Summary of Contents for ROSSO MOTORS X1
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS Children’s electric cars WARNING: Assembled by an adult. This toy is unsuitable for children under 3 years due to its maximum speed. Executive standard: En71 and En62115 ASTM F963-17 Photos are for reference ONLY.
-
Page 2: Installation Instruction
water (swimming pools) or other bodies of water, sloped surfaces, hills, INSTALLATION INSTRUCTION wet areas, flammable vapors, in alleys, at night or in the dark could result in an unexpected accident. Always use the vehicle in a safe, secure environment with continuous adult supervision. - Page 3 CARE WARNINGS immediately give the person water or milk. Do not give water or WARNING! milk if the patient is vomiting or has a decreased level of alertness. Do not induce vomiting. Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
-
Page 4: Specification
Parts List Specification NO. QTY PICTURE PICTURE Name specification Battery 24V 5Ah ( 12-FM-5 ( Ah ) ) * 1 A(Steering Wheel) B(Instruction Book) DC 24V ( motor 550*2) Motor Suitable age 37-96 months D(Wheel cover) C(Wheel) Max weight 30KG Body size 995*660*710MM F(Rear Axle) -
Page 5: Installation Steps
motor R (motor L) P (self-tapping screw) Q( M8 spanner) S(Spring) R(Charger) 3. Install the S(spring) at Z (square pipe), then insert the G(front axle) through the S(spring) and square pipe, finally install the [4] nut in clockwise direction (in the meantime, insert the [5] of front axle should through the [1] steering shaft, then install the [3] gasket and [2] nut to fix T(plum blossom connecter) them in clockwise direction). - Page 6 C [6] C [8] [10] [10] Install the Wheel Step 3: Install the rear axle Step 2: 1. Install C (wheel) and [6] gasket and [7] nut onto the front axle, then install the D (wheel cover) onto the C (wheel) finally. 1.
- Page 7 Step 6: Install Step 4: Install tail box steering wheel battery parts Firstly use a screwdriver to Place and fix M (tail unscrew the steering wheel b o x p a r t s ) o n t h e cover in counterclockwise, corresponding position then install 2 AA batteries...
- Page 8 Step 9: Install the chair The 3 buckles on I (chair) need to be inserted into t h e c o r r e s p o n d i n g grooves on the back of the chair. Then use 2 P(self- attack screws) to fix it.
-
Page 9: Direction For Use
Direction for use Step 11-1: Install the tail bracket I n s t a l l t h e K - 1 ( Ta i l bracket - upper part) and K-2 (Tail bracket - lower part) in correct direction, as show in figure. - Page 10 4-1. Instruction of Control board Button Description: forward backward turn left turn right 11 12 13 S: Speed P:emergency brake, press it and the running function will fall, press again, it release Remote control operating instruction Remote control is priority (when the car is in Remote control, the remote TUNE control personnel can control the car forward and backward, high/Low speed, steering and other functions, the driver CAN NOT operate the car).
- Page 11 13. AUX connector: Connect with other removable device to play audio file 6. Forward/ reverse, and high/ low speed function: Power on, by default, valid. the forward speed is high speed, press button 6 (High/low button) can 14. Charge hole: charge the car with the own charger. change to low speed, press this button again, can change to high speed.
- Page 12 8.Charging instructions. WARNING! Trouble elimination methods Please plug wall charger directly into a wall outlet. Do not use anextension cord. 1.Yes, the fuse cuts off the power 1. Is the fuse overloaded? automatically by 5-20 seconds, then 2. The pedal switch connector is restart;...
