AW-WH035 HDMI Display Mini Card
WirelessHD Application Controller (WAC)
1. Confirm AW-WH035 hardware is installed in the display mini card slot of
notebook or connect with PC by USB and HDMI by the test board.
2. Install WirelessHD Application Controller (WAC) software by click on
"setup" file, and then follow the instruction by software installer.
3. Click on "WiHD Controller" from the desktop to enable WAC after finish the
software installation.
4. Click on "Network" button of WAC for into Network menu.
User's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AzureWave AW-WH035
Summary of Contents for AzureWave AW-WH035
- Page 1 WirelessHD Application Controller (WAC) User’s Manual 1. Confirm AW-WH035 hardware is installed in the display mini card slot of notebook or connect with PC by USB and HDMI by the test board. 2. Install WirelessHD Application Controller (WAC) software by click on “setup”...
- Page 2 5. Select the WiHD receiver from “Current Networks” section click on “Connect” button. 6. WirelessHD network will be linked and display the indicator of connection. The video on local notebook will be displayed on the TV or HDMI monitor connected with WiHD receiver.
- Page 3 FCC Statement : Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into.
