Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLHS68EFSB0
Series
R134a Gal Pro
Color
stainless/black
Volts
115
Wiring Diagram
241689701
Owner's Guide
241695100
Market
North America
Energy Guide
241649238
Service Data Sheet 241636602
Publication No.
5995459806
06/01/30
(EN/SERVICE/RF)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
PLHS68EF
©
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire PLHS68EF
Summary of Contents for Frigidaire PLHS68EF
- Page 1 R134a Gal Pro Color stainless/black Volts Wiring Diagram 241689701 Owner's Guide 241695100 Market North America Energy Guide 241649238 Service Data Sheet 241636602 SIDE-BY-SIDE REFRIGERATOR Model No. PLHS68EF Publication No. 5995459806 06/01/30 (EN/SERVICE/RF) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
-
Page 2: Freezer Door
Publication No: 5995459806 01/06 PLHS68EFSB0 FREEZER DOOR N58FFDCFA1... - Page 3 POS. NO PART NO. 241674806 240334202 240351602 240351702 241545005 241668500 240581906 240536801 240598401 240328204 240328404 241525101 218755402 218755503 240352102 240552102 5303918256 # Functional Parts * Non-Illustrated Parts PLHS68EFSB0 FREEZER DOOR DESCRIPTION Gasket-frzr door, black, magnetic Bin-door, frzr-upper Bin-door Bin-door, frzr-dispenser Bin-tilt out, tilt-out Door-frzr, stainless, complete assy Door Stop, black, frzr...
-
Page 4: Refrigerator Door
Publication No: 5995459806 PLHS68EFSB0 REFRIGERATOR DOOR 01/06... - Page 5 240328203 240328404 240396102 240430312 218755402 218755503 # Functional Parts * Non-Illustrated Parts PLHS68EFSB0 REFRIGERATOR DOOR DESCRIPTION Gasket-refr door, black, magnetic Bin-door, pseudo, bottom Door-dairy Label-nameplate Door Stop, black, ref Door-refr, stainless steel, complete assy Handle-door, stainless steel, with insert Screw, 10-32 x 1/2...
- Page 6 Publication No: 5995459806 01/06 PLHS68EFSB0 CABINET N58BAAAAB5...
- Page 7 POS. NO PART NO. 240435908 240475907 5303208309 240505801 241547901 218252200 240457702 240402701 240335501 241603701 241603702 240337603 240327201 241555103 241550801 241550701 240578901 240335003 241500301 240349402 241595401 240504901 240518802 240324406 5308016566 5304418225 5303316859 241574605 218249808 216850900 240423701 100* 240350802 240479601 5303321321 # Functional Parts * Non-Illustrated Parts PLHS68EFSB0 CABINET...
- Page 8 Publication No: 5995459806 01/06 PLHS68EFSB0 SHELVES 140A N58SLDJBD1...
- Page 9 POS. NO PART NO. 241510604 240350668 240350667 240324101 241552801 241555401 240590401 16A# 241513901 16A* 241537504 240355203 240355205 240350106 240350702 240362101 240350902 240351022 240349801 240423101 240423201 240423301 241595202 241638201 26A* 241638101 240351219 240362201 240367602 240356501 240349701 42A* 240349901 42A* 240350001 240350602 240350603 240564401 240530502...
- Page 10 Publication No: 5995459806 01/06 PLHS68EFSB0 CONTROLS N58TCAAAB3...
- Page 11 POS. NO PART NO. 5308000010 215474201 241563601 240369702 241517701 241555401 16 # 241513901 241608801 241663601 241603913 241608401 241608501 23 # 5304452071 241608901 5308016566 241637201 241600902 241527302 137* 240396701 240397301 240396002 139* 240526901 241563501 149* 241528306 241505101 241505001 240397401 240397502 199* 240398401 240397601 # Functional Parts...
- Page 12 Publication No: 5995459806 01/06 PLHS68EFSB0 SYSTEM N58CAAAAA6...
- Page 13 POS. NO PART NO. 240333603 218679607 218944001 241641401 241663601 241651601 14 # 240316107 15 # 5303918284 5308000110 5303918214 240330008 218252200 218513300 240491501 241637401 5303918314 30 # 241527803 241544101 240405201 240555001 215174700 5308016566 241635501 241641501 218909915 240542601 218897002 5304430246 240346701 240359401 60 # 240525402 61 #...
-
Page 14: Ice And Water Dispenser
Publication No: 5995459806 PLHS68EFSB0 ICE & WATER DISPENSER 01/06... - Page 15 POS. NO PART NO. 218976409 218976901 218976907 240561701 5304422012 5304424549 5304426649 240323949 5304421619 241649003 5304433613 5304433610 5304421628 5304421624 5304421625 5304421629 5304421620 5304421824 5304433619 38A# 5304421617 5304454250 38C* 5304430811 5304421627 5304421829 215296300 240363401 5304421830 5304421622 5304421621 5304421831 5304421850 5303918256 5304426535 # Functional Parts * Non-Illustrated Parts PLHS68EFSB0 ICE &...
-
Page 16: Ice Container
Publication No: 5995459806 01/06 PLHS68EFSB0 ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 POS. NO PART NO. 5304428402 5304404343 241561301 5304404346 241561401 241624801 5304404359 241555401 241559801 5304404345 18 # 5304440392 241578401 5304404332 215285100 240597201 5304404347 5304404362 5304420654 5304404351 5304404349 5304404353 5304404352 5304404348 5304404350 5304404356 5304404365 5304404358 218359200 45 # 5304404333 5304406816 5304406817 5304406818 5304406819 5304404341 5304404342...
-
Page 18: Ice Maker
Publication No: 5995459806 01/06 PLHS68EFSB0 ICE MAKER INSTALLATION PARTS N58I115T... - Page 19 POS. NO PART NO. 218976409 218976901 218976907 218976911 240561701 5304436616 3206301 5304436604 3206305 5304436619 3206312 5304436610 3206315 11 # 5304436618 5304436614 5304436613 5304420652 15 # 3206324 5304436609 17 # 5304436617 5304436607 18*# 240352601 5304436606 5304408581 5304436608 5304436602 5304408582 3206335 3206336 5304420654 3206338 3206339...
-
Page 20: Wiring Schematic
Publication No: 5995459806 FF THERMISTOR FRZ THERMISTOR 01/06 PLHS68EFSB0 WIRING SCHEMATIC G E N E S I S C O N T R O L... -
Page 21: Wiring Diagram
# Functional Parts * Non-Illustrated Parts PLHS68EFSB0 WIRING DIAGRAM White White Gray Gray WHITE WHITE Publication No: 5995459806 01/06...
