Philips HTS3564 Series Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. Turntable
  5. HTS3564
  6. Service manual

Philips HTS3564 Series Service Manual

Home theater bd player
Hide thumbs Also See for HTS3564 Series:

Advertisement

Quick Links

Download this manual
Home Theater BD Player
Service
Service Manual
. Location of PCB Boards&Version Variation&Repair Scenario Matrix..........1-2
. Technical Specifications.........................................................1- 3
. Safety Instruction, Warning & Notes........................................1- 4
. DFU Instruction..............................................................................2-1
. Mechanical and Dismantling Instructions....................................3-1
. Software Upgrades .......................................................................
. Change settings...........................................................................4-2
. Trouble Shooting Chart......................................................
. Wiring Diagram..................................................................6-1
. Electrical Diagrams and Print-layouts......................................7-1
. Set Mechanical Exploded view & Part list................................8-1
. Revision List..................................................................................9-1
©Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by Stephen&Arya- 1238 BU AVM Printed in The Netherlands Subject to modification
Version 1.2

TABLE OF CONTENTS

HTS3564/78/F7/94
Page
4-1
.
5-1
.
CLASS 1
LASER PRODUCT
GB
3139 785 36162
PHILIPS

Advertisement

loading

Related Manuals for Philips HTS3564 Series

Summary of Contents for Philips HTS3564 Series

  • Page 1: Table Of Contents

    . Electrical Diagrams and Print-layouts..….…………………..….…7-1 . Set Mechanical Exploded view & Part list.…………………..….….8-1 . Revision List..................9-1 ©Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands CLASS 1 All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or...
  • Page 2 PCB BOARD LOCATION: AMPLIFIER BOARD MAIN BOARD POWER BOARD LOADER FRONT CONTROL BOARD VERSION VARIATIONS Type / Versions HTS3564 Service Police Board in used MAIN BOARD FRONT BOARD POWER BOARD AMPLIFIER BOARD LOADER C -- Component Lever Repair Tips M -- Module Lever Repair X -- Used...
  • Page 3 Video Product Specifications: • Signal system: PAL / NTSC • HDMI output: 480i/576i, 480p/576p, 720p, 1080i, 1080p, 1080p24 Note Audio • Specifi cations and design are subject to change • S/PDIF Digital audio input: without notice. • Coaxial: IEC 60958-3 •...
  • Page 4 Speakers Center speaker: • Output power: 128 W RMS (10% THD) • Speaker impedance: 4 ohm • System: Full range satellite • Speaker drivers: 1 x 3" full range • Dimensions (WxHxD): 161 x 95 x 92 mm • Weight: 0. Front/Rear speaker: •...

  • Page 5: Safety Instruction, Warning & Notes

    Safety instruction, Warning & Notes Safety instruction 1. General safety 2.Laser safety Safety regulations require that during a repair: This unit employs a laser. Only qualified service personnel . Connect the unit to the mains via an isolation transformer. may remove the cover, or attempt to service this device .
  • Page 6 Warning 1.General 2. Laser . All ICs and many other semiconductors are susceptible to . The use of optical instruments with this product, will increase eye hazard. electrostatic discharges (ESD). Careless handing during repair can reduce life drastically. Make sure that, during .
  • Page 7 Solder Joint...
  • Page 8 - lead free BGA-ICs will be delivered in so-called respected by the workshop during a repair: ‘dry-packaging’ (sealed pack including a silica gel Use only lead-free solder alloy Philips SAC305 with pack) to protect the IC against moisture. After order code 0622 149 00106. If lead-free solder-paste is...
  • Page 9 EN Before using your product, read all accompanying safety information ES Antes de usar el producto, consulte la información de seguridad que se encuentra adjunta PT Antes de usar o produto, leia todas as informações de segurança em anexo HDMI User manual...
  • Page 10 EN Connect the home theater ES Conecte el sistema de cine en casa PT Conectar o Home Theater FRONT FRONT FRONT REAR REAR SUB- FRONT FRONT FRONT WOOFER RIGHT LEFT CENTER RIGHT LEFT WOOFER LEFT RIGHT CENTER REAR REAR LEFT RIGHT FRONT FRONT...
  • Page 11 EN Connect to TV in one of these ways ES Conecte al TV de alguna de las siguientes maneras PT Conecte à TV de uma destas maneiras HDMI ARC HDMI OUT (ARC) HDMI IN (ARC) HDMI + OPTICAL OPTICAL HDMI OUT (ARC) OPTICAL HDMI IN OPTICAL...
  • Page 12 HDMI + COAXIAL COAXIAL HDMI OUT (ARC) DIGITAL IN COAXIAL HDMI IN COAXIAL HDMI + AUDIO L/R AUDIO L/R HDMI OUT (ARC) AUDIO IN HDMI IN AUDIO OUT...
  • Page 13 EN Switch on the home theater ES Encienda el sistema de cine en casa PT Ligar o Home Theater...
  • Page 14 EN Complete the fi rst time setup ES Complete la confi guración inicial PT Fazer a confi guração inicial HDMI HOME THEATER HOME THEATER...
  • Page 15 EN Use your home theater ES Use el sistema de cine en casa PT Usar o Home Theater...
  • Page 16 3.5MM STEREO MUSIC iLINK...
  • Page 18 Your home theater Remote control Congratulations on your purchase, and welcome This section includes an overview of the remote control. Philips offers, register your product at www.philips.com/welcome. Main unit This section includes an overview of the main unit. Disc compartment...
  • Page 19 2-11 (Standby-On) Switch the home theater on or to standby. OPTIONS When EasyLink is enabled, press and hold for Access more play options while playing a at least three seconds to switch all connected disc or a USB storage device. HDMI CEC compliant devices to standby.

