User's Manual
LQ-401CL
RGB Color & NIR
4CMOS Line Scan Camera
Document Version:1.2
LQ-401CL_Ver.1.2.Dec2014
1060E-1409

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LQ-401CL and is the answer not in the manual?

Questions and answers

Related Manuals for IAI LQ-401CL

Summary of Contents for IAI LQ-401CL

  • Page 1 User's Manual LQ-401CL RGB Color & NIR 4CMOS Line Scan Camera Document Version:1.2 LQ-401CL_Ver.1.2.Dec2014 1060E-1409...
  • Page 2 CE compliance As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC (Electromagnetic compatibility), JAI Ltd., Japan declares that LQ-401CL complies with the following provisions applying to its standards. CISPR Pub.22 (EN55022) (Emission admissible value and measuring method) CISPR Pub.24 (EN55024) (Immunity admissible value and measuring method)
  • Page 3 LQ-401CL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera.

  • Page 4: Table Of Contents

    LQ-401CL - Table of contents – General ....................... 6 Camera composition ..................6 Main features ....................7 Locations and functions ..................8 4.1. Locations and functions ................8 4.2. Rear Panel ....................9 Connectors and pin assignment ................. 10 5.1.
  • Page 5 Command WB – White Balance ..............53 Serial communication and command list .............. 54 8.1. Serial communication ................54 8.2. Command list ..................55 Camera Control Tool for LQ-401CL ..............61 9.1. Software Install ..................61 9.2. Open the Control Tool ................61 9.3.
  • Page 6 LQ-401CL Exportation ....................70 References ....................70 Change history ....................71 User's Record ..................... 72...

  • Page 7: General

    General The LQ-401CL is a 4CMOS line scan camera using four 4096 pixel line sensors mounted on a prism, for the R, G, B and NIR channels. It operates with an 84 MHz pixel clock, resulting in a maximum line rate of 18,252 lines per second.

  • Page 8: Main Features

    LQ-401CL Main features  4CMOS line scan camera with 4096 pixel resolution  Dichroic beam splitter prism to separate R,G,B and NIR wavelengths  18,252 lines per second scan rate  84 MHz pixel clock  4 x 8 bits or 4 x 10 bits output through Camera Link interface ...

  • Page 9: Locations And Functions

    LQ-401CL Locations and functions 4.1. Locations and functions Fig. 1 Location of external features 1 Lens mount M52 mount (*1)Note) 2 Camera Link connector 1 base connector (1) (*2)Note) 3 Camera Link connector 2 medium connector (2) (*2)Note) 4 12-pin Hirose connector...

  • Page 10: Rear Panel

    LQ-401CL 4.2. Rear Panel ① POW ER / TRIG W . B . D C IN ② /TRIG S W 1 Fig2. Rear panel ① LED Green (Steady)  Operating, but not receiving external trigger input Green (Flashing)  Operating and receiving external trigger input.

  • Page 11: Connectors And Pin Assignment

    LQ-401CL Connectors and pin assignment 5.1. 12-Pin Connector 5.1.1 Pin assignment Type: HR10A-10R-12PB-01 (Male) or equivalent Use the part number HR10A-10P-12S or equivalent for the cable side Pin No. Signal Remarks DC in +12V to +24V Reserved Do not connect...

  • Page 12: Conformable Connector And Cable Assembly

    (Thin diameter type) or 14B26-SZ3B-xxx-04C (High flex type), the cable length for transmission is limited. 5.3.3 Camera Link Interface (Bit allocation) The LQ-401CL follows the Camera Link standard in all respects. Out1_D9～Out1_D0 : Out1_Camera Data (Out1_D9=MSB, Out1_D0=LSB) Out2_D9～Out2_D0 : Out2_Camera Data (Out2_D9=MSB, Out2_D0=LSB) Out3_D9～Out3_D0 : Out3_Camera Data (Out3_D9=MSB, Out3_D0=LSB) Out4_D9～Out3_D0 : Out4_Camera Data (Out4_D9=MSB, Out4_D0=LSB)
  • Page 13 LQ-401CL Port B6 Out2_D6 × Tx10 Port B7 Out2_D7 × Tx11 Port C0 Out3_D0 Out2_D0 Tx15 Port C1 Out3_D1 Out2_D1 Tx18 Port C2 Out3_D2 Out2_D2 Tx19 Port C3 Out3_D3 Out2_D3 Tx20 Port C4 Out3_D4 Out2_D4 Tx21 Port C5 Out3_D5 Out2_D5...

