CMP-WNAP10
Wireless Access Point
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMP-WNAP10 and is the answer not in the manual?

Questions and answers

Related Manuals for Konig CMP-WNAP10

Summary of Contents for Konig CMP-WNAP10

  • Page 1 CMP-WNAP10 Wireless Access Point MANUAL...
  • Page 2 CE Declaration of Conformity For the following equipment: CMP-WNAP10 Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low-voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive 99/5/EC and 89/3360EEC.
  • Page 3 EN 60950-1: 2001  EN 55022: 1998 + A1: 2000 + A2: 2003  EN61000-3-2:2001  EN61000-3-3:2001  EN 55024: 1998 +A1: 2001 + A2: 2003  European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range 2.400-2.4835GHz; In France, the equipment must be restricted to the 2.4465-2.4835GHz frequency range and must be restricted to indoor use.

  • Page 4: Table Of Contents

    Package contents ........................4 Chapter 1: About this Guide ....................5 1.1 Purposes.........................5 1.2 Conventions......................5 1.3 Overview of this User Guide...................5 Chapter 2: Introduction ......................6 2.1 Overview of the AP ....................6 2.2 Features........................6 2.3 Panel Layout......................7 2.3.1 The Front Panel....................7 2.3.2 The Rear Panel ....................7 Chapter 3: Connecting the AP .....................9 3.1 System Requirements ....................9 3.2 Installation Environment Requirements ..............9...

  • Page 5: Package Contents

    Package contents The following contents should be found in your box: One CMP-WNAP10 54Mbps Wireless Access Point  One AC power Adapter for CMP-WNAP10 54Mbps Wireless Access Point  One Resource CD for CMP-WNAP10 54Mbps Wireless Access Point, including: ...

  • Page 6: Chapter 1: About This Guide

    AP, please look through this guide to get to know all the AP’s functions. 1.1 Purposes This Guide tells you how to use the CMP-WNAP10 54Mbps Wireless Access Point. 1.2 Conventions The AP mentioned in this guide stands for CMP-WNAP10 54Mbps Wireless Access Point.

  • Page 7: Chapter 2: Introduction

    Chapter 2: Introduction 2.1 Overview of the AP The CMP-WNAP10 54Mbps Wireless Access Point is the basic building block of a wireless LAN infrastructure. It provides connectivity between Ethernet wired networks and radio-equipped wireless notebook systems, desktop systems, print servers, and other devices.

  • Page 8: Panel Layout

    2.3 Panel Layout 2.3.1 The Front Panel Viewed from left to right, as shown in figure 2-1, the front panel of the CMP-WNAP10 consists of four LEDs, which is designed to indicate connections. Table 2-1 describes the LEDs on the front panel of the AP.
  • Page 9 CMP-WNAP10 54M Wireless Access Point User Guide Figure 2-2: Rear Panel sketch - 8 -...

  • Page 10: Chapter 3: Connecting The Ap

    Adjust the direction of the antenna. Normally, upright is a good direction. Connect the Ethernet Broadband Router to the CMP-WNAP10 AP. Power on the AP. If you are connecting a desktop PC or laptop to your network, install the KÖNIG Wireless Adapter on the PC.
  • Page 11 CMP-WNAP10 54M Wireless Access Point User Guide Figure 3-1 The Example of Infrastructure Network Incorporating the CMP-WNAP10 - 10 -...

  • Page 12: Chapter 4: Tcp/Ip Configuration

    54M Wireless Access Point User Guide Chapter 4: TCP/IP Configuration After connecting the CMP-WNAP10 AP into your network, you should configure it. The default IP address of the CMP-WNAP10 54Mbps Wireless Access Point is 192.168.1.1, and the default Subnet Mask is 255.255.255.0. These values can be seen from the LAN.
  • Page 13 CMP-WNAP10 54M Wireless Access Point User Guide Figure 4-2: Failed result of Ping command If the result displayed is similar to that shown in figure 4-2, it means that your PC has not connected to the AP. Please check it following these steps: Is the connection between your PC and the AP correct? Note: The LED of LAN port on the AP and LED on your PC's adapter should be lit.

