USER'S
MANUAL
MPC-3600 Series
Superior Fanless Embedded System
USA: (800) 607-1460
EMAIL: Info@Seatronx.com
WEBSITE: www.seatronx.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPC-3600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Seatronx MPC-3600 Series

  • Page 1 USER’S MANUAL MPC-3600 Series Superior Fanless Embedded System USA: (800) 607-1460 EMAIL: Info@Seatronx.com WEBSITE: www.seatronx.com...

  • Page 2: Table Of Contents

    MPC-3600 | User’s Manual Table of Contents Prefaces ……………………………………………………………………………………………….. 04 Revision ………………………………………………………..……………………………..……………….……….. 04 Disclaimer ……………………………………………………….…….……………….………………….………….. Copyright Notice …………………………………….…….….………………………………….………………… Trademarks Acknowledgment …………..………….………………………………………....Environmental Protection Announcement ……………………………………..……..……………….. Safety Precautions ……………………………………………………………………………………….….…….. Technical Support and Assistance ………………………………...……………………..…….…….……. Conventions Used in this Manual …………………………………..……………………..….……….. Package Contents ……………………………………………………………………..…..…………………….… Ordering Information …………………………..……………………………………..………..….….…………...
  • Page 3 MPC-3600 | User’s Manual Chapter 2 Switches and Connectors …………….……………………………………. Switch and connector Locations ………………………………………..…….….……..2.1.1 Top View ………………………………………………………………………..…..……… 2.1.2 Bottom View ……………………………………………………………..……..……….. 48 Connector / Switch Definition ……………………………….……….…….……..... 49 Switch Definitions ………….……………............. 50 Connector Definitions …………………………............. 50 Chapter 3 System Setup …………………………..…………………………….……………...

  • Page 4: Prefaces

    MPC-3600 | User’s Manual Prefaces Revision Revision Description Date Manual Released 2016/08/23 Switches and Connectors Revised 2017/09/12 Power Connector Definition Revised 2017/11/02 Upper Cover 2D Drawing Revised 2017/11/29 GPIO Sample Code Revised 2018/02/09 New-added CPU support and OS revision 2018/08/20 WDT &...

  • Page 5: Safety Precautions

    Preface MPC-3600 | User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...

  • Page 6: Technical Support And Assistance

    Preface MPC-3600 | User’s Manual Technical Support and Assistance Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call:  Model name and serial number ...

  • Page 7: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty MPC-3600 Series Fanless Embedded System Utility DVD Driver Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No.
  • Page 8 Preface MPC-3600 | User’s Manual Model No. Product Description Superior fanless embedded system with LGA 1151 for Intel® 6 Gen Processor and Q170 PCH, MPC-3611E-4P 2x LAN, 4x PoE, 1x PCIe x16 Expansion Superior fanless embedded system with LGA 1151 for Intel® 6 Gen Processor and Q170 PCH, MPC-3611E-4P-M12 2x LAN, 4x M12 PoE, 1x PCIe x16 Expansion...

  • Page 9: Optional Accessory

    Preface MPC-3600 | User’s Manual Model No. Product Description Superior fanless embedded system with LGA 1151 for Intel® 6 Gen Processor and Q170 PCH, MPC-3622PP-8L 10x LAN, 2x PCI Expansion Superior fanless embedded system with LGA 1151 for Intel® 6 Gen Processor and Q170 PCH, MPC-3622PP-8L-M12 2x LAN, 8x M12 LAN, 2x PCI Expansion...

  • Page 10: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 11: Overview

    MPC-3600 series are ruggedized systems that can operate in harsh environments and easy to install and maintain. A build in over voltage protection (OVP), over current protection (OCP), reverse protection, and wide range DC power input makes MPC-3600 series are safety system for all industrial applications.

  • Page 12: Hardware Specification

    M12, MPC-3622EE(PP/PE)-4P and MPC-3622EE(PP/PE)-4P-M12 Only] Physical • 8x 802.3at Compliant PoE Port, The Maximum DC Power • MPC-3600 Series Delivery on Each PoE is 25.5W. 80W total power budget  Dimension (WxDxH): 240 x 261 x 79 mm [MPC-3600-8P, MPC-3600-8P-M12, MPC-3611E(P)-8P, MPC-3611E(P)-8P- ...

