T A B L E O F C O N T E N T S Contents ................ 2 Components Overview ..........3 Reader ................4 Controller ..............6 Hub................7 Electronic Locks ............8 Cables & Connections ..........11 Power Supply ...............12 SENSEON PLUS INSTA LLATION GUID E...
Supply to Hubs across the length between Hub Programmer allows you Senseon Plus System. cables should one be to program enhanced too short. security configuration and download audit trail data from the Senseon Plus System. SENSEON PLUS INSTA LLATIO N G UI DE...
Reader The Senseon Plus Reader scans user/administrator cards, fobs, or other RFID access credentials. You can mount a Reader in a variety of locations. These include a cabinet's outside surface, subsurface, or a surrounding panel or wall. Determine where you want users to scan cards for access beforehand.
Page 5
Subsurface Mounting You can mount a Senseon Plus Reader underneath a cabinet surface if the surface is not metallic. You may use the center or the edge of a cabinet as a reference for the location. NOTE! Material composition, such as wood or stone, may impact the Reader's signal strength. It's recommended a subsurface-mounted Reader be under a surface 1″...
Controller The Controller is the "brain" of the Senseon Plus System and resides inside the cabinet fixture. One Controller supports up to 10 Hubs You can mount a Controller by screw attachment or adhesive tape (included). The Controller holds audit trail data and system configurations. You have the option to connect a Controller to third-party RFID readers.
The Hub is the “heart” of the Senseon Plus System. Hubs connect to each other, to the locks, to the Power Supply, and the Controller. All connected Hubs distribute power and unlock signals amongst each other. A Senseon Plus Controller supports up to ten Hubs. You can mount a Hub by screw attachment or adhesive tape (included).
Electronic Locks Senseon Plus electronic locks (e-locks) secure or unlock openings via an electronic signal from the Hub. A built-in sensor monitors the status of a connected opening. The e-lock reports status, defined as “secure” or “unsecure,” to the Controller. Senseon Plus systems use B-model e-locks which are designed specifically for Senseon Plus systems.
Page 9
3 1/2" MIN (76 mm) MOUNTING (89 mm) BLOCK An example of a Senseon Plus standalone 10EL An example of a Senseon Plus standalone 10EL SURFACE MOUNTED on a horizontal partition SURFACE-MOUNTED mounted within a FACE within a FRAMELESS cabinet.
Page 10
(19.1 mm) SIDE VIEW An example of a Senseon standalone e-lock An example of a Senseon standalone e-lock mounted HORIZONTALLY AND BELOW a mounted HORIZONTALLY AND ABOVE a drawer front. drawer front. SENSEON PLUS IN STALLATIO N G UI DE...
Set channel to "1" with the provided To Controller screwdriver. or Hub To E-Lock To E-Lock To Power or Lock or Lock Supply Terminator Terminator Adapter or Cable connection points for Hub SENSEON PLUS IN STALLATIO N G UI DE...
Power Supply TOE KICK AREA An example of placement for a Senseon Plus Power Supply and Adapter in relation to the Hub. The Power Supply can be mounted on any surface of the cabinet. The example shows the Power Supply mounted beneath the bottom panel of the cabinet.
Page 13
Senseon Plus hole placement for a clips. Hub mounted vertically onto the Senseon Plus Hub mounted rear of a cabinet. horizontally (flat) onto a cabinet partition. SENSEON PLUS IN STALLATIO N G UI DE...
