Item # 1002 556 240
Model # FTA79103N
USE AND CARE GUIDE
SQUARE FIRE PIT
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fire pit. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY FTA79103N
Summary of Contents for HAMPTON BAY FTA79103N
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fire pit. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
- Page 2 Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Safety Information ............2 Planning Assembly ..............3 Hardware Included ..............Product Caution ..............2 Package Contents ..............Safety Warnings ..............2 Assembly ................ 5 Warranty ................ 2 Care and Cleaning ............
- Page 3 Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Table leg Leg connector Cover Barbecue grate Log grate Fire bowl Poker...
- Page 5 Assembly ATTACHING THE TABLE LEGS TO THE TABLE TOP Place the table top (A) upside down on a soft surface. Attach the table legs (B) to the table top (A) using M8x50 combination bolts (BB). Do not fully tighten all bolts at this step. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON...
- Page 6 Assembly (continued) ATTACHING THE LEG CONNECTOR TO THE TABLE LEGS Attach the leg connector (C) to the table legs (B) using M6x15 combination bolts (AA). Do not fully tighten all bolts at this step.
- Page 7 Assembly (continued) TIGHTENING THE BOLTS AND ADDING THE FIRE PITS Once all of the bolts are in place, fully tighten the bolts using the hex wrench (CC) and the wrench (DD). Turn the table right side up. Carefully place the fire bowl (H) in the table rim (A). Then place the following in order, from bottom to top: the log grate (G), the barbecue grate (F) and the lid (E) or the cover (D).
- Page 8 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