  • Page 13: System I/O

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3 System I/ 1.3.1 MPC-3600 Front Panel Universal I/O Bracket ATX power on/off switch Used to customized I/O output Press to power-on or power-off the system HDD port Reset switch Removable 2.5" SATA HDD Area Press to reset the system Power LED USB 3.0 port...
  • Page 14 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 15: Mpc-3600-4L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.2 MPC-3600-4L(P) Front Panel PoE Port Used to connect the system to a local area ATX power on/off switch network with power over Ethernet Press to power-on or power-off the system (MPC-3600-4P Only) Reset switch Universal I/O Bracket Press to reset the system...
  • Page 16 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 17: Mpc-3600-4L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.3 MPC-3600-4L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3600-4P-M12 Only) Reset switch Press to reset the system...
  • Page 18 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 19: Mpc-3600-8L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.4 MPC-3600-8L(P) Front Panel PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3600-8P Only) Reset switch Press to reset the system HDD port...
  • Page 20 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 21: Mpc-3600-8L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.5 MPC-3600-8L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3600-8P-M12 Only) Reset switch Press to reset the system...
  • Page 22 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 23: Mpc-3611E(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.6 MPC-3611E(P) Front Panel Universal I/O Bracket ATX power on/off switch Used to customized I/O output Press to power-on or power-off the system HDD port Reset switch Removable 2.5" SATA HDD Area Press to reset the system Power LED USB 3.0 port...
  • Page 24 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 25: Mpc-3611E(P)-4L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.7 MPC-3611E(P)-4L(P) Front Panel PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3611E-4P & MPC-3611P-4P Only) Reset switch Press to reset the system Universal I/O Bracket...
  • Page 26 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 27: Mpc-3611E(P)-4L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.8 MPC-3611E(P)-4L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3611E-4P-M12 &...
  • Page 28 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 29: Mpc-3611E(P)-8L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.9 MPC-3611E(P)-8L(P) Front Panel PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3611E-8P & MPC-3611P-8P Only) Reset switch Press to reset the system HDD port...
  • Page 30 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 31: Mpc-3611E(P)-8L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.10 MPC-3611E(P)-8L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3611E-8P-M12 &...
  • Page 32 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 33: Mpc-3622Ee(Pp/Pe)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.11 MPC-3622EE(PP/PE) Front Panel Universal I/O Bracket ATX power on/off switch Used to customized I/O output Press to power-on or power-off the system HDD port Reset switch Removable 2.5" SATA HDD Area Press to reset the system Power LED USB 3.0 port...
  • Page 34 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 35: Mpc-3622Ee(Pp/Pe)-4L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.12 MPC-3622EE(PP/PE)-4L(P) Front Panel PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3622EE-4P & MPC-3622PP-4P & Reset switch MPC-3622PE-4P Only) Press to reset the system...
  • Page 36 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel DisplayPort DC IN Used to connect a DisplayPort monitor Used to plug a DC power input with terminal block USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Speaker-out Used to connect a speaker LAN port Used to connect the system to a local area Mic-in...

  • Page 37: Mpc-3622Ee(Pp/Pe)-4L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.13 MPC-3622EE(PP/PE)-4L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3622EE-4P-M12 &...
  • Page 38 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel USB 3.0 port DC IN Used to connect USB 3.0/2.0/1.1 device Used to plug a DC power input with terminal block LAN port Used to connect the system to a local area Speaker-out network Used to connect a speaker...

  • Page 39: Mpc-3622Ee(Pp/Pe)-8L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.14 MPC-3622EE(PP/PE)-8L(P) Front Panel PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3622EE-8P & MPC-3622PP-8P & Reset switch MPC-3622PE-8P Only) Press to reset the system...
  • Page 40 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel USB 3.0 port DC IN Used to connect USB 3.0/2.0/1.1 device Used to plug a DC power input with terminal block LAN port Used to connect the system to a local area Speaker-out network Used to connect a speaker...