  • Page 14: Chapter 5: Configuring The Ap

    5.1 login ® With a Web-based (Internet Explorer or Netscape Navigator) utility, the CMP-WNAP10 54Mbps Wireless Access Point is easy to configure and manage. The Web-based utility can be used on any Windows, Macintosh or UNIX OS with a web browser.

  • Page 15: Network

    CMP-WNAP10 54M Wireless Access Point User Guide read-only. Network This field displays the current settings or information for the Network, including the MAC address, IP address and Subnet Mask. Wireless This field displays basic information or status for wireless function, including Operating Mode, SSID, Channel, Mode, MAC Address and IP Address.

  • Page 16: Wireless

    CMP-WNAP10 54M Wireless Access Point User Guide MAC Address - the physical address of the AP, as seen from the LAN. The value  can't be changed. IP Address - Enter the IP address of your AP in dotted-decimal notation (factory ...
  • Page 17 CMP-WNAP10 54M Wireless Access Point User Guide Figure 5-6: Wireless Settings Channel - This field determines which operating frequency will be used. It is not  necessary to change the wireless channel unless you notice interference problems with another nearby access point.
  • Page 18 MAC of AP. Here is an example of how to configure wireless repeater. Please do the following: Configure the Operating Mode of the CMP-WNAP10 Access Points.  Configure AP1 on LAN Segment 1 in Access Point mode.
  • Page 19 Configure the CMP-WNAP10 (AP1) on LAN Segment 1 in Point-to-Point Bridge mode. Configure the CMP-WNAP10 (AP2) on LAN Segment 2 in Point-to-Point Bridge mode. AP1 must have AP2’s MAC address in its MAC Address field and AP2 must have AP1’s MAC address in its MAC Address field.
  • Page 20 LAN segments.  Wireless stations will not be able to connect to the CMP-WNAP10 Access Points in the illustration above. If you require wireless stations to access any lan segment, you can add CMP-WNAP10 Access Points configured in Wireless Access Point mode to any LAN segment.

  • Page 21: Site Survey

    CMP-WNAP10 54M Wireless Access Point User Guide 5.4.2 Site Survey After selecting a mode and pressing button Survey, you can view all of APs around you. Figure 5-10: Site Survey  SSID - The SSID of the AP.  BSSID - The BSSID of the AP, usually also the MAC address of the AP.
  • Page 22 CMP-WNAP10 54M Wireless Access Point User Guide Figure 5-11: Wireless Securities  Disable Security - The wireless security function can be enabled or disabled. If disabled, the wireless stations will be able to connect the AP without encryption. It is recommended strongly that you choose one of following options to enable security.

  • Page 23: Mac Filtering

    CMP-WNAP10 54M Wireless Access Point User Guide 2) For 128-bit encryption - You can enter 26 hexadecimal digits (any combination of 0-9, a-f, A-F, zero key is not permitted) or 13 ASCII characters. 3) For 152-bit encryption - You can enter 32 hexadecimal digits (any combination of 0-9, a-f, A-F, zero key is not permitted) or 16 ASCII characters.
  • Page 24 CMP-WNAP10 54M Wireless Access Point User Guide Figure 5-12: Wireless MAC address Filtering The Wireless MAC Address Filtering feature allows you to control wireless stations accessing the AP, which depend on the station's MAC addresses. MAC Address - The wireless station's MAC address that you want to access.
  • Page 25 CMP-WNAP10 54M Wireless Access Point User Guide 00-0A-EB-B0-00-0B. Enter a simple description of the wireless station in the Description field. For example: Wireless station A. Privilege - Selects the privileges for this entry, one of Allow / Deny / 64-bit / 128-bit / 152-bit.

  • Page 26: Wireless Statistics

    CMP-WNAP10 54M Wireless Access Point User Guide in the Privilege pull-down list, enter 2F34D20BE2E54B326C5476586A in the WEP Key field and select Enabled in the Status pull-down list. Click the Save and the Return button. The filtering rules that configured should be similar to the following list:...

  • Page 27: Dhcp

    CMP-WNAP10 54M Wireless Access Point User Guide 5.5 DHCP Figure 5-16: the DHCP menu There are three submenus under the DHCP menu (shown in figure 5-16): DHCP Settings, DHCP Clients List and Address Reservation. Click any of them, and you will be able to configure the corresponding function.