  • Page 14: Camera Link Output Port

    TxOUT0 Fig.6 Camera Link output timing 5.3.4 Camera link output port LQ-401CL handles R, G, B and NIR channels. The output ports for 8-bit and 10-bit are different. 8-bit output Input signal Camera Link output Out 1 Camera Link 1...

  • Page 15: Bit Allocation Of The Output Video

    Fig.9 Signals flow The LQ-401CL uses four high-performance CMOS line scan image sensors mounted on a prism block. During exposure, the incoming light is converted to electrons (electric charge) in the photodiodes (active pixels). The transfer gate controls the transfer of charge from photodiodes to the shift register.
  • Page 16 (the inverse of line rate). This also allows a fixed exposure time, independent of the line rate. In the LQ-401CL the exposure time can be set individually for all four channels.

  • Page 17: Key Functions

    LQ-401CL Key functions Important note: LQ-400CL has many functions explained in this chapter. In order to use these functions properly and to get proper image, please follow the procedure described below. Setting procedure: 1. Set the shutter and line rate 2.

  • Page 18: External Trigger

    LQ-401CL 6.2.3 External Trigger The external trigger can be input through the 12-pin connector or Camera Link CC1. These cannot be used at the same time. The external trigger signal can be terminated by 75 ohms inside the camera (Refer to Chapter 4.2).

  • Page 19: Gain Control

    LQ-401CL Gain white balance Calculates the difference between green and red video levels, and green and blue levels, and adjusts the red and blue channels’ video level so that the video level of all three channels becomes equal. Command WB=0...
  • Page 20 LQ-401CL Analog Gain = LOW Analog Gain = HIGH Master Blue +6dB +20dB Master Blue +6dB +14dB +6dB -4dB +8dB +6dB +6dB -4dB +4dB +2dB -4dB -4dB Fig.13 Master gain mode with Gain Low and High 2. Individual gain mode...

  • Page 21: Black Level

    LQ-401CL 6.2.6 Black level The setup level of the LQ-400CL is set at 8LSB in 4 x 8-bit output mode as the factory default setting (32LSB for 4 x 10-bit output mode) In order to adjust, the following commands are available.

  • Page 22: Dsnu (Dark Signal Non-Uniformity) Correction

    LQ-401CL After correction: flat response from pixel to pixel Average Fig.16 Conceptual drawing for PRNU correction (2) 6.2.8 DSNU (Dark Signal Non-Uniformity) correction DSNU (Dark Signal Non-Uniformity) is, as the name implies, a non-uniformity of offset level of each pixel, which is not dependent on the incoming light.
  • Page 23 LQ-401CL Shading caused by uneven illumination or transmission at the edges of the lens. Pixel response non-uniformity will be superimposed on the output signal Fig.19 Shading correction The shading correction has two ways to compensate, flat shading correction and color shading correction.

  • Page 24: Lateral Chromatic Aberration

    LQ-401CL Color shading correction (SDR=1): Color shading correction compensates red, blue and NIR signals to match with green signal characteristics. The camera does not store the reference data for color shading. Fig.21 Color shading correction concept drawing Note:  For this function, no reference value is stored in the camera.
  • Page 25 LQ-401CL The following screen is used for creating up to three user-defined sets of lateral chromatic aberration data in the camera control tool. Fig. 22 Setting screen for lateral chromatic aberration Setting procedure: Please use the following steps. 1. Chromatic Aberration Enable 2.
  • Page 26 LQ-401CL L3 says to shift 3 pixels to the left and R3 says to shift 3 pixels to the right. In case of Red, CABLR=[User Lens],[Shift value] In case of Blue, CABLB=[User Lens],[Shift value] In case of NIR, CABLIR=[User Lens],[Shift value] The range of the shift value is -3 to +3.

