EF70-300mm F4-5.6 IS USM
Instruction

Advertisement

Table of Contents
loading

Related Manuals for Canon EF70-300mm F4-5.6 IS USM

Summary of Contents for Canon EF70-300mm F4-5.6 IS USM

  • Page 1 EF70-300mm F4-5.6 IS USM Instruction...
  • Page 2 Thank you for purchasing a Canon USM lens. Dedicated to EOS cameras, the Canon EF70- 300mm f/4-5.6 IS USM lens is a high- performance telephoto zoom lens equipped with an Image Stabilizer. The Image Stabilizer helps to prevent blurred shots during hand-held shooting at slow shutter speeds.

  • Page 3: Safety Precautions

    a Safety Precautions a Safety Precautions 1. Do not look at the sun or a bright light source through the lens or camera. Doing so could result in loss of vision. Looking at the sun directly through the lens is especially hazardous. 2.
  • Page 4 Nomenclature Image stabilizer mode selector switch (→ 7) Hood mount (→ 5) Filter mounting thread (→ 10) Focusing ring (→ 4) Zoom ring (→ 5) Image stabilizer switch (→ 7) For detailed information, reference page numbers are provided in parentheses (→ **). Zoom position index Focus mode switch (→...

  • Page 5: Focusing Ring

    1. Mounting and Detaching the Lens See your camera’s instructions for details on mounting and detaching the lens. ¡After detaching the lens, place the lens with the rear end up to prevent the lens surface and electrical contacts from getting scratched. ¡If the contacts get soiled, scratched, or have fingerprints on them, corrosion or faulty connections can result.

  • Page 6: Zoom Ring

    3. Hood (Sold separately) The ET-65B hood reduces annoying flare and also protects the front of the lens from rain, snow, dust, etc. To attach the hood, connect the hood’s tabs to the hood attachment tabs on the front end of the lens, then turn the hood clockwise to secure it.

  • Page 7: Zoom Ring Lock Lever

    5. Fixing the Zoom Ring The zoom ring can be fixed at the widest position. This function is convenient for carrying a camera on a strap because it prevents the lens from extending. ENG-6 Turn the zoom ring to the widest position (70mm).
  • Page 8 6. Image Stabilizer You can use the image stabilizer in AF or MF mode. Set the STABILIZER switch to ¡If you are not going to use the image stabilizer function, set the switch to Selecting the Image Stabilizer mode. ¡Use MODE 1 for normal photography.
  • Page 9 7. Tips on Using the Image Stabilizer The image stabilizer is effective particularly for hand-held shots under the following conditions. ● MODE 1 ¡Dimly lit scenes, such as at dusk or indoors ¡Locations such as art galleries or theater stages where flash photography is forbidden ¡Situations in which your footing is uncertain ENG-8 ●...
  • Page 10 Tips on Using the Image Stabilizer ¡The Image Stabilizer cannot compensate for a blurred shot caused by a subject that moved. ¡Set the STABILIZER switch to you are taking pictures using the Bulb setting (long exposures). If the STABILIZER switch is set to image stabilizer function may introduce errors.

  • Page 11: Filter Mounting Thread

    ¡The front end of the lens rotates, so hold it when attaching the filter. ¡Only one filter may be attached. ¡If you need a polarizing filter, use Canon’s PL-C 58mm polarizing filter. ¡To adjust the polarizing filter, first remove the lens hood.
  • Page 12 10. Extension Tubes (Sold separately) With Extension Tube EF 12 II or EF 25 II, the camera-to-subject distance and image magnification will be as follows: Camera-to-Subject Distance (mm) Near 70mm EF12 II 300mm 1361 7629 70mm EF25 II 300mm 1254 3890 When an Extension Tube is attached, focus manually.

  • Page 13: Specifications

    ¡The size and weight listed are for the lens only, except as indicated. ¡Aperture settings are specified on the camera. ¡The EF1.4X II/EF2X II extenders cannot be used with this lens. ¡All data listed is measured according to Canon standards. ¡Product specifications and appearance are subject to change without notice. ENG-12 24 ×...
  • Page 14 2006.9.1 CT1-7560-002 © CANON INC. 2005...
