NA-F903B̲953B̲インドネシア向洗濯機.indd 1
NA-F903B̲953B̲インドネシア向洗濯機.indd 1
Operating Instructions
& Installation Instructions
Fully Automatic Washing Machine
Model No.
NA-F953B
NA-F903B
No.Reg. I.14.PGI3.01201.0313
Contents
Safety Precautions .................. 2
Part Names ............................... 3
Operation Panel ....................... 4
Variety of Courses ................... 5
Washing .................................... 6
Washing Options ..................... 8
Convenient Functions ............ 10
Maintenance ........................... 10
Installation .............................. 12
Troubleshooting .................... 14
Error Messages ...................... 15
Specifi cations ......................... 16
Thank you very much for purchasing
Panasonic Product.
Before operating this washing machine,
please read these instructions completely,
paying special attention to Safety Precautions.
(Domestic use)
W9901-8HB20
H0313-2113 (I)
Printed in Vietnam
2013/11/21 12:54:23
2013/11/21 12:54:23
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F953B
Summary of Contents for Panasonic NA-F953B
-
Page 1: Table Of Contents
Operating Instructions & Installation Instructions Fully Automatic Washing Machine (Domestic use) Model No. NA-F953B NA-F903B No.Reg. I.14.PGI3.01201.0313 Contents Safety Precautions ....2 Part Names ....... 3 Operation Panel ....... 4 Variety of Courses ....5 Washing ........6 Washing Options ..... 8 •... -
Page 2: Safety Precautions
Safety Precautions To prevent the risk of danger to humans or property damages, make sure to follow the precautions described below. ■ The descriptions are classifi ed according to the degree of harm or damage caused by misuse. May cause minor or WARNING CAUTION May cause serious... -
Page 3: Part Names
Part Names Lint fi lter Water supply valve Bleach / Liquid detergent inlet Power cord Operation and plug panel ■ During Use Do not put in fl ammable things or clothes with such things attached. Keep them away from the washing machine. -
Page 4: Operation Panel
Operation Panel ● The operation panel for NA-F953B is used in this manual. Detergent volume guideline Water level/Remaining time The detergent volume guideline corresponding to the water level indication is shown below. Indicates the selected course (No.) : 1 scoop of detergent) ●... -
Page 5: Variety Of Courses
Variety of Courses Maximum capacity Purpose Course (Number) ) is for NA-F903B. Everyday Daily washing 7.5 (7.0) kg Normal (P.6) clothes Speedy washing 7.5 (7.0) kg Speedy (P.6) for light soil Delicates Washing 3.5 kg Delicate (P.8) delicates gently Clothes for baby & people Rinsing 7.5 (7.0) kg Baby-care... -
Page 6: Washing
Washing Preparation: ● Check whether the washing machine has been properly installed. (P.12) ●Turn on the water faucet. Turn the power on. Start. Select the course. For reservation Powdered synthetic According to the water level, After loading the laundry, detergent put in the detergent. - Page 7 ■ Fragrance course The buzzer beeps and operation stops before the fi nal rinse cycle. buzzer Peep (5 times) After the buzzer beeps, dilute your preferred amount of softener with water and directly put in the tub. ● You cannot select 5 Fragrance course during Child Lock (P.10).
-
Page 8: Washing Options
Blanket course. Preparation: Turn on the water faucet. Turn the power on. Start. Select Delicate course. ● Water level indication NA-F953B: 53 L NA-F903B: 52 L ● Water level cannot be changed. Put in the Start. liquid detergent. Close the lid. -
Page 9: Energy Save
Energy Save Air Dry This extracts water from clothes by air blow utilising the tub rotation. The power consumption is 10% lower than that of Normal course. (Agitation is performed approx. every 30 minutes to untangle Preparation: Turn on the water faucet. the laundry.) ■... -
Page 10: Convenient Functions
Turn the tub. (See left.) ■ If the fi lter is broken Buy a new fi lter at nearest Panasonic Service Centre. NOTE ● If there is water in the tub or “Start” is pressed, the tub cannot be turned. - Page 11 Water supply fi lter <Air Dry/Tub Hygiene> If water does not fl ow smoothly Once a week (Dry) ● Make sure to observe the following procedure to prevent After operation is complete, spatter of water. operate the washing machine with Air Dry course without Turn off the faucet.
-
Page 12: Installation
Installation ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. ■ Make sure to ask a service person for installation. Do not install by yourself. - Page 13 4. Connect the water tap adaptor and water supply hose. Connect the water tap adaptor to the faucet. A part 1) Loosen 4 screws. 2) Connect to the faucet and tighten the Flange Screw screws. Claw thread Fix. Lever Lever ●...
-
Page 14: Troubleshooting
Troubleshooting Check the following before requesting service. Symptoms Checkpoints ● Remaining time is corrected during the process and displayed. Remaining time fl uctuates. (Time indication is an approximation.) ● Power failure? ● Is the lid closed completely? ● Is the power fuse or the breaker cut off? No operation. -
Page 15: Error Messages
Error Messages If the buzzer sounds and “U”/“H” and “Number” are alternately displayed, check the following. If the problem persists or any other malfunctions occur, pull out the power plug and contact a service person for service. ● Cancel Child Lock (P.10) when it is active. Symptoms Checkpoints ■... -
Page 16: Specifi Cations
PT. Panasonic Gobel Indonesia Jl.Dewi Sartika No.14 (Cawang Ⅱ ). Jakarta 13630. Indonesia Telp. (021) 8090108, Fax. (021) 8004368 Panasonic Corporation Web site: http://panasonic.net © Panasonic Appliances Vietnam Co., Ltd. 2013 Made in Vietnam / Produksi Vietnam NA-F903B̲953B̲インドネシア向洗濯機.indd H4 NA-F903B̲953B̲インドネシア向洗濯機.indd H4 2013/11/21 12:54:23 2013/11/21 12:54:23...