  • Page 41: Mpc-3622Ee(Pp/Pe)-8L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.3.15 MPC-3622EE(PP/PE)-8L(P)-M12 Front Panel M12 PoE Port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network with power over Ethernet (MPC-3622EE-8P-M12 &...
  • Page 42 MPC-3600 | User’s Manual Chapter 1: Product Introductions Rear Panel USB 3.0 port DC IN Used to connect USB 3.0/2.0/1.1 device Used to plug a DC power input with terminal block LAN port Used to connect the system to a local area Speaker-out network Used to connect a speaker...

  • Page 43: Mechanical Dimension

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 MPC-3600 / MPC-3600-4L(P) / MPC-3600-4L(P)-M12 / MPC-3600-8L(P) / MPC-3600-8L(P)-M12 Unit: mm...

  • Page 44: Mpc-3611E / Mpc-3611E-4L(P) / Mpc-3611E-4L(P)-M12 / Mpc-3611E-8L(P) / Mpc-3611E-8L(P)-M12 / Mpc-3611P / Mpc-3611P-4L(P) / Mpc-3611P-4L(P)-M12 / Mpc-3611P-8L(P)

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.4.2 MPC-3611E / MPC-3611E-4L(P) / MPC-3611E-4L(P)-M12 / MPC-3611E-8L(P) / MPC-3611E-8L(P)-M12 / MPC-3611P / MPC-3611P-4L(P) / MPC-3611P-4L(P)- M12 /MPC-3611P-8L(P) / MPC-3611P-8L(P)-M12 Unit: mm...

  • Page 45: Mpc-3622Ee / Mpc-3622Ee-4L(P) / Mpc-3622Ee-4L(P)-M12

    MPC-3600 | User’s Manual Chapter 1: Product Introductions 1.4.3 MPC-3622EE / MPC-3622EE-4L(P) / MPC-3622EE-4L(P)-M12 / MPC-3622EE-8L(P) / MPC-3622EE-8L(P)-M12 / MPC-3622PP / MPC-3622PP-4L(P) / MPC-3622PP-4L(P)- M12 /MPC-3622PP-8L(P) / MPC-3622PP-8L(P)-M12 / MPC-3622PE / MPC-3622PE-4L(P) / MPC-3622PE-4L(P)-M12 / MPC-3622PE-8L(P) / MPC-3622PE-8L(P)-M12 Unit: mm...

  • Page 46: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 47: Switch And Connector Locations

    MPC-3600 | User’s Manual Chapter 2: Switches and Connectors 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 48: Bottom View

    MPC-3600 | User’s Manual Chapter 2: Switches and Connectors 2.1.2 Bottom View...

  • Page 49: Connector / Switch Definition

    MPC-3600 | User’s Manual Chapter 2: Switches and Connectors 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch PWR_SW1 Power Switch RESET1 Reset Switch USB3_1,USB3_2 USB 3.0 Port USB2_1, USB2_2 USB 2.0 Port...

