Ewig TPR303 Instruction Manual

Grill thermometer
Hide thumbs

Advertisement

Quick Links

Download this manual
WIRELESS GRILL THERMOMETER
MODEL: TPR303
Congratulations on your purchase of the Wireless Grill Thermometer, a programmable wireless food
thermometer. You will now be able to remotely monitor the time and temperature of food cooking in the oven or
outdoors from anywhere in your home. The receiver unit will beep to alert you when the cooking temperature is
within the 10°F (5°C) range or already reaching the target temperature.
Receiver Features
LCD - Liquid crystal display to show display icons, Food-Taste, Timer, Received & Set temperatures. See LCD
diagram for detailed information.
CLIP – Detachable clip for attaching the receiver unit on a wrist belt or for resting on cradle.
BATTERY COMPARTMENT - Holds two (2) 'AAA' 1.5V batteries.
8
CLIP
BATTERY COMPARTMENT
Description of buttons
1. [HR/▲]
In Timer mode, press to set hour from 0hr to 23hr. Press and hold for 2 seconds; the hour setting will
increase at a faster rate.
In Thermometer mode, press to increase the manual temperature from 14ºF to 482ºF ( -10ºC to 250ºC ).
INSTRUCTION MANUAL
LCD
1
2
3
4
9
Page 1 of 10
6
7
5

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPR303 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ewig TPR303

  • Page 1 WIRELESS GRILL THERMOMETER MODEL: TPR303 INSTRUCTION MANUAL Congratulations on your purchase of the Wireless Grill Thermometer, a programmable wireless food thermometer. You will now be able to remotely monitor the time and temperature of food cooking in the oven or outdoors from anywhere in your home.
  • Page 2 Press and hold for 2 seconds, the temperature setting will increase at a faster rate. 2. [MIN/▼] In Timer mode, press to set minutes from 0 min to 59 min. Press and hold for 2 seconds; the minute setting will increase at a faster rate. In Thermometer mode, press to decrease the manual temperature from 14ºF to 482 ºF ( -10ºC to 250ºC ).
  • Page 3 Timer mode (Count up /Count down) Count up Count down How to use the count up timer 1. Press [MODE] button to select the Timer mode, the timer icon ‘ ’ will appear. 2. In Timer mode and while the timer is stop running, press [CLEAR] button to reset the timer to 0:00. 3.
  • Page 4 Thermometer mode Taste level Low battery indicator for receiver Meat type Low battery indicator for transmitter Pre-programmed Temperature Alert In Thermometer mode, this device will alert user when the probe temperature reached the pre-determined selective setting. The user firstly selects a meat type (e.g. Beef) and a taste level (e.g. WELL DONE). The pre-set temperature of 170ºF display automatically.
  • Page 5 Pre-Alert When the probe temperature is within 10°F (5°C) of the pre-set temperature, the device unit will beep once every 2 seconds and last for 1 minute. Reach Alert When the probe temperature reaches the pre-set temperature, the device unit will beep in pattern of bi-bi-bi/sec for 5 second, then silent for 7 second.
  • Page 6 Manual temperature setting The user can use [▲] and [▼] button to enter a manual temperature other than the above pre-programmed temperature. When manual temperature is in use, the ‘PRE-SET’ icon change to ‘MANUAL’. RF loss link indication The receiver unit normally works well in the 30 m / 98 ft. range (at sign) with the Transmitter unit. However, if the receiver unit is taken outside the wireless reception range or there is severe external radio interference, the receiver may not able to receive the temperature signal from the Wireless sensor probe.
  • Page 7 SPECIFICATIONS – Receiver unit (Device) Temperature measuring range: 14°F to 482°F (-10°C to 250°C) Displayed probe temperature range: 14°F to 482°F (-10°C to 250°C) Operating temperature (device): 32°F to 122°F (0°C to 50°C) Batteries: 2 ‘AAA’ (1.5V) alkaline batteries Page 7 of 10...

  • Page 8: Battery Compartment

    Transmitter Features plug in for stainless steel probe sensor BATTERY COMPARTMENT – holds 2 AAA batteries. Description of buttons 1. [TX] – transmit manually, terminates the auto registration process. Press and hold for 2 seconds to register the radio frequency with the receiver. 2.

  • Page 9: Helpful Hints

    5. Registration is complete when the Receiver receives the probe temperature and displays it in place of the flashing icon ‘- - -‘. If the probe temperature does not appear in the receiver within 5-10 seconds, press and hold [MODE] button in the Receiver unit for 2 seconds to re-enter the RF registration mode. The icon ‘- - -‘...
  • Page 10 Cleaning - Always wear a heat resistant glove to touch the stainless steel probe sensor or wire during or just after cooking. Do not touch with bare hands. - Keep the stainless steel probe sensor and wire away from children. - Wash the metal probe tip with hot soapy water and dry thoroughly.