  • Page 27: Aperture Filter

    LQ-401CL Setting example: Left side = -3 or 3 Area : 6, 2nd : 4, 3rd : 2 4096th Pixel Fig. 24 Setting example Note: 1) If left side pixel is set at -2 or +2, only Area and 2nd can be configured.

  • Page 28: Sub-Sampling

    LQ-401CL 6.2.14 Sub-sampling In this mode, every two effective pixels are read out. Accordingly, the read out rate is doubled. The FOV (Field Of View) is not changed versus full scan mode but the resolution becomes half. 4 0 8 9...

  • Page 29: Operation Modes

    LQ-401CL Gray 1 890( 222) Si gnal （RGB） 32( 8) DVAL ０ 4095 Fig.29 Gradation test pattern Gray 2 890( 222) Si gnal （RGB 32( 8) 16 16 16 16 16 16 16 16 16 16 16 16 ・・・ 16 16 16 16...

  • Page 30: Camera Default Settings

    LQ-401CL 6.3.1 Camera Default Settings The following table shows the default settings of LQ-401CL Item Default setting Value Gain Master mode B/G/R/NIR Black Master mode B/G/R/NIR 8LSB Trigger Mode No-shutter Trigger Origin Internal Auto Reset Mode Input Camera Link Polarity...
  • Page 31 LQ-401CL 450clk LVAL 610clk 16clk 4096clk 16clk DVAL AP4095 Data Fig.32 No-Shutter / Internal Trigger mode 450clk 610clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Fig.33 No-Shutter mode / Binning/ Internal...

  • Page 32: Shutter Mode With External Trigger

    LQ-401CL 450clk 610clk LVAL 16clk 2048clk 16clk DVAL AP2047 Data Fig.34 No-Shutter /Sub-sampling and Window/ Internal 6.3.3 No-Shutter mode with external trigger In this mode, the accumulation and readout is activated by an external trigger pulse. The exposure period depends on the trigger interval and if the trigger interval becomes longer, the sensitivity is increased.
  • Page 33 LQ-401CL 179clk 653clk 790clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Fig. 35 No-Shutter mode with external trigger 179clk 450clk 790clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Fig. 36 No-Shutter mode /Binning/ External...

  • Page 34: Shutter-Select Mode With Internal Trigger

    LQ-401CL 179clk 450clk 610clk LVAL 16clk 2048clk 16clk DVAL AP2047 Data Fig.37 No-Shutter mode /Sub-sampling and Window/ External 6.3.4 Shutter-Select mode with internal trigger In this mode, the exposure and readout is activated by the trigger pulse generated internally. As the accumulation control is done by the internal counter, the accumulation is not affected by the trigger jitter.
  • Page 35 LQ-401CL * Note Exposure R Exposure G Exposure B Exposure NIR 610clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Note: EEN uses channel with the largest exposure value Fig.38 Shutter-Select mode / Internal...
  • Page 36 LQ-401CL * Note Exposure R Exposure G Exposure B Exposure NIR 610clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Note: EEN uses channel with the largest exposure value Fig. 39 Shutter-Select mode / Binning /Internal...

  • Page 37: Shutter-Select Mode With External Trigger

    LQ-401CL * Note Exposure R Exposure G Exposure B Exposure NIR 610clk LVAL 16clk 2048clk 16clk DVAL AP2047 Data Note: EEN uses channel with the largest exposure value Fig.40 Shutter–Select mode/Sub-sampling and Window/ Internal 6.3.5 Shutter-Select mode with external trigger In this mode, the exposure and readout is activated by the external trigger pulse.
  • Page 38 LQ-401CL  The minimum trigger pulse width Trigger input via Minimum trigger pulse width Camera link 500 ns Hirose 12-pin 5 µs  For one-push white balance, both shutter gain (AH) and gain (AW) are effective. 153clk * Note Exposure R...
  • Page 39 LQ-401CL 156clk * Note Exposure R Exposure G Exposure B Exposure NIR 610clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Note: EEN uses channel with the largest exposure value Fig.42 Shutter-Select mode /Binning /External...