  • Page 28: Dhcp Clients List

    CMP-WNAP10 54M Wireless Access Point User Guide Primary DNS - (Optional.) Input the DNS IP address provided by your ISP. Or  consult your ISP. Secondary DNS - (Optional.) Input the IP address of another DNS server if your ...

  • Page 29: Wireless Advanced Settings

    CMP-WNAP10 54M Wireless Access Point User Guide Figure 5-19: Address Reservation MAC Address - The MAC address of the PC of which you want to reserve IP  address. Assigned IP Address - The IP address of the AP reserved.

  • Page 30: System Tools

    CMP-WNAP10 54M Wireless Access Point User Guide Figure5-20: AP Wireless Advanced Settings Disable short preamble - Disable short preamble and use long preamble only.  802.11b mode supports only long preamble and this parameter will be ignored.  RTS threshold - RTS/CTS Threshold, the packet size that is used to determine if RTS/CTS should be sent.

  • Page 31: Reboot

    CMP-WNAP10 54M Wireless Access Point User Guide  The default IP Address: 192.168.1.1  The default Subnet Mask: 255.255.255.0 Note: Any settings you have saved will be lost when the default settings are restored. 5.7.2 Reboot This page (shown in figure 5-22) allows you to reboot the AP.

  • Page 32: Log

    CMP-WNAP10 54M Wireless Access Point User Guide Click the Clear All button to clear all. 5.7.5 Log This page (shown in figure 5-24) allows you to query the Logs of the AP. Figure 5-24: System Log The AP can keep logs of all traffic. You can query the logs to find what happened to the Click the Refresh button to refresh the logs.

  • Page 33: Appendix A: Faq

    CMP-WNAP10 54M Wireless Access Point User Guide Appendix A: FAQ No lights are lit on the access point. It takes a few seconds for the power indicator to light up. Wait a minute and check the power light status on the access point.

  • Page 34: Appendix B: Configuring The Pcs

    CMP-WNAP10 54M Wireless Access Point User Guide Appendix B: Configuring the PCs In this section, we’ll introduce how to install and configure the TCP/IP correctly in Windows 95/98. First make sure your Ethernet Adapter is working, refer to the adapter’s manual if needed.
  • Page 35 CMP-WNAP10 54M Wireless Access Point User Guide Network window that appears. An example shown in the following figure: Figure B-3: Configuration tab Click on Properties. The following TCP/IP Properties window will display and the IP Address tab is open on this window by default.
  • Page 36 CMP-WNAP10 54M Wireless Access Point User Guide Figure B-5: Gateway tab Choose Disable DNS on the DNS configuration tab, as shown in the following figure: Figure B-6: DNS Configuration tab  Setting IP address manually Select Specify an IP address on IP Address tab, as shown in the following figure.
  • Page 37 CMP-WNAP10 54M Wireless Access Point User Guide Figure B-7: IP Address tab Type the AP’s LAN IP address (the default IP is 192.168.1.1) into the New gateway field on the Gateway tab, and click on the Add button, as shown...
  • Page 38 CMP-WNAP10 54M Wireless Access Point User Guide click Add button. Shown below: Figure B-9: DNS Configuration tab Now, all the configurations are finished, it will take effect after reboot. - 37 -...

  • Page 39: Appendix C: Specifications

    CMP-WNAP10 54M Wireless Access Point User Guide Appendix C: Specifications General Standards IEEE 802.3, 802.3u, 802.11b and 802.11g Protocols TCP/IP, DHCP Ports One 10/100M Auto-Negotiation LAN RJ45 port supporting Auto MDI/MDIX Cabling Type 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω...

  • Page 40: Appendix D: Glossary

    CMP-WNAP10 54M Wireless Access Point User Guide Appendix D: Glossary 2x to 3x eXtended Range WLAN Transmission Technology - The WLAN device  with 2x to 3x eXtended Range WLAN transmission technology make its sensitivity up to 105 dBm, which gives users the ability to have robust, longer-range wireless connections.
  • Page 41 CMP-WNAP10 54M Wireless Access Point User Guide WEP (Wired Equivalent Privacy) - A data privacy mechanism based on a 64-bit or  128-bit or 152-bit shared key algorithm, as described in the IEEE 802.11 standard. Wi-Fi - A trade name for the 802.11b wireless networking standard, given by the ...
