Summary of Contents for Opticon EE-290
- Page 1 EE-290 EE-290 V-0.4 Electronic Shelf Label The EE-290 is an e-paper based electronic shelf label with a screen size of 2.9” and with 802.15.4 based wireless communication. V-0.4...
- Page 2 OR USING THE PRODUCT. Serial Number A serial number appears on all Opticon products. This official registration number is directly related to the device purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
- Page 3 EE-290 V-0.4 Revision History Product Name : EE-290 Edition Date Page Section Description of Changes V0.1 2015/10/02 Preliminary Version Section 3, Added dimensions drawing Section 7, Changed Radio Frequency range Section10.1, Changed product safety standards V0.2 2015/10/13 Section10.2, Changed FCC statement Section 11.4,...
-
Page 4: Table Of Contents
EE-290 V-0.4 Contents Abstract ........................6 Overview ........................6 Physical Features ......................6 Dimensions ..........................6 Weight ............................6 Environmental Specifications ..................7 Operating Temperature and Humidity ..................7 Storage Temperature and Humidity ..................7 Static Electricity ......................... 7 Controls ........................8 Electrical Specifications .................... - Page 5 EE-290 V-0.4 Table of Figures Figure 1: Dimensions ..........................6 Figure 2: Product Label ......................... 11 Figure 3: Product Label dimensions ...................... 11 Figure 4: Shipment box label ......................... 12 Figure 5: Individual packaging ....................... 13 Figure 6: collective packaging ....................... 13 Figure 7: collective shipment packaging ....................
-
Page 6: Abstract
“ESL”). 2 Overview The EE-290 is an E-ink based ESL with a 2.4GHz radio for data communication. This product uses Direct Sequence Spread Spectrum RF technology that allows for ultra-low power consumption combined with a reduced sensitivity to background noise. That means less interference by other radios that operate in the 2.4GHz band. -
Page 7: Environmental Specifications
EE-290 V-0.4 4 Environmental Specifications 4.1 Operating Temperature and Humidity Temperature: 0 to 40° C Humidity: 20 to 85% RH (Non Condensing) 4.2 Storage Temperature and Humidity Temperature: -20 to 60° C Humidity: 20 to 85% RH (Non Condensing) 4.3 Static Electricity ±... -
Page 8: Controls
EE-290 V-0.4 6 Controls Items Specifications Remarks Type 8051 core 8-bit MCU Internal flash ROM 128KB Internal RAM 8 KB Clock frequency 32 MHz Active area W 66.90 x H 29.06 mm Number of dots W 296 x H 128... -
Page 9: Electrical Specifications
EE-290 V-0.4 7 Electrical Specifications 7.1 Electrical Characteristics Conditions: Operating voltage 3.0V unless otherwise specified Parameter Unit Remarks Operating voltage 2.3-3.3 Lithium primary battery Sleep current µA When the transmitter and receiver are idle Poll time >= 20 seconds See below The ESL is in sleep mode almost the entire time. -
Page 10: Radio Specifications
EE-290 V-0.4 Battery replacement SOP: 1. Remove the front cover 2. Slide out the 2pcs CR2450 batteries 3. Insert new 2pcs CR2450 batteries 4. Add the front cover. 8 Radio Specifications Parameter Unit Remarks Over the entire temp. and Receiver sensitivity... -
Page 11: Labeling
EE-290 V-0.4 9 Labeling 9.1 Product Label The product label is affixed to the ESL as shown below. Figure 2: Product Label Label material: Material: Base + laminate protection against wear. Base: PP film, thickness 80µm, backing with glue. Laminate: PET film, clear, thickness 25µm. -
Page 12: Shipment Box Labels
EE-290 V-0.4 9.2 Shipment Box Labels The shipment box labels are meant to show the regulatory information on the shipment box as well as the quantity in the box. The labels are 150mm*95mm and are made from plain paper with adhesive backing. -
Page 13: Packaging Specifications
Figure 5: Individual packaging 10.2 Collective Packaging Specification Pack the tray with 20 EE-290’s in a plastic bag, fold the open end of the bag and fix it with a piece of tape. Figure 6: collective packaging... -
Page 14: Figure 7: Collective Shipment Packaging
EE-290 V-0.4 Put 10 stacks, containing 200 ESL’s inside a box and stick the shipment box label on the indicated position. Use cardboard and a plastic bag between each layer of ESL’s as shown below. Figure 7: collective shipment packaging Note: The “RO”... -
Page 15: Regulatory Compliance
EE-290 V-0.4 11 Regulatory Compliance 11.1 Product Safety EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 IEC 60950-1:2005 (2nd Edition)+Am 1:2009+Am 2:2013 11.2 EMC EN55022: 2010 EN55024: 2010 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. -
Page 16: Weee
EE-290 V-0.4 11.3 WEEE Waste Electrical and Electronics Equipment Directive, 2012/19/EU. 11.4 RoHS RoHS: The restriction of the use of certain hazardous substances in electrical and electronic equipment, 2011/65 EC. -
Page 17: Safety
EE-290 V-0.4 12 Safety Handle this product carefully. Do not deliberately subject it to any of the following. 12.1 Shock Do not throw or drop the ESL. Do not place heavy objects on the ESL. 12.2 Temperature Conditions Do not use the ESL at temperatures outside the specified range. -
Page 18: Mechanical Drawing
EE-290 V-0.4 13 Mechanical Drawing Figure 8: Mechanical drawing...