  • Page 40: Pulse Width Control (Pwc) Mode

    LQ-401CL 156clk * Note Exposure R Exposure G Exposure B Exposure NIR 610clk LVAL 16clk 2048clk 16clk DVAL AP2047 Data Note: EEN uses channel with the largest exposure value Fig.43 Shutter-Select /Sub-sampling and Window/ External 6.3.6 Pulse Width Control (PWC) mode In this mode, the exposure time and readout are activated by the external trigger pulse.
  • Page 41 LQ-401CL 154clk 154clk 610clk LVAL 16clk 4096clk 16clk DVAL AP4095 Data Fig. 44 Pulse Width Control mode 154clk 154clk 610clk LVAL 16clk 4096clk 8clk 16clk DVAL AP4095 Data Fig.45 PWC mode /Binning...

  • Page 42: The Minimum Interval Of The External Trigger

    LQ-401CL 154clk 154clk 610clk LVAL 16clk 2048clk 16clk DVAL AP2047 Data Fig.46 PWC mode /Sub-sampling and Window 6.3.7 The minimum interval of the external trigger Full resolution / Binning Minimum interval (μs） No-Shutter Camera Link 54.8 Hirose 12pin 59.3 Shutter-Select Camera Link 54.8...

  • Page 43: Compatibility Of Trigger Modes And Functions

    LQ-401CL 6.3.9 Compatibility of trigger modes and functions Trigger Image output format Gain Offset Full Binnin Windowin Master Master Individua Mode Origin Individual resolution sampling Tracking tracking Internal No-shutter ◎ ◎ ◎ ◎ ◎ ◎ ◎ ◎ Externa Internal Shutter-Selec ◎...

  • Page 44: Functions Listed Alphabetically By Command Acronyms

    LQ-401CL Functions listed alphabetically by command acronyms The following is not a complete list. Please refer to Chapter 8, Serial Communication and Command List, for the details. Command AHRS – Request Status After One-Push AWB This command returns the status of the one-push AWB function, with the following parameters:...
  • Page 45 LQ-401CL In Shutter Select mode, when the first trigger is input, the camera is exposed during setting exposure time and the video is output regardless of the setting of Auto Reset Mode. The following shows the timing. Auto Reset OFF t >...

  • Page 46: Command Ah - Activate One-Push Auto White Balance (Awb) - Shutter

    LQ-401CL 2. If the trigger interval is longer than 52 ms 52ms Ext Trigger Int Trigger Sensor EEN ① ② LVAL ① ② 3. If the external trigger timing happens to be the same as the internal trigger timing, the internal trigger is generated again as shown below. In this case, jitter may occur.

  • Page 47: Command Aw - Activate One-Push Auto White Balance (Awb) - Gain

    LQ-401CL Command AW – Activate One-Push Auto White Balance (AWB) - Gain By sending this command via the serial communication, the gain based One-Push AWB function is activated. This function can also be initiated by pressing the rear panel button. The white balance function takes approximately 3 seconds to complete.

  • Page 48: Commands Blr, Blb And Blir - Black Level Red, Blue And Nir

    LQ-401CL Individual Settings: G ch: 0 to 64 Associated functions: Commands BLR, BLB, BLIR 7.10 Commands BLR, BLB and BLIR – Black Level Red, Blue and NIR In conjunction with Command BL, these commands allow individual setting of the black level in all channels.