  • Page 20: Mechanical And Dismantling Instructions

    Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step1: Remove 6 screws around the Top Cover, and then remove the Top Cover (Figure 1). Figure 1 Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first.
  • Page 21 Mechanical and Dismantling Instructions Detailed information please refer to the model set. Dismantling Instruction :Dismantle Front Panel, disconnect the connectors (XP6 XPP604 ,XP9), need release 2 snaps of Front Panel & 2 snaps Step3 of bottom cabinet , then gently pull the Panel out from the set. (Figure 3 6) Figure 3 Step4 : Dismantle Front Control Board,remove 5 screws (Figure 4...
  • Page 22 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. : Dismantle Main Board, first disconnect 3 connector (XP13, XP35,XP1), and then remove 5 screws. (Figure 5/6) Step6 : Dismantle Power Board, disconnect the connectors (CN501,CN502,CON502,CN503) then remove 4 screws.(Figure 5/6) Step7 ),and then remove 5 screws...

  • Page 23: Software Upgrades

    Software upgrade Software upgrade method: 1.Copy the bin file as "HTS3564_XX.bin". 2.Then use the file to burn the upgrade CD-R/CD-RW. 3.Put the CD in the tray ,let the player loading the disc. 4.If the CD is correct ,it will display the Upgrade Menu ,press the PLAY key on the remote control to start upgrade 5.Afer a while, the tray will open automatically ,but must not power off the player.

