Caution when Installing the Product
Keep the followings to prevent damages, electric shock, fume and fire.
Do not connect to AC power.
NG!
Do not use a tool with sharp point .
NG!
Do not tramp on or strike the product.
NG!
Do not pull out the product diagonally
from the channel.
NG!
Do not bend the product toward
horizontal direction.
NG!
✔ OK
ZTE2TLDRGB(W)
NG!
Horizontal direction
Vertical direction.
Bending radius is 150 mm or more.
Ver. 200416
Advertisement
Table of Contents
Related Manuals for Atex Tsubaki TL10-090DM K Series
Summary of Contents for Atex Tsubaki TL10-090DM K Series
- Page 1 Caution when Installing the Product Keep the followings to prevent damages, electric shock, fume and fire. ZTE2TLDRGB(W) Ver. 200416 Do not connect to AC power. Do not pull out the product diagonally from the channel. Do not bend the product toward Do not use a tool with sharp point .
- Page 2 Tsubaki Seamless Light Type V (TL10D RGBW / RGB) Installation Manual For Keeping We will appreciate for your purchasing the product. Please carefully read this manual to install the product correctly and safely. ※The contents described on this manual are subject to change without prior notice. ZTE2TLDRGB(W) Ver.
- Page 3 Wiring Method □ Total length of serial connected products should be 10.1m (5047mm x 2) or less. If two or more products are used, connect them in parallel so that the serial length does not exceed 10.1 m. □ Cable color means below. White cable: +24V, Red cable: Red, Green cable: Green, Blue cable: Blue, Yellow cable: White □...
- Page 4 ・ Please use the appropriate screws according to the wall. ■ 4. Put and push the product into the channel securely. Use Atex Accessories to install the product. ・ ■ Insert the product ribs securely below the channel Ribs. Do not put the screws on the product directly. It may cause damages.
