HAND-OPERATED STRAP CUTTER
Congratulations on the purchase of your new
Master Tool Hand-Operated Strap Cutter.
Designed and manufactured by Weaver Leather,
this 8" strap cutter features a table and roll that
adjust together. This hand-operated machine
features a handle that can be mounted in two
positions – one for higher torque, lower speed
applications and one for lower torque, higher
speed applications. With the ability to cut
through most types of leather, this efficient
machine is an economical alternative to cutting
by hand. You'll appreciate the way the ends
remove easily for quick change of blades
and spacers and the roller bearings that
ensure trouble-free operation.
Your machine is assembled and ready to
use after you mount it to a solid wood
bench. This strap cutter features holes and
mounting hardware for your convenience. It comes
set up for 1" straps with spacers and blades. Do
not operate this machine until you have read this
instruction sheet in its entirety. This machine is
designed for cutting leather. Use for any other
purpose is prohibited and voids the warranty.
A - Left Adjustment Wheel
B - Right Adjustment Wheel
C - Metal Fingers
D - Side Bracket
E - Low Speed Adjustment
F - High Speed Adjustment
G - Thumb Screw
H - Locking Lever
I - Thumb Screw
J - Thumb Screw
K - Left-Handed Nut
L - Work Table
M - Chain Guard
N - Guide
O - Wrench
P - Bar
800-932-8371
weaverleathersupply.com
H
D
K
A
P
Included Tools
G
F
E
M
N
I
J
L
N
B
O
HANDCRAFTED IN THE USA
C
C
D
M
H
D
H
L
INSERT-139 7/21
Advertisement
Table of Contents
Summary of Contents for Weaver Leather 65-3085
- Page 1 HAND-OPERATED STRAP CUTTER Congratulations on the purchase of your new Master Tool Hand-Operated Strap Cutter. Designed and manufactured by Weaver Leather, this 8" strap cutter features a table and roll that adjust together. This hand-operated machine features a handle that can be mounted in two positions –...
- Page 2 POSITIONING THE WORK TABLE It is important to position the Work Table (L) correctly to ensure you receive the best cutting performance from the blades. 1. Turn the Adjustment Wheels (A and B) to the left until the blades cut into the bottom of the roll approximately 1/16"...
- Page 3 TROUBLESHOOTING PROBLEM REMEDY Ruined or dull blade edge. Sharpen or replace blades. Weaver Leather offers blade sharpening service. Deep wrinkles on bottom roll. Rearrange spacers and blades on drive shaft or replace bottom roll. Incorrect position of bottom roll Turn the Adjustment Wheels (A and B) to the (it’s too far from blades).
- Page 4 Weaver Leather makes no express warranties other than those that are specifically described herein. This warranty is expressly in lieu of all other warranties express or implied. There are no implied warranties of any kind including merchantability or fitness for a particular purpose. Weaver Leather will in no event be liable for any incidental or consequential damages whatsoever, nor for any sum in excess of the price received for the goods.
