- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS FOR THE RADIATION DETECTION SYSTEM Including Version 14 January 2017 D-tect Systems Group Visionary Products Inc. 11814 South Election Road, Suite 200 Draper, UT 84020 www.dtectsystems.com...
-
Page 2: Table Of Contents
Table of Contents Introduction ..........................3 Installation and Configuration ....................3 System Components......................3 Installation and Setup of your Rad-DX................5 2.2.1 Physical Installation ....................5 Networking Options ......................7 NEMA Enclosure Option ....................7 Operation ..........................9 Software Monitoring Options ..................9 3.1.1... -
Page 3: Introduction
The Rad-DX is a security and inspection system that detects emissions from radioactive material. The Rad-DX system can operate as a stand-alone detector or as part of a larger Rad- DX network for monitoring areas such as buildings or other facilities. - Page 4 Mounting Bracket USB Cable “Pigtail” Wire Harness Wire Nuts and Mounting Screws Power Cable (black or white depending on color of Rad-DX) Table 1: Additional Rad-DX Hardware V019231_14_Rad-DX_Manual.docx Page 4 of 19...
-
Page 5: Installation And Setup Of Your Rad-Dx
3. Plug the wire harness into the back of the Rad-DX unit. 4. Press the Rad-DX onto the wall bracket and make sure it is secure. It will snap into place. The Rad-DX can be removed from the bracket by lifting the top tab with a flathead screwdriver. - Page 6 1. Mount the Rad-DX wall bracket to the wall using drywall anchors or wood screws. 2. Connect the A/C power cord to the Rad-DX. Then plug this cord into a nearby outlet. Note: The plug-in wall method is meant for indoor installation. The IP65 rating does not apply to this method.
-
Page 7: Networking Options
2.3 Networking Options For information on using the Rad-DX in a network please refer to either the DX View desktop or DX Dashboard web manuals. 2.4 NEMA Enclosure Option The Rad-DX can be mounted and sold in a NEMA enclosure that is designed to protect against environmental conditions. - Page 8 Larger, High Gain Antennas: The standard Rad-DX has two built-in antennas—one for Wi-Fi and the other for Mesh communication. The NEMA enclosure option comes with two larger, higher gain antennas, one for each communication type.
-
Page 9: Operation
The DX-Dashboard is a web server application, which can be used to monitor and control a Rad-DX network remotely. It runs on either the D-tect Cloud Server or on the DX Network Assistant (if installed at your facility). Using the DX-Dashboard, you can access your Rad-DX network using any web-enabled device (smartphones, tablets, PCs). -
Page 10: Using The Lcd Screen
Options for the Rad-DX, such as display types and radiation units, can be set using the following process: 1. Connect the Rad-DX device to a power source, either by using the A/C plug or wiring it directly to the junction box (see Physical Installation, Section 2.2.1) 2. -
Page 11: Explanation Of Networking Icons On The Lcd Touch Screen
3.2.1 Explanation of Networking Icons on the LCD Touch Screen Wi-Fi Ethernet Mesh network Battery Level Connection Connection Connection Connection Figure 7: LCD Screen The appearance of any network connection icon indicates that the device is currently connected via the referenced connection. V019231_14_Rad-DX_Manual.docx Page 11 of 19... -
Page 12: Turning Off The Rad-Dx
Turning Off the Rad-DX There are three ways to turn off or “Power Cycle” the Rad-DX. The first way is to simply unplug the power cable and allow the backup battery to die. The second method is to insert a small paper clip into the small hole located on the back of the device. -
Page 13: Specifications
Non-LCD version: 0.5 lb (0.2 kg) LCD version: 0.65 lb (0.3 kg) Environment IP65 rated for indoor/outdoor operation Table 3: Rad-DX Specifications 5.1 Optional NEMA Enclosure Specifications D-tect SensorNet Mesh network, Wi-Fi, Ethernet, USB, with Larger, Communication Higher Gain Antennas... -
Page 14: Dx-Link
Mesh network. In the same manner that a DX-Link can act as a gateway, a Rad-DX that is connected to a PC via a USB cable can also act as a gateway. Again, this can only be done using the DX-View on your PC. - Page 15 Figure 10: Sample USB Power Adapter Figure 11: DX-Link as a Repeater You can now extend the range of communication between the Rad-DX and the monitoring PC. If more range is needed, add more DX-Link repeaters. DX-Links can be used interchangeably as a gateway or a repeater as long as they are on the same mesh channel.
-
Page 16: Compliance Requirements
DX-Links used as repeaters can also be used as repeaters when Rad-DXs are communicating with the D-tect Cloud or D-tect Network Assistant servers. Compliance Requirements This device complies with part 15 of the FCC rules and Industry Canada ICES-003. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 17: Software Usage Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. For Industry Canada Important Note: Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. -
Page 18: Warranty For D-Tect System Products
D-tect Systems. If D-tect Systems agrees to perform services requested and approved by the customer that are not included in either the Limited or Extended Warranty, these services will be billed to the customer at D-tect Systems’ standard prices and terms. - Page 19 . Patent and Software Provisions D-tect Systems will defend at its own expense, any suit brought against you to the extent that it is based on a claim that the Products infringe a United States patent. D-tect Systems will pay those costs and damages finally awarded against you in any such suit which is attributable to any such claim.