  • Page 49: Command Ga - Master Gain Level

    LQ-401CL 7.14 Command GA – Master Gain Level This function is a global gain adjustment for all channels. There are two ways to adjust gain: one is “Master Tracking” and the other is “Individual”. Command GM selects a required mode. The gain setting is done in the analog domain where 1LSB equals 0.01dB.

  • Page 50: Command Mav - Chromatic Aberration Control

    LQ-401CL Associated functions: Trigger origin, TG=0 Applicable modes: No-shutter with internal trigger (TR=0) Shutter-Select with internal trigger (TR=1) Note  The data can be stored in the camera memory for next start up. 7.19 Command MAV – Chromatic Aberration Control This command enables or disables chromatic aberration adjustment for each channel.

  • Page 51: Command Pbr - Run Pixel Black Correction And Store To User Area

    LQ-401CL 7.23 Command PBR – Run Pixel Black Correction and Store to User Area This command initiates the “pixel black level” correction function, and stores the settings in the user area. When this function is activated, lens must be capped.

  • Page 52: Command Pgr - Pixel Gain Correction And Store In User Area

    LQ-401CL 7.27 Command PGR – Pixel Gain Correction and Store in User Area This command initiates the pixel gain correction function, and stores the settings in the user area. Settings: 0= activate automatic process Associated functions: Command PGC must be set to 2 Note: ...

  • Page 53: Command Sds - Request Status After Executing Shading Correction Command

    LQ-401CL 7.32 Command SDS – Request Status After Executing Shading Correction Command This command returns the status of the shading correction function, with the following parameters: 0=Not completed yet 1=Succeeded 2=Error1: Image too bright 3=Error2: Image too dark 4=Error3: Timeout occurred 7.33...

  • Page 54: Command Tr - Trigger Mode

    LQ-401CL 7.38 Command TR – Trigger Mode Selects the trigger mode of the camera. Depending on the mode used, it allows the scan rate to either be programmed by an internal timing generator or by and external trigger pulse. See chapter 6 for details on the operation modes.

  • Page 55: Serial Communication And Command List

    8.1. Serial communication The LQ-401CL can communicate by serial communication via the Camera Link connector or via RS232C in the 12-pin Hirose connector. The Baud Rate is fixed at 9600 bps. Switch SW1 at the rear panel of the camera is used to select which way the serial communication is set up.

  • Page 56: Command List

    LQ-401CL Transmit the request command to camera: The status of the camera's settings can be queried by transmitting NN?<CR><LF>, where NN is any one of the commands. The camera will return the current setting data. e.g. Send to camera: TR? <CR><LF>...
  • Page 57 LQ-401CL with G Full resolution PER=[Param.]<CR><LF Programmable Sub-sampling/Windowing > Only valid for TR=1 840 to 1194752 clocks Exposure - Red PER?<CR><LF> - 1 clock is 11.9 ns Full resolution Programmable PEG=[Param.]<CR><LF Sub-sampling/Windowing Exposure > Only valid for TR=1 840 to 1194752 clocks Green PEG?<CR><LF>...
  • Page 58 LQ-401CL SRO＝［Param.］ 0=off SRO Sensor read <CR><LF> 1=Sub-sampling SRO？<CR><LF> 2=Windowing E - Gain, white balance and signal settings Master Tracking Mode Gain Level - GA=[Param.]<CR><LF> 0 to 802 Master GA?<CR><LF> Individual -402 to 1404 Master Tracking Mode Gain Level - GAR=[Param.]<CR><LF>...
  • Page 59 LQ-401CL too bright. 3=Error2. Green image was too dark. 4=Error3. Timeout-error occurred. Noise NR=[Param.]<CR><LF> 0 = OFF, 1= ON reduction F - Shading correction, pixel gain and pixel black correction Select shading 0=Off (Bypass) SDC=[Param.]<CR><LF> correction 1=Factory area SDC?<CR><LF> mode...
  • Page 60 LQ-401CL 0=Pixel black correction has Inquire the not been finished yet. status after PBS?<CR><LF> 1=Succeeded. pixel black 2=Error1 - Timeout error correction occurred. 0：1～5m SCB=[Param.]<CR><LF> Select Cable 0 to 2 1：5～10m SCB?<CR><LF> 2：10～15m Chromatic MAVCG=[Param1]<CR><L 0=User1 Lens MAVC Available when MAV=1 aberration F>...
  • Page 61 LQ-401CL aberration 2]<CR><LF> Param2:1 to 8 the value set in MAVCG Area No. Blue CABAB?[Param1]<CR><LF > CABAIR=[Param1],[Para Chromatic VABAI m2]<CR><LF> Param1:User No. 0 to 2 Param1：Correspond to aberration CABAIR?[Param1]<CR><L Param2:1 to 8 the value set in MAVCG Area No. NIR F>...

