damage when applying a little force. -
Page 24: Installation
7. Life phases 7.6 Installation Check for any damage or missing components after receipt of the electric cylinder. The electric cylinder will be delivered read for operation without a controller. The fixing of the electric cylinder is carried out using the fork heads on the push rod and the gear housing. -
Page 25: Installation Procedure / Installation Sequence
7. Life phases 7.6.1 Installation procedure / installation sequence • Hang the rear suspension onto the "counter-piece". The counter-piece must not be able to be twisted. The electric cylinder must be able to be rotated in the direction of the arrow (see graphic). •... -
Page 26: Maintenance
7. Life phases • Connect to the respective controller. • Perform the test run / initial run without load and check the function of the system. 7.7 Maintenance The electric cylinder generally does not require servicing, but it is not exempt from wear and tear. You can recognise possible wear on faulty functions, increased play of the moving parts or unusual sounds that originate from the electric cylinder. -
Page 27: Cleaning
7. Life phases 7.8 Cleaning You can clean the hand switch and the outside surface of the electric cylinder's profile using a lint- free, clean cloth. Solvent-based cleaners will corrode the material and can damage it. 7.9 Disposal and return The electric cylinder must either be disposed of in accordance with the applicable regulations and guidelines, or returned to the manufacturer.
