Summary of Contents for CaptiveWorks CW-100R

Page 2: Table Of Contents
Portable Digital Recorder & Player CW-100R Content Content……………………………………………………………………………………….…1 Instruction………………………………………………………………………………….2 RCU………………………………………………………………………………………..3 System Menu Introduction………………………………………………………………..5 3.1 . Play file……………………………………………………………………………...6 3.2 . Format…………………………………………………………………….…….…..9 3.3 . AV Signal………………………………………………………………….………..11 3.4 . Timer Record……………………………………………………….……..……….11 3.5 . Setup…………………………………………………………………….…………14 3.5.1. System……….………………………………………………….…..………..15 3.5.2. TV Signal…………………………………………………….……….………18...
Page 3: Instruction
Portable Digital Recorder & Player CW-100R Introduction This digital DVB recorder take place of traditional Video recorder。It can be connected to your PC, upload video or image, download AVI, MPEG1, MPEG2, JPEG, BMP, MP3 multimedia files. Has connector for SD card and USB, and can extend to connect hard dis.
Page 4: Rcu
Portable Digital Recorder & Player CW-100R 2 RCU...
Page 5 Portable Digital Recorder & Player CW-100R CW-100R: RCR function BUTTON FUNCTION STANDBY POWER VOL+ Volume increase VOL- Volume decrease Channel increase Channel decrease 0～9 Numeric button, +10, channel selecting, Switch to recorder mode UP/DOWN up and down, right and left to select in menu,...
Page 6: System Menu Introduction
Portable Digital Recorder & Player CW-100R SOURCE Source of the signal REPEAT Repeat the playing DISPLAY Display the playing information STORAGE USB/CARD/HDD switchable Blue = context button on bottom of screen Numbers = numbers or letters in text entry areas. The numbers work like a cell phone. The letters for each number are below the number on the remote.
Page 7: Play File
Portable Digital Recorder & Player CW-100R 3.1 Play file Supporting Movie, Music, JPG file playing and edit, when the selected file (not including JPG) is highlighted, press EDIT button on remote control, it will pop up a edit menu, here can configure format of playing, rename and delete.
Page 8 Portable Digital Recorder & Player CW-100R Edit 1． Menu for edit： When one file is selected, press EDIT on remote control, there will pop up an EDIT menu, select “ PLAY MODE” to setup the repeat playing mode of the file;...
Page 9 Portable Digital Recorder & Player CW-100R 3． RENAME： Can input name by letter 12 max, English letter capital, number and PC supported also, and normal symbol input supported. 4． DELETE： Can delete selected file, before deleting, there will be a warning message to ask for...
Page 10: Format
Portable Digital Recorder & Player CW-100R 3.2 Format To format internal and external store, clear up disk. Format will clear up data in USB/CARD/HDD，and reset up FAT file system. Press “ENTER” you will see the following dialog box. Then press “ENTER” again to...
Page 11 Portable Digital Recorder & Player CW-100R After execution, there will be another menu pop up, the format time will be different depend on the data storage in the device, don’t remove the USB/CARD/HDD at this time, neither cut power off, otherwise system will not be able to identify USB/CARD/HDD device,...
Page 12: Av Signal
Portable Digital Recorder & Player CW-100R After format, you will see the following dialog box. 3.3 AV signal Selet AV signal and press ok, will switch to the A/V in source 3.4 Timer Record Timer record can record the TV or AV IN signal to HDD/USB/CARD by AVI format, here can select signal source, destination, date, mode, start time, end time, and quality.
Page 13 Portable Digital Recorder & Player CW-100R 2． Setup date and mode for recording 3． Setup the time for starting recording...
Page 14 Portable Digital Recorder & Player CW-100R 4． Setup the end time for recording 5． Setup the recording quality...
Page 15: Setup
Portable Digital Recorder & Player CW-100R 3.5 Setup Setup: Functions of system and signal source. Setup: System Tv Tuner...
Page 16: System
Portable Digital Recorder & Player CW-100R 3.5.1 System TV System PAL、NTSC； Press [→] [←] [↑] [↓] to move bouquet on the item you want, then press “ENTER”. “RETURN” button for exit. Screen Saver Turn on/off Screen Saver； Press [→] [←] [↑] [↓] to move bouquet on the item you Want, then...
Page 17 Portable Digital Recorder & Player CW-100R System Language Display languages saved in system: Press [→] [←] [↑] [↓] to move bouquet on the item you Want, then press “ENTER”. “RETURN” button for exit. Time Format Set time format: Press [→] [←] [↑] [↓] to move bouquet on the item you want, then...
Page 18 Portable Digital Recorder & Player CW-100R Date Setup system Year/month/date: Press [→] [←] [↑] [↓] to move bouquet on the item you Want, then press numeric button to input Year/month/date 。 Timer Setup system hh:mm、 AM/PM； Press [→] [←] [↑] [↓] to move bouquet on the item you want.
Page 19: Tv Signal
Portable Digital Recorder & Player CW-100R Factory default。move bouquet on this item, then press “ENTER”. 3.5.2 TV Signal TV Signal Choose analog signals format: Set time format: Press [→] [←] [↑] [↓] to move bouquet on the item you want, then press “ENTER”. “RETURN” button for exit.
Page 20 Portable Digital Recorder & Player CW-100R Press [↑] [↓]to move bouquet to the first item on the left, then press [→] [←] to move bouquet optional setup PAL、SECAM L、SECAM L’（NTSC）；press [↑] [↓] to put bouquet on the second item ，press [→] [←] to choose I、BG、DK audio format，；...
Page 21 Portable Digital Recorder & Player CW-100R Press [↑] [↓] move the bouquet on the option items，press [→] [←], change data of each item. Press “ENTER” begin Manual search. Manual Tuning Press [→] [←] [↑] [↓] to move bouquet on “Manual Tuning” item. press “ENTER”...
