Summary of Contents for MDL POWERUP 15HP
- Page 1 Page 1 MDL POWERUP LIMITED Dalston Carlisle OPERATERS MANUAL 15HP PETROL LOG SAW Please read through manual thoroughly before operation For any technical issues please call the workshop on 01228 712121 Or email info@mdlpowerup.com...
-
Page 2: Product Models
Page 2 INDEX: Introduction Safety Machine installation Operation Care and maintenance Technical specifications Exploded view Parts list MDLpowerup Warranty PRODUCT MODELS Engine 177FA, 15.0HP, single-cylinder, air-cooled, 4 strokes OHV single cylinder, horizontal shaft, Engine certificate: CE Bore x stroke 77mm x 58mm Displacement 270ml Compression ratio 8.2:1 Max. -
Page 3: Safety Instructions
Page 3 SAFETY INSTRUCTIONS Before operating the your AGF flail mower, please read the following safety instructions. Failure to comply with these warnings may result in serious injury or death. Please review these safety instructions with all users annually. SIGNAL WORDS: The signal words DANGER, WARNING and CAUTION are used with the safety messages in this manual and with each safety sign. -
Page 4: Specified Conditions Of Use
Page 4 These instructions have been written in a way which facilities learning of how to safely operate your saw. Here is a guide on how you should read these instructions: - Read these instructions before use. Pay special attention to the safety instructions - These instructions are intended for persons having a basic technical knowledge of the operation of machines such as the one described here. - Page 5 Page 5 2.2 General safety instructions When using this machine observe the following safety instructions, to exclude the risk of personal injury or material damage. Please also observe the special safety instructions in the respective chapters; where applicable, follow the legal directives or regulations for the prevention of accidents pertaining to the use of circular saw.
- Page 6 Page 6 Do not change any parts. Hazard generated by machine defects! Keep machine and accessories in good repair. Observe the maintenance instructions. Before any use check machine for possible damage: Before operating the machine all safety devices, protective guards or slightly damaged parts need to be checked for proper function as specified.
- Page 7 Page 7 supply. This machine should never be connected to power supply when you are assembling parts, making adjustments, installing. Carefully remove all parts from the carton and place the machine on a level work surface. Separate and check against the list of loose parts. If any parts are missing, do not operate this machine until the missing parts are replaced.
- Page 8 Page 8 surroundings. 3. Remove wood dust depositions in the work area (do not blow away!) Hazard generated by insufficient personal protection gear! 1. Wear suitable work clothing, providing protection against falling logs. 2. Wear hair protection. 3. Wear safety glasses. 4.
- Page 9 Page 9 Hazard generated by pieces of wood being hurled away! 1. Always place curved logs on the feed rocker with the curved side facing the saw blade. 2. Do not jam the logs to be cut. 3. Do not attempt to stop the saw blade by pushing the workpiece against its die.
- Page 10 Page 10 1. Check that all safety devices are operational again after each service. 2. Replace damaged parts, especially safety devices, only with genuine replacements parts since parts not tested and approved by the equipment manufacturer can cause unforeseeable damage. 3.
- Page 11 Page 11 - saw blades with visible damage; - cut-off wheel blades. 5.2 Saw storage Store saw so that - it cannot be started by unauthorized persons, and -nobody can get injured. Caution! Do not store saw unprotected outdoors or in damp environment. Note: Always install the transport brace before transporting the saw.
- Page 12 Page 12...
- Page 13 Page 13...
- Page 14 Page 14...
-
Page 15: Warranty
Page 15 Warranty MDL warrants to the original purchaser that this MDL product will be free from defects in material and workmanship beginning on the date of purchase by the end user according to the following schedule when used as intended and under normal service and conditions for personal use. - Page 16 Page 16 01228 712121 www.mdlpowerup.com info@mdlpowerup.com...
