Summary of Contents for Zanussi ZTAN28FW0
- Page 1 User Manual GETTING STARTED? EASY. ZTAN28FW0 EN User Manual Fridge Freezer...
-
Page 2: Safety Information
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. -
Page 3: Safety Instructions
By clients in hotels, motels, bed and breakfast and other – residential type environments. To avoid contamination of food respect the following • instructions: do not open the door for long periods; – clean regularly surfaces that can come in contact with food –... -
Page 4: Electrical Connection
• Make sure the air can circulate around the appliance. The appliance contains flammable gas, • At first installation or after reversing the door isobutane (R600a), a natural gas with a high level wait at least 4 hours before connecting the of environmental compatibility. -
Page 5: Installation
• This appliance contains hydrocarbons in the • Door gaskets will be available for 10 years after cooling unit. Only a qualified person must do the the model has been discontinued. maintenance and the recharging of the unit. DISPOSAL • Regularly examine the drain of the appliance and if necessary, clean it. - Page 6 DIMENSIONS Overall dimensions Space required in use 1610 1) the height, width and depth of the appliance in- cluding the handle, plus the space necessary for free circulation of the cooling air 1) the height, width and depth of the appliance without the handle and feet Overall space required in use Space required in use...
-
Page 7: Rear Spacers
Overall space required in use 1123 1) the height, width and depth of the appliance in- cluding the handle, plus the space necessary for free circulation of the cooling air, plus the space necessary to allow door opening to the minimum angle permitting removal of all internal equipment LOCATION To ensure appliance's best functionality, you should... -
Page 8: Door Reversibility
screws and the pin to it. Put the hinge aside. 5. Carefully lift the upper door from the middle DOOR REVERSIBILITY hinge to remove it. Place the upper door on the soft surface. Be careful not to lose washers WARNING! Before carrying out any that may stick to the door. - Page 9 door. 15. Install the middle hinge to the left side of the appliance by reversing its original position. 10. Remove the hole covers of the middle hinge and put them in the holes on the opposite side. 16. Fit the upper hole of the lower door on the middle hinge pin.
-
Page 10: Operation
OPERATION CONTROL PANEL °C 3sec 1. Temperature indicator 3. Control button 2. Super Freeze indicator SWITCHING ON SUPER FREEZE FUNCTION Insert the plug into the wall socket. The Super Freeze is used to perform pre-freezing and fast freezing in sequence of Freezer SWITCHING OFF compartment. -
Page 11: Hints And Tips
2. Lift the right side of the shelf until it comes free To freeze fresh food activate the Super Freeze from the fastener. function at least 15 hours before placing the food to be frozen in the freezer compartment. Store the fresh food evenly distributed in the freezing compartment. -
Page 12: Hints For Freezing
distributed. Position of the door bins does not directly next to it. Place food at room affect energy consumption. temperature in the part of the freezer • Do not open the door frequently or leave it open compartment where there is no frozen food. longer than necessary. -
Page 13: Hints For Fresh Food Refrigeration
Type of food Shelf life (months) Leftovers without meat 1 - 2 Dairy food: Butter 6 - 9 Soft cheese (e.g. mozzarella) 3 - 4 Hard cheese (e.g. parmesan, cheddar) Seafood: Fatty fish (e.g. salmon, mackerel) 2 - 3 Lean fish (e.g. cod, flounder) 4 - 6 Shrimps Shucked clams and mussels... -
Page 14: Care And Cleaning
CARE AND CLEANING Defrost the freezer compartment when the frost WARNING! Refer to Safety chapters. layer reaches a thickness of about 3-5 mm. To defrost freezer compartment: 1. Switch off the appliance or pull out electrical CLEANING THE INTERIOR plug from the wall socket. 2. - Page 15 WHAT TO DO IF... Problem Possible cause Solution The appliance does not oper- The appliance is switched off. Switch on the appliance. ate. The mains plug is not connec- Connect the mains plug to the ted to the mains socket cor- mains socket correctly.
- Page 16 Problem Possible cause Solution Food products are not wrap- Wrap the food products better. ped properly. Temperature is set incorrectly. Refer to "Operation" chapter. Appliance is fully loaded and is Set a higher temperature. Re- set to the lowest temperature. fer to "Operation"...
-
Page 17: Replacing The Lamp
Problem Possible cause Solution The thickness of the frost is Defrost the appliance. greater than 4-5 mm. The door has been opened of- Open the door only if necessa- ten. The Super Freeze function is Refer to "Super Freeze func- switched on. -
Page 18: Technical Data
NOISES SSSRRR! BRRR! CLICK! HISSS! BLUBB! TECHNICAL DATA The technical information is situated in the rating It is also possible to find the same information in plate on the internal side of the appliance and on EPREL using the link https://eprel.ec.europa.eu the energy label. -
Page 19: Environmental Concerns
ENVIRONMENTAL CONCERNS with the symbol with the household waste. Recycle materials with the symbol . Put the Return the product to your local recycling facility or packaging in relevant containers to recycle it. Help contact your municipal office. protect the environment and human health by recycling waste of electrical and electronic appliances. - Page 20 WWW.ZANUSSI.COM/SHOP...
