CANT-0042 Signal Antenna Installation
For maximum performance be sure to aim the antenna in the direction of your wireless provider's tower. If you know
the direction of your provider's tower, simply point the antenna in that direction. If you are unsure of the location of
the nearest tower, see antenna aiming instructions below. Note: the closest tower to your location may not be for
your specific provider.
Note: Choosing the highest possible point for antenna placement will usually produce the best results. If
you do not have roof access, you should choose the side of the building with the strongest signal.
Keep the Antenna at least 3 feet above metal.
Keep the Base Unit unplugged until all cables are connected.
Installation Steps:
1. Once you have determined the location of strongest signal,
install a mast or pole (not provided) on which to mount the
antenna.
2. Assemble the provided L-bracket with the antenna using the
provided screws. Then loosely connect the L-bracket to a mast
to allow rotation around the mast (Important: The 2 holes on
the side of the antenna plastic must be facing down). Before
securing antenna hardware, take care in finding the optimum
angle at which to aim the antenna – See Antenna Aiming
Section for further instruction.
3. Connect the RG-6 coax cable to the antenna.
4. Route the cable indoors and connect it to the base unit using
the Cell Phone Signal Booster installation instructions.
CONTINUED ON BACK
