Colour Television
Contents
1. Revision List
2. Technical Specs, Diversity, and Connections
3. Precautions, Notes, and Abbreviation List
11. Styling Sheets
6601 series 50"
6601 series 55"
Published by CQZ/SC 1627 Quality
©
2016
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
2
5
9
9
10
22
24
31
35
Drawing PWB
36
40-41
42
46-47
48
63-64
65
66
67
68
69
70
Printed in the Netherlands
Chassis
QM16.1L
Page
Subject to modification
EN 3122 785 20160
LA