  • Page 50: Switch Definitions

    MPC-3600 | User’s Manual Chapter 2: Switches and Connectors 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode（Default） CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS 2.4 Connectors Definitions PWR_SW1: Power Button...
  • Page 51 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors USB2_1: USB3.0 Connector, Type A Definition USB2_D7- USB2_D7+ USB2_2: USB3.0 Connector, Type A Definition USB2_D8- USB2_D8+ USB2_CN1: USB2.0 Ports Connector Type: 2X5 10-pin box header, 2.0mm pitch Definition Definition USB2_D9+ USB2_D10+ USB2_D9- USB2_D10- Cable Shield...
  • Page 52 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors SIM3：SIM Card Socket Definition Definition UIM3_PWR UIM3_RESET UIM3_VPP UIM3_CLK UIM3_DATA SIM4：SIM Card Socket Definition Definition UIM4_PWR UIM4_RESET UIM4_VPP UIM4_CLK UIM4_DATA COM1_2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub COM1 RS422 / 485 Full RS485 Half Duplex...
  • Page 53 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors COM3_1： RS232 / RS422 / RS485 Connector Connector Type: 2X5 10-pin box header, 2.54mm pitch COM3_1 RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD3 TX3- DATA3- RxD3 TX3+ DATA3+...
  • Page 54 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ VGA_DDC_CLOCK DVI_DDC_CLOCK VGA_DDC_DATA DVI_DDC_DATA VGA VSYNC...
  • Page 55 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors DP2: DisplayPort Connector Definition Definition DP2_LANE0_P DP2_LANE3_N DP2_LANE0_N DP2_LANE1_P DP2_AUX_P DP2_LANE1_N DP2_LANE2_P DP2_AUX_N DP2_HPD DP2_LANE2_N DP2_LANE3_P DP2_PWR SPK_OUT1 : Speaker-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R...
  • Page 56 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X9 18-pin, 3.5mm pitch Definition Definition DC INPUT...
  • Page 57 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors Digital Input Wurung Digital Output Wurung PWR_SW2 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 58 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors CN1: LAN1 and USB3.0 Ports Connector Type: RJ45 port with LEDs and dual USB3.0 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1- USB3_RX2- LAN1_MDI2N USB3_RX1+ USB3_RX2+ LAN1_MDI1N LAN1_MDI3P USB3_TX1-...
  • Page 59 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors LAN3, LAN4, LAN5, LAN6, LAN7, LAN8, LAN9, LAN10 : RJ45 with LEDs Port Connector Type: RJ45 Connector LAN3~LAN10 LAN3~LAN10 Definition Definition LAN_MDI0P LAN_MDI2N LAN_MDI0N LAN_MDI1N LAN_MDI1P LAN_MDI3P LAN_MDI2P LAN_MDI3N Link LED Status LAN3~LAN10 Definition Act LED Status LAN3~LAN10 Definition...
  • Page 60 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors MINIPCIE1: Mini PCI-Express Socket Definition Definition Definition WAKE# +3.3V +3.3V USB2_D11+ +3.3V MINIPCIE RST# MINIPCIE_RXN11 +3.3V +1.5V +3.3V CLKREQ0# MINIPCIE_RXP11 USIM1_VCC USIM1_DATA +1.5V MINIPCIE_CLKN0 USIM1_CLK SMB_CLK +1.5V MINIPCIE_CLKP0 MINIPCIE_TXN11 USIM1_RST SMB_DATA MINIPCIE_TXP11 USIM1_VPP +3.3V...
  • Page 61 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors CN3: Mini PCI-Express / mSATA Socket Definition Definition Definition WAKE# +3.3V +3.3V USB_D13+ +3.3V MINIPCIE RST# MINIPCIE_RXN4 +3.3V (SATA_RXN4) +1.5V +3.3V MINIPCIE_RXP4 CLKREQ1# (SATA_RXP4) USIM3_VCC USIM3_DATA +1.5V MINIPCIE_CLKN4 USIM3_CLK SMB_CLK +1.5V MINIPCIE_TXN4 MINIPCIE_CLKP4 (SATA_TXN4)
  • Page 62 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors SATA1, SATA2: SATA with Power Connector SATA1 SATA1 SATA2 SATA2 Definition Definition Definition Definition SATA_TXP0 SATA_TXP1 SATA_TXN0 SATA_TXN1 SATA_RXN0 SATA_RXN1 SATA_RXP0 SATA_RXP1 +3.3V +3.3V +3.3V +12V +3.3V +12V +3.3V +12V +3.3V +12V +12V +12V...
  • Page 63 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors POWER1, POWER2, POWER3, POWER4: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V PCIE1: PCI-Express X1 Socket Connector Type: PCI-Express X1 Slot Definition Definition +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V...
  • Page 64 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors PCIE1: PCI-Express X16 Socket Connector Type: PCI-Express X16 Slot Definition Definition Definition Definition PCIE_PRSNT1 +12V PEG_TXN6 +12V PEG_RXP6 +12V +12V PEG_RXN6 +12V PEG_TXP7 SMB_CLK PEG_TXN7 PEG_RXP7 SMB_DATA PEG_RXN7 PRSNT2_3 +3.3V +3.3V PEG_TXP8 +3.3V +3.3VSB...
  • Page 65 MPC-3600 | User’s Manual Chapter 2: Switches and Connectors PWR_LED1: Power LED Status Definition POWER LED+ POWER LED- HDD_LED1: HDD Access LED Status Definition HDD LED+ HDD LED- WDT_LED1: Watchdog LED Status Definition WATCHDOG LED+ WATCHDOG LED- GPIO_LED1: GPIO LED Status Definition GPIO LED+ GPIO LED-...

