Temperature Controlled Enclosures
Protect your electronics and control their environment!
ACE Series
Outdoor enclosures with UL Listed
air-conditioners, filters, and thermostats
BW-124-8-ACE
NEMA 4, 24"W x 24"H x 8"D
with an 800 BTU AC unit
BW-124-8-ACESS
Stainless steel NEMA 4X
version
BW-124ACE
NEMA 4, 24"W x 24"H x 12"D
with a 2000 BTU AC unit
BW-124ACESS
Stainless steel NEMA 4X
version
BW-136ACE
NEMA 4, 24"W x 36"H x 12"D
with a 2000 BTU AC unit
BW-136ACESS
Stainless steel NEMA 4X
version
BW-RACKACE
NEMA 4, 22"W x 12RU H x 24"D
with 2000 BTU AC unit and an
internal 19" rack
BW-RACKACESS
Stainless steel NEMA 4X
version
BW-242410ACE
NEMA 4X, Polycarbonate,
non-metallic enclosure,
24"W x 24"H x 10"D with an
800 BTU AC unit
Don't see the enclosure you need?
Call or e-mail us and we'll be happy to help!
Indoor & Outdoor Electrical Enclosures | Drive-Alert Vehicle Detection & Asset Protection Systems | Custom Fabrication
Protection from Vandals and Mother Nature!
800-473-0213 ~ info@mierproducts.com ~ www.mierproducts.com
ACHT Series
Outdoor enclosures with UL Listed
air-conditioners, heaters, filters, and thermostats
BW-124-8-ACHT
NEMA 4, 24"W x 24"H x 8"D with an
800 BTU AC unit and 150W heater
BW-124-8-ACHTSS
Stainless steel NEMA 4X
version
BW-124ACHT
NEMA 4, 24"W x 24"H x 12"D with a
2000 BTU AC unit and 500W heater
BW-124ACHTSS
Stainless steel NEMA 4X
version
BW-136ACHT
NEMA 4, 24"W x 36"H x 12"D with a
2000 BTU AC unit and 500W heater
BW-136ACHTSS
Stainless steel NEMA 4X
version
BW-RACKACHT
NEMA 4, 22"W x 12RU H x 24"D
with 2000 BTU AC unit, 500W
heater, and an internal 19" rack
BW-RACKACHTSS
Stainless steel NEMA 4X
version
BW-242410ACHT
NEMA 4X, Polycarbonate,
non-metallic enclosure,
24"W x 24"H x 10"D with an
800 BTU AC unit and a
150W heater
Advertisement
Related Manuals for Mier products ACE Series
Summary of Contents for Mier products ACE Series
- Page 1 Protection from Vandals and Mother Nature! Temperature Controlled Enclosures Protect your electronics and control their environment! ACE Series ACHT Series Outdoor enclosures with UL Listed Outdoor enclosures with UL Listed air-conditioners, heaters, filters, and thermostats air-conditioners, filters, and thermostats BW-124-8-ACE BW-124-8-ACHT NEMA 4, 24”W x 24”H x 8”D...
- Page 2 Mier Products’ Temperature Controlled Enclosures Installation and Warranty Information ***** AC/Heater Units Must be kept upright at all times or damage to cooling system may result ***** 2000BTU & 800BTU AC Units with compressor coil heater and thermostats with variable controls for both cooling or heating Power: Once installed correctly, the power cords for the AC unit and the heater are within the enclosure.
- Page 3 • The tamper switch should be mounted on the studs at the top of the enclosure • If you have ANY questions regarding the installation of these products, call Mier Products at 1-800-473-0213 For ON-SITE inspection & repair of A/C units, or A/C Tech Support, call nVent Customer Service at 800-896-2665 AC units needing repair or inspection should be viewed onsite and should not be removed.
- Page 4 2000 BTU AC Unit Thermostat Instruction and Malfunction-Switch Wiring Information Many of the air-conditioners and combination air-conditioner/heater units have optional Malfunction Switches in them, that are controlled by the red, yellow, and blue wires that exit the AC unit with the power-cord. Internal facing surface External facing surface Malfunction Switch Wiring...
- Page 5 800 BTU AC Unit Thermostat Instruction and Malfunction-Switch Wiring Information Many of the air-conditioners and combination air-conditioner/heater units have optional Malfunction Switches in them, that are controlled by the red, yellow, and blue wires that exit the AC unit with the power-cord. Internal facing surface Remove FRONT Cover Malfunction Switch Wiring...
- Page 6 3) Wrap the pole-brackets around the pole, insert the attachment bolts, secure and tighten with the lock-nuts. These pole-mount kits are used with the following Mier Products Enclosures: BW-1248BP, BW-1248FC, BW-1248ACE, BW-1248ACHT, BW-124BP, BW-124FC, BW-124ACE, BW-124ACHT, BW-136BP, BW-136FC, BW-136ACE, BW-136ACHT, BW-RACKACE and BW-RACKACHT 800-473-0213 | info@mierproducts.com | www.mierproducts.com...
- Page 7 3/8” socket fitting, to tighten the bands securely around the pole (F). These pole-mount kits are used with the following Mier Products Enclosures: BW-1248BP, BW-1248FC, BW-1248ACE, BW-1248ACHT, BW-124BP, BW-124FC, BW-124ACE, BW-124ACHT, BW-136BP, BW-136FC, BW-136ACE, BW-136ACHT, BW-RACKACE and BW-RACKACHT 800-473-0213 | info@mierproducts.com | www.mierproducts.com...
- Page 8 Customer Shared Mounting Examples and Notes Make sure you properly ground the enclosure, especially if mounting to a wall or wooden posts. If you’re not sure how to do this, consult a certified electrician or contact the manufacturer. Mounted inside the gate- Along a gate using metal house at a gated community tubing to run wiring from...
-
Page 9: Warranty Information
Mier Products, Inc. agrees to repair or replace parts (Mier’s option) that are deemed defective by our Quality Control Team, without charge for parts or labor, if the defective unit is returned prepaid to Mier Products, Inc., Kokomo, IN, within the 30-day period.
Need help?
Do you have a question about the ACE Series and is the answer not in the manual?
