Olhausen Games OG Pro Air Hockey Assembly Instructions

Hide thumbs

Table of Contents

Quick Links

Download this manual

OG Pro

Congratulations on your purchase of the Olhausen

Games home entertainment table. We want to ensure

that you are completely satisfi ed with your purchase.

So, please feel free to contact either your dealer or

Olhausen Games for any assistance in the assembly

of your new product or for any other information you

may want or need.

Tools Needed for Assembly:

• Wrenches

• Philips Head Screw Driver

• Level

Be sure to verify that all of the items listed above are included in the box before starting assembly

Assembly Procedure

DUE TO THE WEIGHT AND SIZE OF THE TABLE, IT IS RECOMMENDED THAT

Step 1: Content Removal

• Carefully lift the OG Pro Series cabinet out of the box and lay it on its top, placing it on a clean

and smooth surface to avoid scratching the fi nish.

• Remove the legs from the box and locate the accessory package.

Step 2: Leg Assembly

• Attach the legs to the cabinet using (4) bolts per leg.

• Tighten the leg bolts until bolt heads are fl ush with the table side apron.

*Note: Over-tightning can damage the side aprons

• Repeat this process on each leg.

Step 3: Attach the Blower Motor

• Locate the blower motor, gasket and (3) mounting bolts.

• Place the gasket between the blower motor and the air chamber surface located in the center of

the bottom of the playfi eld

• Line up the holes in the base of the blower with the pre-drilled holes in the air chamber and

tighten all (3) bolts.

• Plug the blower motor into the wall.

(continued on page 2)

(2) PEOPLE ASSEMBLE THE TABLE TOGETHER.

Air Hockey

Assembly Instructions

Content

Cabinet

Legs

Accessory Package

Quantity

OG 110114 P1

Table of Contents

Need help?

Do you have a question about the OG Pro Air Hockey and is the answer not in the manual?

Questions and answers

Summary of Contents for Olhausen Games OG Pro Air Hockey

Page 1 Assembly Instructions OG Pro Congratulations on your purchase of the Olhausen Games home entertainment table. We want to ensure that you are completely satisfi ed with your purchase. So, please feel free to contact either your dealer or Olhausen Games for any assistance in the assembly of your new product or for any other information you may want or need. Tools Needed for Assembly: Content Quantity • Wrenches Cabinet • Philips Head Screw Driver...
Page 2 Assembly Instructions continued for OG PRO Step 4: Flip the Table Over • Check that ll the leg levers are screwed all the way into the legs. • Carefully lift up and roate the table onto its legs. * DO NOT ALLOW WEIGHT OF TABLE TO ROCK ON ANY ONE OR TWO LEGS ALONE. * We recommend that (2) or more people lift the table together. Step 5: Manual Scoring Unit • Locate the top rail with pre-drilled holes to the left and right of the electronic scoring unit area. • Using the (2) score posts, (1) score rod and beads, attach each assembly to the rail. • The black scoring assembly contains (4) black beads and (1) red bead and should be placed at one end of the rail • The red scoring assembly contains (4) red beads and (1) black bead and should be placed at the other end of the rail. The odd colored bead signifies the final point in a game and should be placed so that it is the last bead pulled toward you. Step 6: Power the Game • The blower motor should be plugged into the wall. Step 7: Level the Game • Adjust the leg levelers until the puck floats true on the playing surface.
