- Page 1 GLRSF236JB1 GLRSF236J GLRSF236JD1 GLRSF236J GLRSF236JW1 GLRSF236J North America 101 Masters Blvd. Anderson, SC 29624 GALLERY black GALLERY almond GALLERY white Publication No. 5995342945 000831 -EN/SERVICE/KHB ©2000 White Consolidated Industries, Inc. All rights reserved...
-
Page 2: Freezer Door
Publication No. GLRSF236J 5995342945 FREEZER DOOR 08/00... - Page 3 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J FREEZER DOOR 215734323 A - - Gasket-frzr door,black ,magnetic 215734313 - B C Gasket-frzr door,white ,magnetic 5303288950...
-
Page 4: Refrigerator Door
Publication No. GLRSF236J 5995342945 REFRIGERATOR DOOR 08/00... - Page 5 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J REFRIGERATOR DOOR 215734324 A - - Gasket-refr door,black ,magnetic 215734314 - B C Gasket-refr door,white ,magnetic 215390401...
- Page 6 Publication No. GLRSF236J 5995342945 CABINET 08/00...
- Page 7 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 10A* 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J CABINET 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg...
- Page 8 Publication No. GLRSF236J 5995342945 SHELVES 08/00...
- Page 9 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J SHELVES 5303298147 A B C Trim-basket 218298001 A B C Shelf-freezer,sliding ,wire 218159700 A B C Spacer-shelf...
- Page 10 Publication No. GLRSF236J 5995342945 CONTROLS 08/00...
- Page 11 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 13 # 17A* 21 # 23 # 114# 141* # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J CONTROLS 215028605 A B C Knob-damper control 5308000010 A B C...
- Page 12 Publication No. GLRSF236J 5995342945 SYSTEM 08/00...
- Page 13 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 13 # 14 # 15 # 21 # 29 # 30 # 54A* 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J SYSTEM 218787800...
- Page 14 Publication No. 5995342945 08/00 GLRSF236J DISPENSER...
- Page 15 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 12A* 17A* 33 # 35 # 38 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J DISPENSER 218832301 A B C Tube-water inlet, inlet valve ,to filter...
-
Page 16: Ice Container
Publication No. GLRSF236J 5995342945 ICE CONTAINER 08/00... - Page 17 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J ICE CONTAINER 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C...
-
Page 18: Ice Maker
Publication No. GLRSF236J 5995342945 ICE MAKER 08/00... - Page 19 A = GLRSF236J (GLRSF236JB1) B = GLRSF236J (GLRSF236JD1) C = GLRSF236J (GLRSF236JW1) 11 # 12 # 13 # 15 # 17 # 141* # = Fast-moving Parts * = Non-Illustrated Parts GLRSF236J ICE MAKER 218832301 A B C Tube-water inlet, inlet valve, to filter...
-
Page 20: Wiring Schematic
Publication No. GLRSF236J 5995342945 WIRING SCHEMATIC 08/00... -
Page 21: Wiring Diagram
GLRSF236J Publication No. 5995342945 WIRING DIAGRAM # = Fast-moving Parts 08/00 * = Non-Illustrated Parts...