  • Page 24: Trouble Shooting Chart

    Trouble shooting Chart VFD No display on Front Control Board VFD No display on Front Control Board Check every supply voltage on Main Board whether normal or not. Refer to XP501 on Power Board (XP8 PIN4:-24V, PIN6: +5V, PIN5: 12V) Check voltage -24V, +5V,+12V on Power Fix the connection XP2 on Front Board at CN502 position and Front Control...
  • Page 25 Trouble shooting Chart keys do not work keys do not work Check voltage +5V on Front Board U135 Fix the connection XP2 to XP8 on Main PIN38 Board Check Front Control Board signals at XP2 Pin8 VSCLK, Pin7 VSDA,Pin6 VSTB Replace U4 on Main Board, or replace Main Board Replace U135 on Front Board...
  • Page 26 Trouble shooting Chart Remote control does not work Remote control does not work Check battery of remote control whether exhausted or not. Replace the battery for remote control Check power supply of IR601 on Front Check the +5V net on Front Control Control Board whether normal or not Board to Main Board XP8 XP2 Pin6 :+5V...
  • Page 27 Trouble shooting Chart No audio output No audio output Check voltage +34.5V (34V for HTS3564) Check XP13 Pin 14&16 3.3V on Main Board whether normal or not (41V for HTS3251) for whether normal or not at on Amplifier Board Refer to XP501 on Power Board Check the 24Pin FFC connection XP13 on Main Board and XP702 on Amplifier Board...
  • Page 28 Trouble shooting Chart No video output No video output Check L452, R616 whether right on Main Add L452, R616 Board Check the video signal whether right at U7: PIN B18 or R615 Replace Main IC or Main Board...
  • Page 29 Trouble shooting Chart Can’t read disc or can’t open the disk door Can’t read disc or can’t open the disk door Check loader work normally or not Check XP7 on Main Board Check 45Pin, 8Pin, 4Pin cable from Main Board to Loader connect right or Fix 45Pin, 8Pin, 4Pin cable Replace Loader...
  • Page 30 Trouble shooting Chart Tuner FM does not work Tuner FM does not work Check voltage at Q28 C electrode (+5V) on Main Board whether normal Refer to Power Board XP501 or not Check voltage +3.3V Tuner module (TUN1 Pin8) whether right or Check Main Board tuner power supply circuit.
  • Page 31 Trouble shooting Chart AUX in does not work AUX in does not work Check voltage at U27 PIN16:12V on Main Board whether normal or not Refer to Power Board XP501 Check Main Board U27 Pin4, Pin11 signal input whether right or not Check AUX IN connector Check 74HC4052...
  • Page 32 Trouble shooting Chart MP3 Link does not work MP3 Link does not work Check signal XS605 PIN3:MP3_R PIN1:MP3_L ON front board whether normal or Refer to Main Board XP604 Check Main Board U18 74HC4052 PIN2, Check Main Board C358, C349, R340, PIN15 L/R signal input right or not R457, Check voltage at U18 74HC4052...
  • Page 33 5-10 Trouble shooting Chart COAX in does not work COAX in does not work Check voltage at U27 PIN6/PIN23:3.3V on Main Board whether normal or not Refer to Power Board XP501 Check Main Board U27 CS8416 PIN2 input signal whether normal or not Check Main Board C360,L11 Check U27 CS8416 whether broken.
  • Page 34 5-11 Trouble shooting Chart Karaoke in does not work Karaoke in does not work Check signal at XS605 PIN5: MIC_in signal from front board normal or not Refer to Main Board XP604 Check Main Board U18 74HC4052 PIN5, PIN14 L/R signal input right or not Check the cable between XP604 and XS605 Check U18 74HC4052 whether broken Check Main Board U26...
  • Page 35 5-12 Trouble shooting Chart Network in does not work Network in does not work P1 Pin2, Pin3, Pin5, Pin6 from Check netting twine link Check normal or netting twine normal or not Replace P1...
  • Page 37 R161 R161 2.2K 2.2K R150 R150 2.2K 2.2K R149 R149 2.2K 2.2K...
  • Page 42 C314 NC/0.1uF/16V/Y5V C314 NC/0.1uF/16V/Y5V C328 0.47uF/25V/Y5V C328 0.47uF/25V/Y5V...
  • Page 47 C203 27pF/50V/NP0 C203 27pF/50V/NP0 C204 27pF/50V/NP0 C204 27pF/50V/NP0 C201 27pF/50V/NP0 C201 27pF/50V/NP0 C516 0.1uF/50V/Y5V C516 0.1uF/50V/Y5V C517 0.1uF/16V/Y5V C517 0.1uF/16V/Y5V C515 0.1uF/16V/Y5V C515 0.1uF/16V/Y5V C199 27pF/50V/NP0 C199 27pF/50V/NP0...
  • Page 50 C222 100pF/50V/NP0 C222 100pF/50V/NP0 C207 100pF/50V/NP0 C207 100pF/50V/NP0 C206 100pF/50V/NP0 C206 100pF/50V/NP0 C205 100pF/50V/NP0 C205 100pF/50V/NP0 C212 100pF/50V/NP0 C212 100pF/50V/NP0 C211 100pF/50V/NP0 C211 100pF/50V/NP0 C210 100pF/50V/NP0 C210 100pF/50V/NP0 C209 100pF/50V/NP0 C209 100pF/50V/NP0...
  • Page 58 EXPLODED VIEW FOR HTS3564/78/F7/94:...

  • Page 59: Revision List

    REVISION LIST Version 1.0 * Initial release for HTS3564/78 Version 1.1 * Initial release for HTS3564/F7 Version 1.2 * Initial release for HTS3564/94...
