Summary of Contents for Saxxot CRU-158

Page 2: Amendments
CR-158 COUPON PRINTER OPERATIONS MANUAL AMENDMENTS Revision Date Description Issued by 15/06/2015 First issue 11/06/2015 Contact Details 28/10/2015 Contact Details, Dip Switches Contact Details, Dip Switches, Testing, 01/04/2016 Serial Connection, Protocols, Barcode Types Innovative Technology assume no responsibility for errors, omissions, or damages resulting from the use of information contained within this manual.
Page 3: Table Of Contents
CR-158 COUPON PRINTER OPERATIONS MANUAL Contents AMENDMENTS .......................2 COPYRIGHT ........................4 LIMITED WARRANTY ......................4 CONNECTING THE PRINTER ...................5 Power & Pulse Connection ..................5 USB Data Connection....................5 Serial Connection .......................6 DIP SWITCHES, BUTTONS & STATUS LEDS ..............6 Dip Switches & Buttons .....................6 LED Status Lights ......................7 BEZEL OPTIONS &...
Page 4: Copyright
CR-158 COUPON PRINTER OPERATIONS MANUAL COPYRIGHT This manual set is Copyright © Innovative Technology Limited. No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Innovative Technology Limited.
Page 5: Connecting The Printer
CR-158 COUPON PRINTER OPERATIONS MANUAL CONNECTING THE PRINTER The printer has three available connections: 7 pin connector, USB or RJ45 socket. 7-Pin RJ45 Connector & P OWER ULSE ONNECTION The 7-pin connector at the centre, rear of the device is for power and for controlling the device via a pulse interface.
Page 6: Serial Connection
CR-158 COUPON PRINTER OPERATIONS MANUAL ERIAL ONNECTION This connector (RJ45) is used for RS232 communication. Pot ‘O’ Gold should be connected here, using an RJ45 1 to 1 eight pin patch lead sold separately. DIP SWITCHES, BUTTONS & STATUS LEDS LEDs Dip Switches Button 1...
Page 7: Led Status Lights
CR-158 COUPON PRINTER OPERATIONS MANUAL LED S TATUS IGHTS The device has 3 LEDs - green, yellow and red - which are used to display the status of the device. The standard statuses are displayed as follows: Slow pulsing yellow Printer idle Slow pulsing yellow and solid red Printer idle, paper low...
Page 8: Bezel Options & Fixing Points
CR-158 COUPON PRINTER OPERATIONS MANUAL BEZEL OPTIONS & FIXING POINTS There are currently two types of bezel available, see below; EUR Bezel US Bezel 4 x fixing points (on bezel) 4 x fixing points (x2 on each side) Note: refer to technical drawings for further installation details. GA02041...
Page 9: Technical Specifications
CR-158 COUPON PRINTER OPERATIONS MANUAL TECHNICAL SPECIFICATIONS DC V OLTAGE Minimum Nominal Maximum Absolute limits 11 V 12 V 26 V Supply ripple voltage 0.5 V @ 100 Hz UPPLY URRENT Standby 100 mA Printing Peak 4.8 A NTERFACE OGIC EVELS Logic Low Logic High...
Page 10: Performance
Thermal roll media Roll Outer Diameter Roll Core Diameter 12.5 Coupon Length Coupon Width Coupon Thickness Print Head Reliability 320,000 coupons Approved Paper can be purchased from SaXXot Germany GmbH using part number LB02014. 9930550514 click here for order GA02041...
Page 11: Field Service
CR-158 COUPON PRINTER OPERATIONS MANUAL FIELD SERVICE NSERTING A ROLL OF PAPER To insert a new roll of paper, remove the roll mandrel from the printer (reverse of Position the roll so that the paper edge comes from below the roll (B). Insert the mandrel into the roll of paper.
Page 12: Removing The Paper Guide
CR-158 COUPON PRINTER OPERATIONS MANUAL EMOVING THE PAPER GUIDE For maintenance or clearing a paper jam, the paper guide may need to be removed. EUR Bezel US Bezel For the EU bezel, squeeze latches For the US bezel, simply lift upwards to inwards and lift paper guide.
Page 13: Micro Sd Card Slot And Battery Compartment
CR-158 COUPON PRINTER OPERATIONS MANUAL ICRO CARD SLOT AND BATTERY COMPARTMENT The micro SD card slot and battery compartment are located on the left hand side of the unit. The battery is accessed via the removable cover. Micro SD card Battery cover slot Inserting a micro SD card expands the memory of the printer, allowing extra fonts,...
