- Page 1 OWNER’S MANUAL Model VP Model VB Model VF VERSATILE/PORTABLE CARTRIDGE DUST COLLECTOR V SERIES MODELS - VB, VF, VP...
- Page 2 KNOW YOUR EQUIPMENT READ THIS MANUAL FIRST. Your V Series system should provide many years of trouble-free service. This manual will help you understand the operation of your V Series unit. It will also help you understand how to maintain it in order to achieve top performance. For quick future reference, fill in the system and filter information in the spaces below.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page SAFETY PRECAUTIONS……………………………………………………………ii 1. IMPORTANT NOTICE ................1 2. INTRODUCTION ..................1 2.1 Unit Nomenclature ..................1 2.2 Description and Operation................1 2.3 Air Filtering Operation ................1 2.4 Filter Cleaning Cycle ................1 3. SPECIFICATIONS ..................1 4. INSTALLATION ..................3 4.1 Off Loading and Inspection ..............3 4.2 Installation ....................3 4.2.1 Portable Installation (VP Model) ..........3... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS We have provided many important safety messages in this manual and on the V Series source capture system. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”. -
Page 5: Important Notice
V SERIES Revised 08/09 Cartridge Dust Collector 2.3 AIR FILTERING OPERATION 1. IMPORTANT NOTICE The contaminated air stream is drawn into the collector. This manual contains specific information concerning Once the dust-laden air enters the cabinet, it meets a safety and precautionary measures. It is impossible to baffle plate that disperses the air and significantly list every potential hazard associated with dust reduces the air stream velocity. - Page 6 V SERIES Revised 08/09 Cartridge Dust Collector 61-10036-0001 Figure 1. Basic Unit Operation V SERIES UNIT SPECIFICATIONS Nominal Shipping Filter Sound Cabinet Dimensions (inches) SCF Per Model Airflow Weight Area Level Pulse Width Depth Height (CFM) (lbs) (dBA) VB-1500 1500 30-1/4 52-3/4 46-13/16...
-
Page 7: Installation
V SERIES Revised 08/09 Cartridge Dust Collector See below for the amperage requirements of your unit, 4.2 INSTALLATION given the horsepower and power supply. The unit Different models of the V Series collector require nameplate will provide the electrical specifications of different assembly techniques. -
Page 8: Downdraft Table Assembly (Vb Model)
V SERIES Revised 08/09 Cartridge Dust Collector 4.2.2 DOWNDRAFT TABLE ASSEMBLY (VB MODEL) 4.3 PULSE CLEANING The V Series downdraft table (VB) comes packaged, If your V Series system came with a cleaning system, requiring some assembly before using. Follow the please review the following section for optimum steps below to complete the assembly. -
Page 9: Operation
V SERIES Revised 08/09 Cartridge Dust Collector DOWNTIME CLEANING OPERATION I M P O RTA N T 1. Turn the CLEAN switch to the ON position. The PWR Information for units with 3-phase power light will be ON. A separate motor starter auxiliary isolated dry contact 2. -
Page 10: Checklist
V SERIES Revised 08/09 Cartridge Dust Collector 3. Turn the unit on by pushing the "Power" rocker 4. Check the filter monitor gauge at start-up. The switch to the ON position (refer to Figure 6). On cleaning system should be activated when the gauge 3-phase units, fan rotation will need to be verified has increased 0.5"... -
Page 11: Filter Removal And Replacement
V SERIES Revised 08/09 Cartridge Dust Collector 1. Collected dust may be a potential fire hazard. Refer 6.2 DUST DRAWER REMOVAL to Section 1 of this manual. 1. To access and remove the dust drawer located at the 2. Wear appropriate protective clothing. base of the V Series unit, you must first unseal the drawer by pulling the drawer release handle (see 3. -
Page 12: Servicing Direct Drive Blower
V SERIES Revised 08/09 Cartridge Dust Collector 4. Install a new filter element by sliding it into the filter 7.1 UNIT CONTROL (ON/OFF) housing with the gasket of the after-filter leading. All units will have the blower controlled from the unit 5. -
Page 13: Troubleshooting
V SERIES Revised 08/09 Cartridge Dust Collector 8. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE RECOMMENDED SOLUTIONS The Swing Arm slips from The joints require adjustment. Adjust the joints (refer to Section 8.2 of the set position. Swing Arm Manual) Strong resistance during Lack of grease in the rotating socket. -
Page 14: Illustrated Parts List
V SERIES Revised 08/09 Cartridge Dust Collector Panel shown is with UAS supplied starter 61-10041-0002 ELECTRICAL ENCLOSURE REPLACEMENT PARTS ELECTRICAL ENCLOSURE REPLACEMENT PARTS Item No. UAS Part No. General Description 23-3124-9 CONTACTOR, MOTOR 23-3124-5.0 OVERLOAD RELAY (3-PHASE, 1-1/2 HP, 208,230 V) 23-3124-3.1 OVERLOAD RELAY (3-PHASE, 1-1/2 HP, 460 V) 23-3124-2.4... - Page 15 V SERIES Revised 08/09 Cartridge Dust Collector...
- Page 16 V SERIES Revised 08/09 Cartridge Dust Collector PORTABLE V SERIES REPLACEMENT PARTS PORTABLE V SERIES REPLACEMENT PARTS Item No. UAS Part No. General Description 15-10028-000M SWING ARM, W/PARAVENT HOOD, 6" DIA. x 7' EXTENSION 15-10029-000M SWING ARM, W/PARAVENT HOOD, 6" DIA. x 10' EXTENSION 15-10030-000M SWING ARM, W/PARAVENT HOOD, 6"...
-
Page 17: Appendix
V SERIES Revised 08/09 Cartridge Dust Collector APPENDIX A. V SERIES WRING DIAGRAM 41-2537 Figure 10. Wiring Diagram 120 Volt, Single Phase, Manual Clean 41-2538 Figure 11. Wiring Diagram 120 Volt, Single Phase, Pulse Cleaning 41-2541 Figure 12. Wiring Diagram 230 Volt, Single Phase, Manual Clean... - Page 18 V SERIES Revised 08/09 Cartridge Dust Collector 41-2542 Figure 13. Wiring Diagram 230 Volt, Single Phase, Pulse Cleaning 41-2543 Figure 14. Wiring Diagram, Three Phase, Manual Clean w/ UAS Supplied Starter...
- Page 19 V SERIES Revised 08/09 Cartridge Dust Collector 41-2544 Figure 15. Wiring Diagram, Three Phase, Pulse Cleaning w/ UAS Supplied Starter 41-2545 Figure 16. Wiring Diagram, Three Phase, Manual Clean w/ Customer Supplied Starter 41-2546 Figure 17. Wiring Diagram, Three Phase, Pulse Cleaning w/ Customer Supplied Starter...
- Page 20 UNITED AIR SPECIALISTS, INC. LIMITED WARRANTY UAS warrants to the original purchaser that all equipment will be free from defects in materials and workmanship for one year from the date of shipment from UAS (three years for Smokeeter® and VisionAir™ models other than CC and DC series) and that major structural components on SFC and MCB series will be free from defects in materials and workmanship for ten years from the date of shipment from UAS.
