TV Wall Mount
Instruction Manual
V1.0
Model: EI6153
Thank you for choosing this ERGO-INNOVATE product! At ERGO-INNOVATE
we strive to provide you with the best quality products and services in the
industry. Should you have any issues, please don't hesitate to contact at
support@ergo-innovate.com(US/CA)
Advertisement
Summary of Contents for Innovate EI6153
- Page 1 Instruction Manual V1.0 Model: EI6153 Thank you for choosing this ERGO-INNOVATE product! At ERGO-INNOVATE we strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact at...
- Page 2 If your TV VESA is greater than 400x400 mm/16x16 in. or less than VESA 75x75mm/3x3in., this mount is NOT compatible. If this mount is NOT compatible, please contact customer service at support@ergo-innovate.com to find a compatible mount. Verify Your Wall Construction If you are not sure the wall...
-
Page 3: Supplied Parts And Hardware
Before starting assembly, verify all parts are included and undamaged. Do not use damaged or defective parts. lf you require replacement parts, contact our Product Support line at support@ergo-innovate.com. • Please note: Not all hardware included in this package will be used. - Page 4 Bolts [Only one bolt size fits your TV] Note: The bolts are shown in accordance with the actual size M4 x 30mm M6 x 15mm M6 x 35mm [E1] [E2] M8 x 15mm M8 x 35mm [F1] [F2] Supplied Part and Hardware for Step 2 Arm Assembly/Wall Plate Level Note:...
- Page 5 Step 1 Secure the Faceplate(or Faceplate with Extender Brackets) to TV 1-1 Choose the combination that applies to your VESA 16in.(400mm) 16in.(400mm) 8in.(200mm) 12in.(300mm) 12in.(300mm) 4in.(100mm) 3in.(75mm) For VESA hole pattern: For VESA hole pattern: For VESA hole pattern: 3x3 in.(75mmx75mm) 12x12 in.(300x300mm) 12x8 in.(300x200mm) 4x4 in.(100x100mm)
- Page 6 When using the spacers it is important to note that they can be used in multi-layers (meaning stacked). If you have any difficulty understanding how to install the TV bolts or spacers, please contact customer service at support@ergo-innovate.com. CAUTION: Ensure the faceplate [02](or faceplate [02]...
- Page 7 1-3 Attach the TV Bracket Option A (For Flat Back TV) E1/F1/D (If needed) (If needed) Alternate Spacer Setups Option B (For Round Back TV) D/E2/F2 (If needed) C1/C2 (If needed) Alternate Spacer Setups...
- Page 8 Option C (For TV with A “Bump”) Spacers may be necessary for 2 holes ONLY. D/E2/F2 (If needed) E1/F1/D C1/C2 Alternate Spacer Setups C1/C2 (If needed) Alternate Spacer Setups Option D For cable interference or inset holes, use spacers to create extra space between the TV and faceplate.
- Page 9 Step 2 Attach the Arm Assembly/Wall Plate [01] to Wall For wood stud installation, follow STEP 2A For concrete installation, follow STEP 2B Step2A Wood Stud Option WARNING: ●Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A1].
- Page 10 2A-3 Drill 3 pilot holes using a 5/32 in.(4mm) diameter drill bit. Make sure the depth is not less than (60mm). 2 23/64 in. 2 23/64 in.(60mm) ø5/32 in.(4 mm) 2A-4 Install the arm assembly/wall plate [01]. using lag screws [A1]. Tighten the lag screws [A1] only until they are pulled firmly against the wall plate.
- Page 11 2B-1 Position arm assembly/wall plate [01] at your desired height, level the wall plate and mark the pilot hole locations. 2B-2 Drill 3 pilot holes using a 3/8 in.(10mm) diameter drill bit. Make sure the depth is not less than 2 9/16 in.(65mm). Never drill into the mortar between blocks.
-
Page 12: Tilt Adjustment
Hang the TV onto the Arm Assembly/Wall Plate [01] Step 3 ① Detach the preassembled bolts [S1] and washers [S2] and keep them for the next step. ② Hang the TV to the Arm Assembly. ③ Tighten the bolts [S1] and washers [S2] to secure TV to the arm assembly.
