Summary of Contents for BIO UV UV3205HO
- Page 1 REACTORS IN THE UV MULTILAMP RANGE WITHOUT CLEANING (Picture UV 4205 HO) INSTALLATION AND MAINTENANCE MANUAL UV_SN-GB.doc Copyright BIO-UV - 29/09/2008 Marque, Modèles et Brevets déposés - Produits exclusifs Page 1...
- Page 2 UVPS subsidiary of the BIO-UV COMPLIANCE CERTIFICATE CERTIFICATE OF CONFORMITY BIO-UV and this subsidiary, hereby declares that the following products UV multilamp range comply to the following standards: NF EN 60598-1 + A11 (2001) CEM : EN55015 (Ed.00) + A1 (Ed.01) Number and year of EC stamp: CG-03-006 dated 29/01/2003 LS-03-51003/NL dated 20/02/03...
-
Page 3: Table Of Contents
We thank you for choosing a BIO-UV reactor. Our equipment has been designed to give you reliable and safe operation for many years to come. The BIO-UV reactors have been designed for speed and ease of installation. Their design also makes them easy to maintain.. Read these instructions carefully in order to optimise the operation of your reactor. -
Page 4: Technical Characteristics
A. TECHNICAL CHARACTERISTICS UV HO RANGE 3205 HO 4205 HO 5205 HO 6205 HO 6273 HO REACTOR Material Stainless steel 316L Finish Mirror polish Maximum service pressure 3 Bars Weight (kg) Ø and body length (mm) 204 x 830 273 x 830 Overall length (mm) 1010 Volume (litres) -
Page 5: Maintenance File
B. MAINTENANCE FILE CAUTION: This sheet must be kept up to date. It provides a record of the reactor’s operating cycle. Date Action UV_SN-GB.doc Copyright BIO-UV - 29/09/2008 Marque, Modèles et Brevets déposés - Produits exclusifs Page 5... -
Page 6: Warnings And Safety
C. WARNINGS AND SAFETY BIO-UV reactors are ready to install, no works is required inside the reactor. Read all the instructions in this manual before switching on the BIO-UV appliance. INSTALLATION RECOMMANDATIONS The reactor must be installed: in a technical room, protected from light and rain, after the filter(s), in a dry zone, ambient humidity must be <... - Page 7 USE AND MAINTENANCE M Allow the ultraviolet lamp to cool for at least 30 minutes before handling. M Never look at the ultraviolet lamps when lit. This may cause severe injuries or burns and may even lead to loss of eyesight. M Do not touch the ultraviolet lamp with bare hands, as these would leave impurities that shorten the life of the lamp.
-
Page 8: Starting Up
D. STARTING UP Check that the reactor BIO-UV is properly mounted on your installation. Start your installation to fill the pipes with water. Purge the air of the reactor: - close the valve upstream of the reactor, - unscrew the drain plug on the top of the body reactor, - open the valve upstream of the reactor slowly and close it when the water is forced out through the drain plug, - re-tighten the drain plug and open the valve upstream of the reactor. -
Page 9: Manual Of The Moniteur (Option)
E. MANUAL OF THE MONITEUR (Option) Your UV equipment is fitted with a UV monitor and a UV-C radiation measurement cell. UV MONITOR UV INTENSITY < 50 % 50…70 % > 70 % Main Alarm alarm This monitor will indicate the gradual reduction in the intensity of the lamps throughout their lifetime but may also provide a warning of dirt being deposited in the quartz sleeve or on the UV-C radiation measurement cell. -
Page 10: Changing Uv Lamp And Quartz Sleeve
F. CHANGING UV LAMP AND QUARTZ SLEEVE When a lamp is defective, we recommend to change all lamps and to keep those still valid for the next repairs. SWITCH OFF the reactor CUT the POWER source and EMPTY IT. Unscrew and remove the cover. Unplug each connector of lamp and the ground plug if necessary. - Page 11 Clean the quartz sleeve with acid or white vinegar or replace it if necessary. With a finger inside the sleeve, insert the quartz sleeve into the equipment up to its housing at the bottom of the reactor. The quartz should protrude slightly, it should not be dropped right to the bottom.
-
Page 12: Electrical Unit
G. ELECTRICAL UNIT Electrical unit without monitor: References and quantities by reactor n° Designation 3205 HO 4205 HO 5205 HO 6205 HO 6273 HO 1 Differential circuit breaker D ELE003555 1 ELE003555 1 ELE003555 1 ELE003555 1 ELE003555 1 2 On / Off switch C ELE000271 1 ELE000271 1 ELE000271 1 ELE000271 1 ELE000271 1 3 Orange light H ELE002652 3 ELE002652 4 ELE002652 5 ELE002652 6 ELE002652 6... -
Page 13: Blown Up View
H. BLOWN UP VIEW UV Sensor: Drain plug N° Designation Reference Lamp LPE000005 USI000018 PIE000659 Flat washer Seal JTS000100 Quartz sleeve QUA000018 Drain plug ACC000410 ELE000489 UV Sensor or ELE002114* JTS000230 Seal * Only for UV units with a monitor MIII UV_SN-GB.doc Copyright BIO-UV - 29/09/2008 Marque, Modèles et Brevets déposés - Produits exclusifs... - Page 14 WARRANTIES Units in the BIO-UV range are guaranteed subject to the following conditions: 5 years for the stainless steel reactor (materials and welding) except in the event of use in a highly corrosive environment (brackish or very salty, e.g.: seawater). 2 years for all other components excepting the UV lamp (consumable).
- Page 15 ANNEX 1 Clearance dimensions Blown up view Designation UV_SN-GB.doc Copyright BIO-UV - 29/09/2008 Marque, Modèles et Brevets déposés - Produits exclusifs Page 15...
- Page 16 ANNEX 2 Electrical diagrams UV_SN-GB.doc Copyright BIO-UV - 29/09/2008 Marque, Modèles et Brevets déposés - Produits exclusifs Page 16...
