Summary of Contents for Qtx BUSKER-U
- Page 1 BUSKER-U Portable PA Units Order ref: BUSKER-12U (178.966UK) BUSKER-15U (178.968UK) User Manual VERSION 2.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing a Busker-U portable PA unit. This versatile portable PA unit is packed with features in a compact, manageable enclosure and is suitable for a wide array of applications ranging from public address for presentations to outdoor karaoke.
- Page 3 Front Panel UHF microphone indicators UHF Mic A volume UHF Mic B volume USB port LED display SD/MMC card slot USB/SD/FM/Bluetooth volume Media player Mode select Playback Repeat mode select USB/SD memory device select Previous track (hold seek reverse) Play/Pause Next track (hold seek forward) Rear Panel Aux line Volume control...
- Page 4 Powering up Your new Busker-U portable PA unit may arrive with you with the internal battery charged. Before connecting to the mains, turn down all volume controls and switch the unit on (30) and check to see if the power LED above the switch is lit. If not, you will need to charge the battery before use away from mains power.
- Page 5 External Inputs In addition to the Busker-U’s own UHF microphones, two 6.3mm jack inputs (20, 21) are provided to connect external wired or wireless microphones, which are both governed by the WIRED MIC VOL control (16). If required, the music level can be automatically muted when speaking into a microphone by switching in the TALKOVER feature on (25) A further 6.3mm jack input is provided for an electric or electro-acoustic guitar (22)
- Page 6 Once audio is playing through the Busker-U from Bluetooth, adjust the MEDIA volume control (7) to the required volume. Bluetooth on the Busker-U can only pair to a single device at any one time and should be operable over a range of 5 to 8 metres.
- Page 7 Specifications Model BUSKER-12U BUSKER-15U Power supply 230Vac, 50Hz (IEC) Output power 100W Frequency response 50Hz - 16kHz 50Hz - 16kHz SPL @ 1W/1m 94dB 96dB Main driver 300mmØ (12“) 380mmØ (15“) Impedance: loudspeaker 4 Ohms HF driver: type Compression driver Wireless microphone frequencies 863.8MHz + 864.8MHz Battery life...
- Page 8 Troubleshooting Check POWER switch is on Check battery is not drained fully No output and no LEDs lit Check mains lead is connected Check mains or D.C. fuse hasn’t blown Check 9V batteries in wireless transmitters Check wireless transmitters are switched on Power LED lit but no UHF Check that handheld transmitters are not switched to MUTE output...
