CHINT AX-5 Quick Start Manual

P-063
Modular DIN Rail Products
3. Main Parameters and Technical Performance
3.1 Rated working current under different rated voltages
AC-12: AC415V/3A, AC240V/6A
DC-12: DC130V/1A, DC48V/2A, DC24V/6A
3.2 Life
The working life of auxiliary contact is not lower than 10,000 operations.
4. Main Parameters and Technical Performance
4.1Ambient temperature:-35 ºC ~+70 ºC
4.2 The atmosphere condition:≤95%
4.3 Pollution degree: II
4.4 Altitude: ≤2000m
5. Product assembly and installation
5.1 AX-5 auxiliary contact is a kind of accessories, and can only function after being assembled with the NL1. The assembly and disassembly
diagrams are shown below.
Plate
RCCB
AX-5
Auxiliary Contact
1. Scope of Application
AX-5 auxiliary contact is mainly used in the circuit of AC 50/60Hz,
rated heating current 6A, rated voltage AC 415V or DC 130V;
assembled with NL1, it is used for distant circuit breaker on/off
signal indication.
Conforming standard: GB/T 14048.5 , IEC 60947-5-1, accredited
through CE certification.
2. Model and Meanings
Auxiliary contact
Design No
Figure 1 wiring diagram
Figure 2
