JJ Plus W23-JA736101 Series User Manual

W23-JA736101 Mini PCI User's Manual

1. Product Overview

The W23-JA736101 series PCI adapter cards contain an Atheros AR9220
chip for IEEE 802.11b/g/n Wireless LAN applications. The mini PCI adapter
cards support key security features like Wi-Fi Protected Access (WPA),
WPA2, WEP and 802.1x.

2. Packaging Contents

The mini PCI card package contains the following item(s):
1 x Wireless Mini PCI Adapter

3. Installation guide


Shut down the power of the platform

Align the PCI adapter with the Mini PCI socket on the platform
 Adjust and push down the PCI adapter gently until the metal locking
levers on the Mini PCI socket is latched. (Please take note that the PCI
adapter can only fit in one direction due to the keyed notch. Wrong
orientation will cause improper installation and may damage the Mini
PCI socket)
 Connect the antenna(s) on the mini PCI module

Reboot on the platform
 Install drivers if necessary

4. Frequency

802.11b/g/n: 2412 ~ 2472 MHz

5. FCC Statement

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
