SAMSUNG POWERED WIFI SURROUND SPEAKER MODEL:CAW-02013 PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE OPERATION AND KEEP IT FOR FUTURE REFERENCE...
Page 2
FCC Warnings WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
LOCATION OF CONTROLS MAIN UNIT: TOP VIEW FRONT VIEW REAR VIEW 1. Play/Pause (WiFi Pairing) Button 8. AUX IN Indicator 2. Previous (Volume Down) Button 9. SD/USB Indicator 3. Next (Volume Up) Button 10. OPTICAL Indicator 11. DC IN Jack 4.
Specification Power supply....................9V Speakers.........................2 X 6W(RMS) Running Time................around 5 hours(with 50% volume) Recharging Time....................around 4 hours Bluetooth working range..............32 feet (tested in open area) Bluetooth version........................V4.1 WiFi working range....................approx. 96 feet Accessories: 1 X AC/DC Adapter for the main unit (9V, 2A ) 1 X 3.5mm Stereo AUX IN Cable 1 X Instruction Manual 1 X Velvet Bag...
Page 6
RECHARGING During playing, press the battery indicator button to display the battery level. Battery Indicator Button The battery indicator will flash blue during low battery level. Battery Indicator Using the supplied Adapter to recharge through the DC IN jack at the rear of the main unit. The red indicator will light up when charging, it will turn blue after fully charged.
3. Activate the Bluetooth function on your Bluetooth device (phone or music device). Please refer to the manufacturer’s instructions of your device. 4. Once you have activated Bluetooth on your device, select the speaker “CAW-02013” from the list of available Bluetooth devices.
AUX IN OPERATION 1. Connected the external audio device to the unit by an audio connection cable with 3.5mm stereo mini jacks as: ~ Insert one end to the Phone; Line Out or AUX Out Jack on the external audio device. ~ Insert the other end to the AUX IN jack on the rear of the main unit.
USB/Sd OPERATION NOTE: Only the USB or SD Card inserted to the unit can the USB/SD mode be selected. The latter one inserted to the unit will be played first. REAR VIEW OF THE UNIT 1. Insert the USB device or SD memory card into the USB port/card slot as shown above figure. 2.
Page 10
CONNECTION THROUGH OPTICAL 1. Connect the Optical out jack from the external audio Player (such like TV, DVD Player, BD Player …etc.) to the OPTICAL IN jack on the subwoofer by the optical connection cable (not supplied) as the figure below: ( F or PCM format only ) REAR VIEW OF THE SUBWOOFER POWER OPTICAL...
Page 11
Activate the WiFi on the phone, search and connect the router (WiFi Source), Tap VARO WIFI CONTROLLER icon to activate and it will try to search the devices (Fig.A). Select CUBE on Fig.B and tap CONNECT SPEAKER, tap Continue on Fig.C.
Page 12
Setup Select the same WiFi (router source) as the phone connected and tap LOGIN on Fig.E. Press and hold the button on the unit as instructed on Fig.F and tap Next to continue. Wait unit the progress bar reach 100% as instructed on Fig.G. Select to add another speaker or play music after successful connection as Fig.H.
Page 13
Setup Wait unit the progress bar reach 100% as instructed on Fig.G. If it displays like Fig.M, tap Try Again to repeate the above stated steps to reconnect. If it does not fail to connect, continue to set the SPEAKER LOCATION, tap Custom...column on Fig.N to rename the speaker location.
Page 14
G lance at The Function of Each Icon On SPEAKER CONTROLS page (Fig.P), tap to return to home page. Tap Rename, browse the Speaker Info and Preset Content. Tap Add a New Speaker to add more speaker as onscreen instructions. Tap Pause All to pause playing on all speakers, tap again to resume play all speakers.
Page 15
G uide of Using App Functions On Home Page, tap Search to search the desired music shown on the below pictures. Home Page On Home Page, tap Favorites to to listen your favorite music, on music playing page, tap the icon to add songs to My Playlist, tap the icon to add songs to Favorites.
Page 16
G uide of Using App Functions On Home Page, tap Sportify to listen music. On Home Page, tap Add More Services to add the desired online programs platform. Tap Line in, Bluetooth, USB Devices or Optical to switch function mode on Fig.S. Tap Setings to check the Version and Feedback information on Fig.T.
Page 17
F AQ Q: Can't stream music to the device? A: Make sure your phone or PAD are in the same Wi-Fi network as your device. If you use 3rd. music APP, please check if the APP supports Airplay, DLNA or Qplay protocol. Q: Can the APP system be controlled independently by two different phones/tablets at the same time or can it only be controlled with one? A:It can be controlled by different phones / tablets.
