CONNECTING THE SOLAR PAl'.EL: WARNIM.:
Mount the 4 brackets on the solar panel with the 8
screws provided.
Step 2 shows the results of Step I, the fully assembled
solar panel;
Mount the solar panel onto the roof with the 4 screws
and 4 lock washers pre-attached (provided). Secure
the solar panel to the roof in the selected location.
Use the wire clips to secure the wire to the roof or
inside of the attic. If you run the wiring through the
interior of the attic to connect to a device such as a
gable mounted attic fan, drill a hole in the immediate
vicinity of the panel but underneath one of the shin­
gles. Remember to use caulking to seal the hole once
the wiring has been secured to the interior of the
attic.
Solar panels generate electricity \',,hen i.:'\posed ln
any light -;ource; electrical shock :ind burns c:rn
result from direct contact with the p::int:l krminals.
Cover the panel surface with an opJyue m�1terial
bdOre handling the electrical connections to th-:
panel. Addition�d hazJrds �.xist whi.::nevcr the pani.: / s;
are wet. Multiple solar pnnels may bl.'.
crease the power/output on both the roof rnnt1nr :rnd
gable attic vents.