  • Page 62: Camera Control Tool For Lq-401Cl

    LQ-401CL Camera Control Tool for LQ-401CL From www.jai.com Camera Control Tool for Windows XP/Vista/7 can be downloaded. 9.1. Software Install Execute LQ-401CL_Ver.XXX.exe in the downloaded file. The setup program starts and continues according to the screen instructions. 9.2. Open the Control Tool Connect the camera to the PC on which the software is installed and set the power ON.

  • Page 63: Camera Control Window

    LQ-401CL 9.4. Camera control window When the connection between camera and PC is completed, the camera control tool shows the current camera settings. 9.5 Menus 9.5.1 File menu Open: Transfer the setting parameters in HDD or other memory devices to the camera.

  • Page 64: Line Correction Menu

    LQ-401CL 9.5.3 Line Correction menu The following windows are for Pixel Black, Pixel Gain and Shading adjustments. 9.5.4 Help menu Display camera software version, model name, firmware version and camera ID.

  • Page 65: External Appearance And Dimensions

    LQ-401CL External appearance and Dimensions Outside dimensions tolerance: ± 0.3mm Fig.49 External Appearance and Dimensions (M52 mount)
  • Page 66 LQ-401CL Outside dimensions tolerance: ± 0.3mm Fig.50 External Appearance and Dimensions (F mount)

  • Page 67: Specifications

    LQ-401CL Specifications 11.1 Typical data Scanning system Line Scan Effective pixels : 4096 pixels Image Sensor Pixel Size : 7.0 μm × 7.0 μm Effective image length : 28.672 mm Pixel clock 84.00 MHz Full Total number of pixels per line: 4602 clocks resolution Line rate: 54.79 μs (No-shutter mode with internal trigger)
  • Page 68 LQ-401CL Binning Available (line rate is not increased) Test pattern 0: Color Bar 1: Gray 1 2: Gray 2 3: White (890 LSB) 1. Pixel gain correction: Pixel Response Non Uniformity(PRNU),Dark Signal Non Uniformity(DSNU) 2. Shading compensation : ON / OFF...

  • Page 69: Camera Spectral Sensitivity

    Note 2: 12P input and Camera Link input cannot be used at the same time. Note 3: 12P input and Camera Link input cannot be used at the same time. 11.2 Camera Spectral sensitivity LQ-401CL CAMERA Sensitivity NIRch 1000 wavelength (nm)

  • Page 70: Appendix

    LQ-401CL Appendix Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera.

  • Page 71: Caution When Mounting The Camera

    Mounting the camera to fixing plate Exportation When exporting this product, please follow the export regulation of your own country. References 1. This manual and datasheet for the LQ-401CL can be downloaded from www.jai.com 2. Camera control software can be downloaded from www.jai.com...

  • Page 72: Change History

    LQ-401CL Change history Date Revision Changes Nov. 2014 New Release Nov. 2014 Correct the range of black level adjustment Dec. 2014 Correct default setting for PBC, PGC and SDC...

  • Page 73: User's Record

    LQ-401CL User's Record Camera type: LQ-401CL Revision: …………….. Serial No. …………….. Firmware version. …………….. For camera revision history, please contact your local JAI distributor. User's Mode Settings. User's Modifications. Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners.
