bravour SECURO Manual

S E C U R O F I X I N G T H E R U B B E R S
A 4x Soft cubes B 4x Soft squares
1 Take the rear part of the enclosure
2 Remove the protective film and position the 4 self adhesive soft squares in
the corners, just within the square hole pattern of the enclosure.
3 Place tablet on top of the squares and position in the center, use a ruler or
the square holes pattern to align.
4 Place the front part of the enclosure upside down under and check the
position noting home button and camera.
Optional: If you have a tablet that is smaller than the opening in the front
part of the enclosure, position the Passe Partout evenly aligned on top of
your tablet
5 Place the cubes on each side of the tablet, do not press firmly yet.
6 Place front part in the correct way and check if the position is correct.
7 Alter the cubes' position and/or press them firmly to fixate.
F O R 7 " - 8 " E N C L O S U R E S
c 1x Passe Partout
1
3
5
7
2
4
6