  • Page 66: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 67: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source. 1.

  • Page 68: Removing Pcie/Pci Expansion Module

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.3 Removing PCIe/PCI expansion module 1. This step only applies to MPC-3611 and MPC-3622 series, which is equipped with PCIe/PCI expansion module. 2. Unscrew four screws (M3x5L) circled below. 3. Now you can remove the PCIe/PCI expansion module.

  • Page 69: Removing Chassis Top Cover

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.4 Removing chassis top cover 1. Unscrew the four screws (M3x5L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3. Top cover separated from the system body.

  • Page 70: Installing Sodimm

    3.5 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. Two SODIMM sockets are available for MPC-3600 Series on the top side. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure...

  • Page 71: Installing Cpu

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.6 Installing CPU 1. CPU socket is located on the top side. 2. Press down the CPU socket lever in order to open the socket cover.
  • Page 72 MPC-3600 | User’s Manual Chapter 3: System Setup 3. Remove the CPU protective cover. 4. Insert CPU gently.
  • Page 73 MPC-3600 | User’s Manual Chapter 3: System Setup 5. Press down the lever again to hold the socket cover. 6. Paste thermal pad (1-BR0500040, 29x29x0.5mm) on the CPU.
  • Page 74 MPC-3600 | User’s Manual Chapter 3: System Setup 7. Place the designated heat block onto the CPU with thermal pad. 8. Lock the heat block with three screws (M3x5L). Screw driver will able to penetrate through the holes on the top in order to fasten the screws with copper stud.
  • Page 75 MPC-3600 | User’s Manual Chapter 3: System Setup 9. Paste the thermal pad (1-BR0500041, 76x70x2.0mm) onto the installed heat block. 10. Installation complete.

  • Page 76: Installing Mini Pcie Card / Msata

    Chapter 3: System Setup 3.7 Installing mini PCIe card / mSATA 1. Four mini PCIe slots are available for MPC-3600 series, three on top side and one on bottom side. CN3 and CN4 on the top side support mSATA. Bottom Side Top Side 2.

  • Page 77: Installing Antenna

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.8 Installing antenna 1. Four antenna holes are available for MPC-3600 series on the rear panel and two holes are on the front panel. 2. Remove antenna hole cover on the system panel.
  • Page 78 MPC-3600 | User’s Manual Chapter 3: System Setup 4. Put on washer and fasten the nut with antenna jack. 5. Assemble the antenna and antenna jack together. 6. Attach the RF connector at the cable-end onto the communication module.

  • Page 79: Assembly Chassis Top Cover

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.9 Assembly chassis top cover 1. Place the top cover upside down as shown below. 2. Ensure thermal pad is in place on both the CPU thermal block and PCH thermal block. 3.
  • Page 80 MPC-3600 | User’s Manual Chapter 3: System Setup 4. Push the system body down until it is firmly in place. 5. Fasten the four screws (M3x5L) to lock the system body with top cover.

  • Page 81: Installing Hdd On Internal Sata Hdd Bay

    Chapter 3: System Setup 3.10 Installing HDD on internal SATA HDD bay 1. Two internal SATA HDD bays are available for MPC-3600 series. 2. Unscrew the four screws (M3x5L) to remove the internal SATA HDD bay. 3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L).
  • Page 82 MPC-3600 | User’s Manual Chapter 3: System Setup 4. Install the HDD bracket following the direction below. 5. Fasten the four screws to lock the internal HDD bracket.

  • Page 83: Installing Hdd On Removable Sata Hdd Bay

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.11 Installing HDD on removable SATA HDD bay 1. Two removable SATA HDD bays are available for MPC-3600 Series. 2. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.

