3" VARIABLE SPEED RANDOM ORBIT
Dual-Action Polisher and Sander with a 3" Backing Plate
Pad oscillates and rotates on varying orbits
SAFETY & OPERATING
INSTRUCTION MANUAL
Speed Dial Settings 1 to 6 Approximate Speeds
Setting
3:
4:
5:
6:
RANDOM ORBITAL ACTION
1
DUR P9517
Speed
Usage
3300 OPM
Polishing & Cleaning
4000 OPM
Polishing & Cleaning
4700 OPM
Removing Paint Defects & Oxidation
5500 OPM
Removing Paint Defects & Oxidation
Advertisement
Table of Contents
Related Manuals for Dura Gold DUR P9517
Summary of Contents for Dura Gold DUR P9517
- Page 1 3” VARIABLE SPEED RANDOM ORBIT Dual-Action Polisher and Sander with a 3” Backing Plate DUR P9517 Speed Dial Settings 1 to 6 Approximate Speeds Setting Speed Usage 3300 OPM Polishing & Cleaning 4000 OPM Polishing & Cleaning 4700 OPM Removing Paint Defects & Oxidation 5500 OPM Removing Paint Defects &...
- Page 2 WARNING: indicates a potentially hazardous situation which may result in death or serious injury and/or property damage. CAUTION: Indicates a potentially hazardous situation which may result in minor or moderate injury and/or property damage. NOTICE: Indicates a potentially hazardous situation, which may result in minor or moderate injury and/or property damage.
- Page 3 e) Do not overreach. Keep proper footing and g) lf devices are provided for the connection of dust balance at all times. This enables better control extraction and collection facilities, ensure these of the power tool in unexpected situations. are connected and properly used. Use of dust collection can reduce dust-related hazards.
- Page 4 has fallen, verify that they are not damaged cutting accessory may contact hidden wiring or install a new accessory. After inspecting or or its own cord. Cutting accessory contacting installing an accessory, test the operation of a “live” wire may make exposed metal parts of the tool at maximum speed and without load for the power tool “live”...
- Page 5 ADDITIONAL SPECIFIC SAFETY INSTRUCTIONS FOR POLISHER • Always use eye protection. All user and in line voltage resulting in loss of power and bystanders must wear eye protection that overheating. When using more than one conforms to Z87.1. extension to make up the total length, be sure each individual extension contains at least •...
- Page 6 REPLACING THE POLISHING PAD OR SANDING DISC CAUTION: Pull the used polishing pad or sanding disc off and apply the new one pressing it onto the backing plate. CAUTION: Accessories must be rated for at least the speed recommended on the tool warning label.
- Page 7 INDICATOR 1. The power indicator can remind you that the power is turned on, which is safer and more reliable; When the light is green, it indicates that the power has been turned on and the machine can be ready for work. Currently, be careful as it is necessary to pay attention to safety. 2.
- Page 8 DP9517 Part List Name Name Backing pad Elastic collar Epoxy spacer Cross pan head screw Stator Elastic collar Carbon brush Bearing 696-2RS Cross pan head screw Elastic collar Brush holder Counterbalance Sping coil Cross pan head screw 5 Name plate Counterbalance Switch shroud...
