Hang your clocks
1.
Place the clock on the wall using the keyhole hanger on the back of the clock or the optional
security bracket (sold separately).
Note: If hanging your clock over an Ethernet jack, offset the clock as shown below.
Keyhole
Hanger
With
Optional
Security
Bracket
(12" shown)
INST-POE-ANA Rev 5
Power Over Ethernet (PoE) Analog Clocks
Please read this first!
If this is your first installation or you have questions at any time during this process, please call
800-328-8996
American Time toll free at
1
Pre-Installation
1. Verify network infrastructure with Network Administrator.
• Power over Ethernet (PoE) solution
• Dynamic Host Configuration Protocol (DHCP) settings
2. Plan Analog PoE Clock locations and cabling routes
2
Unpack the box
• Remove the components from the box. Save the packing materials in case you need
them later.
3
Check the contents
Your package contains:
• Analog PoE clock(s)
• 1ft CAT 5 or higher Ethernet patch cable
• Quick Start Guide
• Installation and Operation Manual
• USB Drive (optional) with Network Clock Connect Software—Part #H004167B-POE
800-328-8996
american-time.com
phone:
online:
140 3rd St. So.; PO Box 707, Dassel, MN 55325-0707
mail:
.
800-789-1882
fax:
