Summary of Contents for OXE CoastKey
- Page 1 DIESEL ENGINE COASTKEY MANUAL Publication No: ODM1021 OXE DIESEL COASTKEY MANUAL...
-
Page 3: Preface
CoastKey wireless kill switch system allows you the freedom to move safely around the boat while preserving the Kill Switch function without being attached to the traditional kill cord. CoastKey also allows you to start and stop up to four engines as well as tilting and trimming the engine(s). - Page 4 OXE DIESEL COASTKEY MANUAL...
-
Page 5: Table Of Contents
Using the Tilt and Trim function ___________________________________________________________ 19 Changing your PIN code _________________________________________________________________ 19 Pairing a new or extra remote control ______________________________________________________ 20 Maintenance ___________________________________________________________________________ 21 Replacing the battery on the remote control _________________________________________________ 21 Before calling for support ________________________________________________________________ 22 OXE DIESEL COASTKEY MANUAL... -
Page 6: Overview
OVERVIEW OVERVIEW Fig. 1 CoastKey wireless kill switch system components - single configuration The CoastKey system consists of a remote control (1), a start panel (2), motor module(s) (3), and adapter harness(es) (4). TECHNICAL DATA Remote control Dimensions (D x H): 50 x 12 mm... - Page 7 We recommend that you test the safety range on board your boat. This should be done in the open sea while you move around the boat. The product is certified according to the following standards: Safety: EN 60950-1 EMC: EN 301 489-17 V3.1.1 Radio: EN 300 328 V2.1.1 FCC Part 15.249 ISED RSS-210 OXE DIESEL COASTKEY MANUAL...
-
Page 8: Safety And Warnings
The system will not stop the engine(s) if the driver falls on board the boat. The remote control with an attached string will float if it falls into the water. Additional weight attached to the remote control will cause it to sink. OXE DIESEL COASTKEY MANUAL... -
Page 9: Installation
Do not alter or tamper with the CoastKey system and design. Only use the CoastKey for its original purpose and only install as per the directions in this manual. Familiarize yourself with the national safety rules and regulations in your region to avoid a breach of these rules and help prevent accidents. -
Page 10: Connecting The Cables
INSTALLATION CONNECTING THE CABLES The CoastKey wireless kill switch system can control from one to four motors. Connection of the cable harness depends on the number of motors. Fig. 3 One-motor application The one-motor application uses one cable harness and a single motor controller. -
Page 11: Initiating Your Pin Code
Connect the start panel to the motor controller. Disconnect the connectors to the helm harness(es) in the motor wiring system. Insert the CoastKey cable harness connectors into the open connectors of the motor wiring harness. INITIATING YOUR PIN CODE The “first time” power is turned ON, the yellow LED indicator on the start panel flashes quickly, indicating that a PIN code must be created. -
Page 12: Pairing The Remote Control To The Start Panel
PIN at the factory. The default PIN code is: “1234”. In this case, the remote control will already be paired with the start panel. It is recommended that you change this PIN code. To do this, see Changing the PIN code. OXE DIESEL COASTKEY MANUAL... -
Page 13: Operation
The backlight on the start panel comes on when the battery switch is turned on. Once the boat is powered up, the backlight will come on each time a key is pressed. The backlight stays on for 2 minutes after power-up and after each keystroke. OXE DIESEL COASTKEY MANUAL... - Page 14 Stop engine(s) – Ignition off Press and release the ON/OFF button. The engine(s) will stop and ignition is switched offf and the start panel is locked. OXE DIESEL COASTKEY MANUAL...
- Page 15 3 = engine number 3 4 = engine number 4 The ignition goes on for the selected engine. After about 2 seconds, the start signal goes on to the selected engine. Release the number button when the engine starts. OXE DIESEL COASTKEY MANUAL...
-
Page 16: Remote Control
NOTE! The remote control must be used to enable the Kill Switch function. The CoastKey system will only work as a kill switch if the remote control is used to turn on the ignition. Activation of the Kill Switch function is done automatically when you use the remote control to start the engine(s). - Page 17 If ignition is switched on and engine(s) have not been started: On the remote control, press and release the START/STOP button. red LED indicator on the remote control flashes to indicate that ignition is off. The Kill Switch function is deactivated - OFF. OXE DIESEL COASTKEY MANUAL...
-
Page 18: Using The Kill Switch Function - Mob
WARNING The gear lever must be returned to neutral for the engine(s) to start. The CoastKey system will only work as a Kill Switch if the remote control was used to start the engines. CoastKey will only stop the engine(s) if the driver falls overboard and has the remote control attached. -
Page 19: Using The Tilt And Trim Function
NOTE! Once your PIN code is changed, the remote control must again be paired with the start panel. NOTE! If system is pre-set with the default PIN (1234), it is very important to change your PIN immediately to a personal PIN upon installation to help prevent theft. OXE DIESEL COASTKEY MANUAL... -
Page 20: Pairing A New Or Extra Remote Control
The yellow LED indicator in the start panel stops flashing. On the remote control, release the START/STOP button. The remote control is now paired with the start panel. must be replaced (battery type: CR2032). OXE DIESEL COASTKEY MANUAL... -
Page 21: Maintenance
Insert a new CR2032 (3 V lithium) battery. Put the battery cover in place and screw clockwise. WARNING Incorrect polarity can damage the remote control. NOTE! The O-ring on the remote control battery cover should be changed every three years to keep the remote control waterproof. OXE DIESEL COASTKEY MANUAL... -
Page 22: Before Calling For Support
Make sure that you are within radio range (max. 10 meters) from the start panel. The engines will not start from the remote control: Make sure that the main power switch is on and that the main batteries have enough voltage. OXE DIESEL COASTKEY MANUAL... - Page 23 OXE DIESEL COASTKEY MANUAL...
- Page 24 Cimco Marine AB, Metallgatan 17 B Ängelholm, SE-262 72 Ängelholm, SWEDEN +46 (0)431-37 11 30, www.oxe-diesel.com Printed in Sweden 2019. Copyright © 2019 Cimco Marine AB. OXE DIESEL COASTKEY MANUAL...