  • Page 84: Installing Pcie/Pci Expansion Card

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.12 Installing PCIe/PCI expansion card 1. PCIe or PCI card with FHHL dimension is supported by MPC-3600 series. 2. Unscrew the screw (M3x5L) to remove the plane bracket. 3. Loose the sun screw (circled below) on the holder so the pairing arm can be adjustable. 4.
  • Page 85 MPC-3600 | User’s Manual Chapter 3: System Setup 5. Adjust the arm until it holds the card firmly in place. Then fasten the sun screw on the holder. 6. For MPC-3622 series, which has two expansion slots, follow the same procedure to install the second card.

  • Page 86: Assemble Pcie/Pci Expansion Module

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.13 Assemble PCIe/PCI expansion module 1. Install the expansion module back in place and ensure the golden finger is inserted into the expansion slot. 2. Fasten the four screws (M3x5L) below to lock the expansion module.

  • Page 87: Assemble Chassis Bottom Cover

    MPC-3600 | User’s Manual Chapter 3: System Setup 3.14 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Lock the bottom cover with the six screws (M3x5L).

  • Page 88: Installing Sim Card

    Chapter 3: System Setup 3.15 Installing SIM card 1. For MPC-3600 Series, SIM card slot is located inside the control area. Unscrew the two screws below to remove the cover bracket. 2. Now you can insert SIM card into the socket.
  • Page 89 MPC-3600 | User’s Manual Chapter 3: System Setup 3. Please note that the installation of SIM cards has to match the installation of mini PCIe slots. SIM Card Socket Number Matching Mini PCIe Slot SIM 1 MINIPCIE1 SIM 2 MINIPCIE2 SIM 3 SIM 4 Bottom Side...

  • Page 90: Installing Wall Mount Kit

    Chapter 3: System Setup 3.16 Installing wall mount kit 1. Wall mount kit is available for MPC-3600 series included in the standard package. 2. Place the system upside down so you can see the bottom cover. The highlighted eight screw holes below will be used.

  • Page 91: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 92: Bios Introduction

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 93: Main Setup

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ...

  • Page 94: Advanced Setup

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

  • Page 95: Cpu Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.1 CPU Configuration ■ SW Guard Extensions (SGX) This item allows you to set the SW Guard Extensions. ■ Select Owner EPOCH input type This item allows you to select the owner EPOCH input type. ■...

  • Page 96: Pch-Fw Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.2 PCH-FW Configuration ■ AMT Configuration Intel Active Management Technology (AMT) is hardware-based technology for remotely managing and securing PCs out-of-band. ■ Un-Configure ME Use this function to enable or disable Un-Configure ME without password function.

  • Page 97: Sata And Rst Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.3 SATA And RST Configuration ■ SATA Controller(s) Enable or disable Serial ATA controller. ■ SATA Mode Selection This item allows users to select mode of SATA controller. ■ Serial ATA Port 0 / 1 / 2 / 3 / 4 / 5 This item allows users to enable or disable Serial ATA Port 0 / 1 / 2 / 3 / 4 / 5.

  • Page 98: Rst (Uefi Raid) Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.4 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to RAID, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage Technology”...
  • Page 99 MPC-3600 | User’s Manual Chapter 4: BIOS Setup 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 100: Trusted Computing

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.5 Trusted Computing...

  • Page 101: Acpi Settings

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.6 ACPI Settings ■ Enable ACPI Auto Configuration Enable or disable BIOS ACPI auto configuration.

  • Page 102: Nct6106D Super Io Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.7 NCT6106D Super IO Configuration ■ Serial Port 1 Configuration  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ...
  • Page 103 MPC-3600 | User’s Manual Chapter 4: BIOS Setup ■ Serial Port 2 Configuration  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ...
  • Page 104 MPC-3600 | User’s Manual Chapter 4: BIOS Setup ■ Serial Port 4 Configuration  Serial Port This item will allow users to enable or disable serial port.  Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ...

  • Page 105: Nct6106D Hw Monitor

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.8 NCT6106D HW Monitor These items display the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds.

  • Page 106: Serial Port Console Redirection

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.9 Serial Port Console Redirection ■ Console Redirection This item allows users to enable or disable console redirection. 4.3.10 Network Stack Configuration ■ Network Stack Use this item to enable or disable UEFI Network Stack.

