PRODUCT NO.
BASE MODEL NO.
FRT16DNHD0
FRT16DNH
FRT16DNHW0
FRT16DNH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995325098
990623
-EN/SERVICE /ECL
357
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT16DNH
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT16DNH
Summary of Contents for Frigidaire FRT16DNH
- Page 1 PRODUCT NO. BASE MODEL NO. FRT16DNHD0 FRT16DNH FRT16DNHW0 FRT16DNH MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - # 218755000 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR...
- Page 2 Publication No. FRT16DNH 5995325098 DOOR 06/99...
- Page 3 A = FRT16DNH (FRT16DNHW0) B = FRT16DNH (FRT16DNHD0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT16DNH DOOR PART NO DESCRIPTION 5308007123 Gasket-frzr door,white ,magnetic 5303288856 Gasket-frzr door,almond ,magnetic 5318680311 Gasket-refr door,white ,magnetic 5303288857 Gasket-refr door,almond ,magnetic 218359001...
- Page 4 Publication No. FRT16DNH 5995325098 CABINET 06/99...
- Page 5 A = FRT16DNH (FRT16DNHW0) B = FRT16DNH (FRT16DNHD0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16DNH CABINET PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5303001388 Plug-button,white...
- Page 6 Publication No. FRT16DNH 5995325098 SHELVES 06/99...
- Page 7 A = FRT16DNH (FRT16DNHW0) B = FRT16DNH (FRT16DNHD0) POS. NO 14 # 19 # 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16DNH SHELVES PART NO DESCRIPTION 218651800 Mullion,white 218651801 Mullion,almond 218781001 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2)
- Page 8 Publication No. FRT16DNH 5995325098 SYSTEM 06/99...
- Page 9 A = FRT16DNH (FRT16DNHW0) B = FRT16DNH (FRT16DNHD0) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # # = Fast-moving Parts * = Non-Illustrated Parts FRT16DNH SYSTEM PART NO DESCRIPTION 218491000 Condenser 5303017691 Spacer-tube 5303208866...
-
Page 10: Wiring Schematic
Publication No. FRT16DNH 5995325098 WIRING SCHEMATIC 06/99... -
Page 11: Wiring Diagram
FRT16DNH Publication No. 5995325098 WIRING DIAGRAM # = Fast-moving Parts 06/99 * = Non-Illustrated Parts...
