Service Manual
REAR PROJECTION TV
CHASSIS : SJ-113
MODEL : DSJ-4710CRU/4720CRU
Caution
: In this Manual, some parts can be changed for improving. their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List)in
Service Information Center(http://svc.dwe.co.kr)
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. :DSJ113FEFO
Aug. 2004