  • Page 107: Csm Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.11 CSM Configuration ■ CSM Support This item allows you to enable or disable CSM support. ■ GateA20 Active This item allows you to select <Upon Request> or <Always>. Upon Request: GA20 can be disabled using BIOS services. Always: Do not allow GA20 disabling.

  • Page 108: Usb Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.3.12 USB Configuration ■ Legacy USB Support This item allows you to select <Enabled>, <Disabled> or <Auto>. Enabled: To enable legacy USB support. Disabled: To keep USB devices available only for EFI specification, Auto: To disable legacy support if no USB devices are connected.

  • Page 109: Chipset

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration ■ VT-d This item allows users to enable or disable VT-d.
  • Page 110 MPC-3600 | User’s Manual Chapter 4: BIOS Setup ■ Graphic Configuration  Primary Display Change the Primary Display. Select <Auto> or <PEG+IGFX> PEG+IGFX (Multiple-Displays): IGFX will be primary and only display under BIOS an DOS mode  GTT Size This item allows you to change the GTT size. ...
  • Page 111 MPC-3600 | User’s Manual Chapter 4: BIOS Setup ■ PEG Port Configuration  PEG 0:1:0  Enable Root Port This item allows you to enable or disable the Root Port.  Max Link Speed This item allows you to configure PEG 0:1:0 Max Sped. ...

  • Page 112: Pch-Io Configuration

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.4.2 PCH-IO Configuration This section allows you to configure the chipset. ■ PCI Express Configuration...
  • Page 113 MPC-3600 | User’s Manual Chapter 4: BIOS Setup  PCI Express Root Port 1 / 3 / 4 / 5 / 6 / 7 / 8 / 9  PCI Express Port 1 / 3 / 4 / 5 / 6 / 7 / 8 / 9 This item allows you to enable or disable PCI Express Port 1 / 3 / 4 / 5 / 6 / 7 /8 / 9 in the chipset.
  • Page 114 MPC-3600 | User’s Manual Chapter 4: BIOS Setup ■ HD Audio Configuration  HD Audio Control detection of the HD-Audio device. This item allows you to select <Enabled>, <Disabled> or <Auto>. Disabled: Azalia will be unconditionally be disabled. Enabled: Azalia will be unconditionally be enabled. Auto: Azalia will be enabled if present, disabled otherwise.

  • Page 115: Security

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.5 Security Security menu allow users to change administrator password and user password settings.  Administrator Password This item allows you to set Administrator Password.  User Password This item allows you to set User Password.

  • Page 116: Boot

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.6 Boot This menu allows you to setup the system boot options.  Setup Prompt Timeout This item sets number of seconds to wait for setup activation key.  Bootup NumLock State This item selects the keyboard NumLock state.

  • Page 117: Save & Exit

    MPC-3600 | User’s Manual Chapter 4: BIOS Setup 4.7 Save & Exit This setting allows users to configure the boot settings.  Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 118: Appendix Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 119: Wdt Sample Code

    MPC-3600 l User’s Manual Appendix – WDT & GPIO WDT Sample Code WDT Setting Psuedo Code #define AddrPort 0x2e #define DataPort 0x2f #define SIO_UnLock_Value 0x87 #define SIO_Lock_Value 0xaa #define WATCHDOG_LDN 0x07 #define GPIO_Port 0xF1 //Enter_Config WriteByte (AddrPort, SIO_UnLock_Value); WriteByte (AddrPort, SIO_UnLock_Value); //Enter WATCHDOG LDN WriteByte (AddrPort, 0x07);...

  • Page 120: Gpio Sample Code

    MPC-3600 l User’s Manual Appendix – WDT & GPIO GPIO Sample Code GPIO Setting PIN# GPIO# Default Configuration XCOM- XCOM+ OUT8 DIO Output8 DIO Input8 OUT7 DIO Output7 DIO Input7 OUT6 DIO Output6 DIO Input6 OUT5 DIO Output5 DIO Input5 OUT4 DIO Output4 DIO Input4...
  • Page 121 All Rights Reserved MPC-3600 | User’s Manual...

This manual is also suitable for:

Mpc-3611e-4pMpc-3611e-4p-m12Mpc-3611e-8pMpc-3611e-8p-m12Mpc-3611pMpc-3611p-4l ... Show all

Table of Contents
