Summary of Contents for Changhong Electric UD55YC5500UA
- Page 1 Operation Manual Model: UD55YC5500UA CHANGHONG TRADING CORP., USA 17800 Castleton St. Suite 306, City of Industry, CA 91748 TEL: 1(626)965-2688 FAX: 1(626)965-6998 Service E-mail: info@changhongusa.com Web site: www.changhongUSA.com...
-
Page 3: Regulatory Information
Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... - Page 4 Warning WARNING To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc. The Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
- Page 5 Warning Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 6: Important Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 7. Do not block any of the ventilation 2. Keep these instructions. openings. Install in accordance with the 3. Heed all warnings. manufacturer's instructions. 4. Follow all instructions. 5. Do not use this apparatus near water. 8. - Page 7 Safety instructions 10. Protect the power cord from being 13. Unplug this apparatus during walked on or pinched particularly at lightning storms or when unused for plugs, convenience receptacles, and long periods of time. the point where they exit from the apparatus.
-
Page 8: Getting Started
Getting Started Using the Remote Control When using the remote control, aim it at remote sensor on the television. If there is an object between the remote control and the remote sensor on the unit, the unit may not operate. •... -
Page 9: Connection And Setup
Connection and Setup Cable Installation Before the installation and use, please read carefully the relevant content in “Warning and Safety instructions”. 1. Take out the TV from the wrapping package and put it in a drafty and flat place. NOTE: •... - Page 10 Connection and Setup Installation Guide When the TV is initially powered on, a sequence of on-screen prompts will assist in ► configuring basic settings. Press the ENTER button to start the guide. Press the button ◄ to go to the next step. Press the button to return to the previous menu.
-
Page 11: Remote Control
Remote Control 1.This product is RF remote control whose code must be connected to the TV code successful, the n RF remote control could be used. codes area 2.Codes Connection Method: Close to TV(codes area), press "MENU" and "INPUT" buttons at the same time. INFO CH LIST SOUND... - Page 12 Remote Control The buttons of the original remote control are as following: Definition of the buttons on the remote control: : Enter or quit the standby mode. INFO: Press to display the current program information on the screen. It takes in effect in some inter faces (In MHL mode). INFO : Mute or restore sound.
-
Page 13: Basic Operation
Basic Operation Turning on and off the TV ■ Turn on the TV Connect the power cable, and press the button to turn on the TV. ■ Turn off the TV Press the button on the remote control to enter standby mode. Do not leave your set in standby mode for long periods of time. -
Page 14: Menu Operation
Menu Operation How to Navigate Menus Before using the TV, follow the steps below to learn how to navigate the menu in order to select and adjust different functions. The access step may differ depending on the selected menu. 1. Press the MENU button to display the main menu. 2. - Page 15 Menu Operation Configuring the Picture Menu ■ Picture Mode: You can select the type of picture which best corresponds to your viewing requirements. Mode: Changes the image mode. Contrast: Adjusts the signal level between black and white in the picture. You may use Contrast when the bright part of the picture is saturated.
- Page 16 Menu Operation frequency band at a time. It is suggested to NOT make large changes. The adjusted values are stored according to the User mode. ■ Balance: You can adjust the sound balance of the speakers to preferred levels. ■ AVC: AVC automatically remains on the same level of volume if you change programs.
- Page 17 Menu Operation Define TV-Y General audience TV-Y7 Parental guidance suggested TV-G Parents strongly cautioned TV-PG Retricted TV-14 No one 17 and under admitted TV-MA Adult audience only TV-None None Content Define Fantasy violence Suggestive dialogue Strong language Sexual situations Violence MPAA Rating Define...
- Page 18 Menu Operation Parental guidance Viewers 14 and older Adult programming EXEMPT Unblock Canada French: The ratings are for programs which are using French rating system. Rating Defined as General 8 ans+ Not recommended for younger children 13 ans+ Not recommended for children under age 13 16 ans+ Not recommended for ages under 16 18 ans+...
- Page 19 Menu Operation Digital CC: Applies only to digital channels with closed caption. Service1,2,3,4,5,6 These are different service data channels. Option: You can customize the closed caption display characteristics. Mode: Default/Custom. If set to Custom, Digital CC is available. Font Style: Default/Font 0~7 Font Size: Default/ Normal/ Large/ Small Font Edge Style: Default/ None/ Raised/ Depressed/ Uniform/ Left Shadow/ Right Shadow...
- Page 20 Menu Operation Using USB mode ■ To Access/Quit USB mode Connect an USB device. Press button to display the main menu. Use the INPUT ▲/▼ to highlight USB, and the ENTER button to access the USB mode. You may also use the signal source selection menu to exit from the USB mode. NOTE: •...
-
Page 21: Troubleshooting Guide
Troubleshooting Guide Troubleshooting Before contacting a service technician, perform the following simple checks. If any program still persists, unplug the TV and call for service. Symptoms Possible Reason Solutions 1.The power cord is not plugged in 1.Plug the power cord in No picture, no sound, and no indicator light on 2.The power is off... - Page 22 Troubleshooting Guide HDMI source, with snowy The input source is not standard Plug the HDMI cable again pixels in full screen 1. Make sure the positive and the negative polarities are correct. The remote control does Batteries are improperly installed or 2.Check whether there is a not work exhausted...
-
Page 23: Specifications
Specifications Key Features Model UD55YC5500UA Digital TV or ATV ATSC/NTSC Area North America Display Technology ELED 2D/3D(2D/PR 3D/SG 3D) Refresh Rate EMR240Hz Aspect Ratio 16:9 Resolution 3840*2160 Energy Grade ENERGY STAR 6.1 Ultra-narrow plastic frame , ID Features Curved stand... - Page 24 Specifications ＞30,000hrs (min) Life Time Color 1.06Billon (10bit) SOUND Speakers Integrated speakers (Bottom side) Audio Power Output 8W+8W 5 sound effects preset Sound mode (user/theater/sports/music/Standard) Sound Control Balance/AVC/Equilizer FUNCTION OSD Language English,Spanish,French Digital signal ATSC Clock/Sleep Timers Watch Time Limit Yes/two hours of health alerts Startup Setting Picture Freeze...
- Page 25 Specifications SPDIF Coaxial ACCESSORIES Screws Batteries Stand Mounting Guide Warranty card Operation Manual Quick Start Guide Remote control Roku Propaganda label BASIC Info. TV System ATSC(DTV) NTSC (ATV) AV System NTSC Channels Air(CH2~CH69) Cable(CH1~CH135) Certification ETL FCC ENERGY STAR Power Supply AC 100V-240V 50/60Hz Power Consumption-TV on ＜...
